TrailBlazer
Traverse
Installation and Instruction Manual
For models from February 2021 onwards
Rugged Interactive
Unit 1, Callywith Court,
Callywith Industrial Estate,
Bodmin, Cornwall, UK
PL31 2RQ
+44 (0) 1726 981 123
www.rugged-interactive.co.uk
hello@rugged-interactive.co.uk
Updated: 08/02/2021
© Rugged Interactive
2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TrailBlazer Traverse and is the answer not in the manual?

Questions and answers

Summary of Contents for Rugged Interactive TrailBlazer Traverse

  • Page 1 ® TrailBlazer Traverse Installation and Instruction Manual For models from February 2021 onwards Rugged Interactive Unit 1, Callywith Court, Callywith Industrial Estate, Bodmin, Cornwall, UK PL31 2RQ +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk Updated: 08/02/2021 © Rugged Interactive 2021...
  • Page 2: Table Of Contents

    Section 3 – Installation 3.1 Parts List 3.2 Tools and Components List 3.3 Installation Overview 3.4 Detailed Installation Section 4 – How to Use Section 5 – Programs Guide TrailBlazer Traverse System Specifications TrailBlazer Traverse Installation Checklist Next Steps © Rugged Interactive 2021...
  • Page 3: Section 1 - Ordering Process

    Installation manual purpose and limitations This manual is intended to provide guidance only, the installation of the Rugged Interactive product will be under your control. You will be responsible for making sure, upon completion of the installation, it is safe to use.
  • Page 4: Order And Installation Checklist

    1.2 - Order and Installation Checklist ☐ Contact the Rugged Interactive sales team or a partner / distributor to begin the process. Confirm the invoice and delivery address along with date required (lead time is at least 5 weeks), ☐...
  • Page 5: Ordering And Installation Timeline

    ® 1.3 – TrailBlazer Traverse Overview An interactive climbing challenge, the TrailBlazer Traverse could be the standout feature for your trampoline park. As well as being great fun, the TrailBlazer improves core strength, mental alertness, balance and agility. Players climb around the wall, scoring points by pressing the easy to hold grips as they light up.
  • Page 6: Getting Started

    If further information is required, please get in touch and we will be able to provide further information and guidance. 1.6 - Place Order To begin the order process with Rugged Interactive: Email: Sales@rugged-interactive.co.uk Or call the Sales Office:...
  • Page 7: Section 2 - Safety Guidelines

    Tidy back loose cables that could become a tripping hazard. § Ensure that the playing area is clear. § Immediately inform Rugged Interactive for maintenance advice if you have concerns. Don’ts: § Do not wear shoes with leather soles or high heels.
  • Page 8: In Play Safety Guidelines

    Make sure you have control before leaving the trampolines, obstacles or activity equipment. Don’ts: § No more than four active users on the equipment at any one time. ® © Rugged Interactive TrailBlazer Traverse – Section 2 - Safety Guidelines 2021...
  • Page 9 Maximum weight restriction per user is 18st/115kg. ® © Rugged Interactive TrailBlazer Traverse – Section 2 - Safety Guidelines...
  • Page 10: Section 3 - Installation

    +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk Section 3 - Installation 3.1 - Parts List Please check off the received parts for the installation and alert Rugged Interactive immediately if anything is missing. ☐ 12 x Wall Mouldings. * ☐...
  • Page 11: Tools And Components List

    Cordless drill – with torque adjuster to avoid over-tightening the screws. ☐ A set of No.2 Pozi bits. ☐ A set of screwdrivers. ☐ A set of Hex keys. ☐ Spirit level. ® © Rugged Interactive TrailBlazer Traverse – Section 2 - Installation 2021...
  • Page 12: Installation Overview

    3.3 - Installation Overview Below is an overview of the steps needed to install TrailBlazer Traverse. More detail for the process is provided in the following pages. Please read through ALL of this prior to beginning the installation and if you are in any doubt, contact Rugged Interactive.
  • Page 13: Detailed Installation

