CardioWall
®
Outdoor Portrait
Order and Installation Manual
For models from March 2020 onwards
Rugged Interactive
Unit 1, Callywith Court
Callywith Industrial Estate, Bodmin
Cornwall, UK
PL231 2RQ
+44 (0) 1726 981 123
www.rugged-interactive.co.uk
hello@rugged-interactive.co.uk
Updated 12/01/2021
© Rugged Interactive
2021
Advertisement
Chapters
Table of Contents
Related Manuals for Rugged Interactive CardioWall Outdoor Portrait
Summary of Contents for Rugged Interactive CardioWall Outdoor Portrait
- Page 1 ® Outdoor Portrait Order and Installation Manual For models from March 2020 onwards Rugged Interactive Unit 1, Callywith Court Callywith Industrial Estate, Bodmin Cornwall, UK PL231 2RQ +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk Updated 12/01/2021 © Rugged Interactive 2021...
-
Page 2: Table Of Contents
3.1 Parts List 3.2 Tools and Components List 3.3 Installation Overview 3.4 Detailed Installation Section 4 – How to Use Section 5 – Programs Guide CardioWall Outdoor Portrait System Specifications CardioWall Outdoor Portrait Installation Checklist Next Steps © Rugged Interactive 2021... -
Page 3: Section 1 - Ordering Process
Installation manual purpose and limitations This manual is intended to provide guidance only, the installation of the Rugged Interactive product will be under your control. You will be responsible for making sure, upon completion of the installation, it is safe to use. -
Page 4: Order And Installation Checklist
1.2 - Order and Installation Checklist ☐ Contact the Rugged Interactive sales team or a partner / distributor to begin the process. Confirm the invoice and delivery address along with date required (lead time is at least 5 weeks), ☐... -
Page 5: Ordering And Installation Timeline
The CardioWall can stimulate a huge range of functional exercises and motor skills. The CardioWall Outdoor Portrait features multiple game modes. A ‘blank canvas’ for PT’s to create their own routines for clients. Every routine is a game, challenging users to beat their previous best score, their friends or the leader board. -
Page 6: Getting Started
If further information is required, please get in touch and we will be able to provide further information and guidance. 1.6 - Place Order To begin the order process with Rugged Interactive: Email: Sales@rugged-interactive.co.uk Or call the Sales Office:... -
Page 7: Section 2 - Safety Guidelines
Tidy back loose cables that could become a tripping hazard. ▪ Ensure that the playing area is clear. ▪ Immediately inform Rugged Interactive for maintenance advice if you have concerns. ▪ Don’ts: Do not wear shoes with leather soles or high heels. -
Page 8: In Play Safety Guidelines
(such as buckles, studs, toggles or alike). Do not wear shoes with leather soles, high heels, sandals, boots or bare feet. ▪ No food, drink or chewing gum during participation. ▪ © Rugged Interactive 2021 CardioWall Outdoor Portrait – Section 2 - Safety Guidelines... - Page 9 Use of this equipment is physically demanding: this is a high-impact, full body activity which requires intense focus, awareness of your body’s strengths and limitations, awareness of the environment around you and extreme caution. © Rugged Interactive 2021 CardioWall Outdoor Portrait –...
-
Page 10: Section 3 - Installation
Section 3 - Installation 3.1 - Parts List Please check off the received parts for the installation and alert Rugged Interactive immediately if anything is missing. 1 x Outdoor Portrait Wall (two halves). ☐ 8 x Plastic bungs. -
Page 11: Installation Overview
3.3 - Installation Overview Below is an overview of the steps needed to install CardioWall Outdoor Portrait. More detail for the process is provided in the following pages. Please read through ALL of this prior to beginning the installation and if you are in any doubt, contact Rugged Interactive. -
Page 12: Detailed Installation
Read this manual before installing the CardioWall. Installation Guidelines: Please complete the Site Survey form prior to delivery and/or installation. ▪ Please send a completed Installation Checklist after any installation to Rugged Interactive. ▪ A typical installation should take 2 people about 2 hours. ▪... - Page 13 A waiting / spectating area positioned nearby is advised. ▪ A leaderboard to go with each unit is highly recommended. ▪ IF YOU ARE IN ANY DOUBT, CALL RUGGED INTERACTIVE DIRECTLY ON +44 (0) 1726 833 882 © Rugged Interactive 2021 CardioWall Outdoor Portrait –...
- Page 14 CardioWall Outdoor Portrait Installation The Outdoor Portrait will be delivered in two boxes, a top and bottom section. Both boxes will be labelled either A or B, if combat is required across two walls, on A wall and one B wall will need to be installed.
- Page 15 Fix the top section to the wall ensuring it is level. Connect the four cables to the correct positions and refit the panel screws. © Rugged Interactive 2021 CardioWall Outdoor Portrait – Section 3 - Installation...
- Page 16 Ensure all fixings are tight and secure. Install power and test the wall works as expected. © Rugged Interactive 2021 CardioWall Outdoor Portrait – Section 3 - Installation...
- Page 17 Ideally a two-man job, but otherwise fully removing the bottom panel will mean resealing the top edge. © Rugged Interactive 2021 CardioWall Outdoor Portrait – Section 3 - Installation...
