- Page 1 TD-AUDIQ73G Audi MMI/3g Installation Manual Applications: Audi A4/A5/A6/A7/A8 Q5/Q7 with MMI/3g...
- Page 2 Contacts www.INTRAPHEX support@intraphex.com Support: 810.355.2266 Fax: 866.431.0676...
-
Page 3: What's In The Box
Contents What's in the Box RGB Interface RGB Interface LCD Switch Box Monitor Cable Remote A/V Input Cable IR Receiver ... - Page 4 Please note that not all features of the interface are used for the INTRAPHEX rear camera installation. For all other features please contact technical support.
- Page 5 REAR CONNECT TO REVERSE 12 VOLT TRIGGER ***MUST USE RELAY*** MODE - CAN H/L - SAFE CONNECT TO PARKING BRAKE WHEN USING VIDEO INPUTS FOR DVD CONNECT TO SUPPLIED IR SENSOR FOR SCREEN ADJUSTMENT CAN BE REMOVED AFTER ADJUSTMENT GPIO-ZO - CONNECT TO VEHICLE GROUND CONNECT TO VEHICLE ACC 12 VOLT...
- Page 6 PLEASE REMEMBER TO SET THE DIPSWITCHES ACCORDING TO YOUR REQUIRED SETUP OF THE INTERFACE. BE SURE TO TURN OFF ACC POWER WHEN SETTING DIP SWITCHES, FAILURE TO DO SO CAN CAUSE DAMAGE TO INTERFACE MODULE. PLEASE CONTACT INTRAPHEX TECHNICAL SUPPORT IF YOU NEED ASSISTANCE...
- Page 7 ON THE LEFT IS A PICTURE OF THE BACK OF THE COMMAND MODULE AND LCD SCREEN. NOTE THE LVDS CONNECTORS CIRCLED (PLUG COLORS MAY CHANGE FROM YEAR TO YEAR BUT CONNECTOR IS THE SAME), FOLLOW THE DIAGRAM ON THE LEFT TO “LOOP THE LVDS SIGNAL THROUGH THE SUB BOARD OF THE MMI INTERFACE MODULE WITH THE SUPPLIED LVDS CABLE.
- Page 8 ONCE INSTALLED AND WORKING, IT WILL BE NESSICARY TO ALIGN THE PICTURE OF THE MODULE. THIS CAN BE DONE BY POINTING THE REMOTE AT THE IR SENSOR AND PRESSING THE LEFT BUTTON FOR 2 TO 3 SECONDS. USE THE REMOTE TO CENTER THE PICTURE OF THE INTERFACE. ***NOTE*** IT IS BEST TO PERFORM THIS AFTER THE LCD HAS BEEN REISTALL AND THE TRIM BEZEL IS IN PLACE, TO MAKE SURE IT IS CENTERED.
- Page 9 INTRAPHEX THREE YEAR LIMITED WARRANTY NONTRANSFERABLE Terms of Limited Warranty INTRAPHEX, a division of TATMAR LLC, a Michigan Limited Liability Company, (INTRAPHEX) warrants to the original retail purchaser, that the product(s) purchased from an INTRAPHEX authorized dealer, in the original vehicle, are free from defects in materials or workmanship under nor- mal use and conditions for a period of THREE (3) years from date of purchase.