-
Page 18: Section 4 - How To Use
Section 4 - 3 4.1.2 Menu Section 4 - 6 4.1.3 5 Pod Menu Section 4 – 7 4.1.4 End of Program Section 4 – 8 4.1.5 Combat © Rugged Interactive 2021 CardioWall Outdoor Portrait – Section 4 - How to Use... -
Page 19: Standard Cardiowall
3. Chaser 4. CardioBeat 5. LowFive In this idle state, the are QuickStart options for the programs. The are menu options green pods blue pods [Figure 4.1]. CardioWall Outdoor Portrait – Section 4 – How to Use © Rugged Interactive 2021... -
Page 20: Menu
CardioWall to its idle state. Select either the yellow, pods to blue pod green set the playing options for ClearOut, ClusterShot or Chaser respectively [Figure 4.2]. CardioWall Outdoor Portrait – Section 4 – How to Use © Rugged Interactive 2021... - Page 21 Select the to return the CardioWall to its idle state. green pod blue pod The program duration will be shown on the time display [Figure 4.3]. CardioWall Outdoor Portrait – Section 4 – How to Use © Rugged Interactive 2021...
- Page 22 The lights will illuminate as shown in Figure 4.4. Select one of these illuminated lights to set the highest pod that can be reached. Once the highest has been confirmed, the CardioWall will sound, “Hit the lowest pad you can reach.” CardioWall Outdoor Portrait – Section 4 – How to Use © Rugged Interactive 2021...
- Page 23 Figure 4.5: CardioWall Lowest Pod Selection NOTE: At any time, if the CardioWall behaves unexpectedly, wait for at least 20 seconds for the unit to reset to its idle state. CardioWall Outdoor Portrait – Section 4 – How to Use © Rugged Interactive 2021...
- Page 24 CardioWall’s idle state. NOTE: At any time, if the CardioWall behaves unexpectedly, wait for at least 20 seconds for the unit to reset to its idle state. CardioWall Outdoor Portrait – Section 4 – How to Use © Rugged Interactive 2021...
-
Page 25: End Of Program
Figure 4.7: “Would you like to play again?” NOTE: At any time, if the CardioWall behaves unexpectedly, wait for at least 20 seconds for the unit to reset to its idle state. CardioWall Outdoor Portrait – Section 4 – How to Use © Rugged Interactive 2021... -
Page 26: Combat
Combat will illuminate when available. With combat illuminated, one user begins the game on one wall and the “challenge” has to be accepted by the other wall. CardioWall Outdoor Portrait – Section 4 – How to Use © Rugged Interactive 2021... -
Page 27: Section 5 - Programs Guide
For gameplay greater than or equal to 10 minutes, wait for at least 2 minutes for the unit to reset to its idle state. This longer time-out period is designed to allow multiplayer circuit training. © Rugged Interactive 2021 CardioWall Outdoor Portrait –... - Page 28 For gameplay greater than or equal to 10 minutes, wait for at least 2 minutes for the unit to reset to its idle state. This longer time-out period is designed to allow multiplayer circuit training. © Rugged Interactive 2021 CardioWall Outdoor Portrait –...
- Page 29 For gameplay greater than or equal to 10 minutes, wait for at least 2 minutes for the unit to reset to its idle state. This longer time-out period is designed to allow multiplayer circuit training. © Rugged Interactive 2021 CardioWall Outdoor Portrait –...
- Page 30 L7.2 NOTE: At any time, if the CardioWall behaves unexpectedly, wait for the program to end and for the unit to reset to its idle state. © Rugged Interactive 2021 CardioWall Outdoor Portrait – Section 5 - Programs Guide...
- Page 31 1 minute NOTE: At any time, if the CardioWall behaves unexpectedly during gameplay, wait for at least 30 seconds for the unit to reset to its idle state. © Rugged Interactive 2021 CardioWall Outdoor Portrait – Section 5 - Programs Guide...
- Page 32 +1 point for each pod hit NOTE: At any time, if the CardioWall behaves unexpectedly during gameplay, wait for at least 30 seconds for the unit to reset to its idle state. © Rugged Interactive 2021 CardioWall Outdoor Portrait –...
- Page 33 Rugged Interactive Unit 1, Callywith Court, Callywith Industrial Estate, Bodmin, Cornwall, UK PL31 2RQ +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk CardioWall Outdoor Portrait System Specifications Dimensions and Weights: Approx. Shipment Details Fully Assembled Details Size (mm) Weight Size (mm) Weight...
- Page 34 CardioWall Outdoor Portrait Order and Installation Manual: System Specifications 1070 Figure 1: CardioWall Outdoor Portrait mounting points (Dimensions in mm) © Rugged Interactive 2021 CardioWall Outdoor Portrait - System Specifications...
- Page 35 PL31 2RQ +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk CardioWall Outdoor Portrait Installation Checklist Please complete this checklist after any installation: Check 1: Pre-power up checks. Equipment is stable, secure and (if applicable) mounted to a wall of a suitable construction ☐...
- Page 36 Play area is clear. ☐ Instruction / training carried out by an appropriate instructor to all new users. If anything unexpected occurs or problems persist after troubleshooting, call Rugged Interactive directly on +44 (0) 1726 833 882. © Rugged Interactive 2021 CardioWall...
- Page 37 Next Steps Train team members Train your team members on how to use CardioWall Outdoor Portrait, having knowledge of the gameplay will help them encourage users. Inspire them to cheer and celebrate with the users when they achieve high scores.
- Page 38 Congratulations! Congratulations on your new Rugged Interactive product! Your customers are going to love this, and it is a great addition to your venue! If there is anything we can assist with or if you would be interested in information about any other Rugged Interactive products, then please do not hesitate to get in contact.