    (50 mm box minimum). Preferably, the plywood should be painted black prior to installation. § The TrailBlazer Traverse should be raised off the floor by at least 200mm. An 8”x 4” (c.200mm x 100mm) baton should be used below the mouldings to support the weight and gameplay. §...
  • Page 14 A waiting / spectating area positioned nearby is advised. § A leaderboard to go with each unit is highly recommended. IF YOU ARE IN ANY DOUBT, CALL RUGGED INTERACTIVE DIRECTLY ON +44 (0) 1726 833 882 ® © Rugged Interactive TrailBlazer Traverse –...
  • Page 15 Installation Installation Instructions 1. Prepare the area where the TrailBlazer Traverse is to be installed. It is recommended that the plywood wall it is to be mounted to is painted black or a dark colour. 2. The TrailBlazer Traverse should be raised off the floor by at least 200mm to accommodate matting and create a ‘step up’...
  • Page 16 12. Mount the control box in the required position (it is recommended that the control box is positioned to the top-left hand side of the TrailBlazer Traverse wall). Details how to mount the control box can be seen further on in this section.
  • Page 17 17. Use box trunking to tidy away and secure the cables along the top of the wall mouldings. Figure 3.4.4: A Typical TrailBlazer Traverse Installation Please note, the wall is raised 200mm to accommodate the matting. A baton is used to which is resting on the floor and attached to a structurally sound wall.
  • Page 18 ® Traverse Order and Installation Manual: Installation TrailBlazer Traverse Display / Score Box (HUB) Installation § Fix HUB using any suitable self-tapping or wood screws into the surface material. The HUB can be recessed to be flush with the surface or affixed on top of the foam-backed vinyl if necessary.
  • Page 19 HUB and relevant grip. connect to the correct connector on the Traverse wall. Note: The data and power ports will only feature on the SkyPods duo model. ® © Rugged Interactive TrailBlazer Traverse – Section 3 - Installation 2021...
  • Page 20 Retain all screws & washers. NOTES: Ensure CAT5 cable is not strained or trapped. Do not overtighten grip screws. Power on the TrailBlazer Climbing wall and check operation. Removing the Grips ® © Rugged Interactive TrailBlazer Traverse – Section 3 - Installation 2021...
  • Page 21: Section 4 - How To Use

    On power up, the TrailBlazer will sound a ‘laugh’ and will turn to its idle state. Initially the dot matrix will display the Hub Software Version Number for the TrailBlazer. The TrailBlazer Traverse Climb has four programs: 1. Cascade – 3 minutes 2.
  • Page 22 TrailBlazer Traverse Order and Installation Manual: FreeStyle TrailBlazer Traverse Trampoline The TrailBlazer Traverse Trampoline has two programs: 1. Cascade – 1 minute 2. Chaser X4 – 1 minute red pods shown in Figure 4.2 are QuickStart programs. Hit a QuickStart button to start the program.
  • Page 23: Section 5 - Programs Guide

    NOTE: At any time, if the CardioWall behaves unexpectedly during gameplay, wait for at least 30 seconds of inactivity for the unit to reset to its idle state. ® © Rugged Interactive TrailBlazer Traverse – Section 5 - Programs Guide...
  • Page 24 NOTE: At any time, if the CardioWall behaves unexpectedly during gameplay, wait for at least 30 seconds of inactivity for the unit to reset to its idle state. ® © Rugged Interactive TrailBlazer Traverse – Section 5 - Programs Guide...
  • Page 25 NOTE: At any time, if the CardioWall behaves unexpectedly during gameplay, wait for at least 30 seconds of inactivity for the unit to reset to its idle state. ® © Rugged Interactive TrailBlazer Traverse – Section 5 - Programs Guide...
  • Page 26 NOTE: At any time, if the CardioWall behaves unexpectedly during gameplay, wait for at least 1 minute of inactivity for the unit to reset to its idle state. ® © Rugged Interactive TrailBlazer Traverse – Section 5 - Programs Guide...
  • Page 27 Operating Environment: Indoors: keep dry and out of direct sunlight. Mount to a wall of a suitable construction. Area required clear in front of the TrailBlazer Traverse: depth of 1 m minimum. Optimum ambient temperature: 5°C to 30°C. Avoid extreme fluctuations of temperature.
  • Page 28 System Specifications 1090 Figure 1: Mounting Points (Dimensions in mm) Note: It is not recommended that these dimensions be used to form mounting points before installation. Figure 2: Panel Orientations ® © Rugged Interactive TrailBlazer Traverse - System Specifications 2021...
  • Page 29 Power Supply Specification for 5~9V) Features ‧  ‧  ‧  ‧  ‧  ‧  ‧  ‧   ‧  ‧  ‧ ℃ ‧ Ⅱ ‧  ‧  ‧  ‧   ...
  • Page 30 Power Supply Specification SPECIFICATION PRODUCT GSM60B12-P1J SAFETY MODEL NO. GSM60B12 DC VOLTAGE Note.2 RATED CURRENT CURRENT RANGE 0 ~ 5A RATED POWER (max.) OUTPUT RIPPLE & NOISE (max.) 100mVp-p Note.3 ±3.0% VOLTAGE TOLERANCE Note.4 ±1.0% LINE REGULATION Note.5 ±3.0% LOAD REGULATION SETUP, RISE TIME 1000ms, 30ms / 230VAC 1500ms, 30ms / 115VAC at full load...
  • Page 31 Power Supply Specification Derating Curve Static Characteristics (HORIZONTAL) ℃ AMBIENT TEMPERATURE ( ) INPUT VOLTAGE (VAC) 60Hz Mechanical Specification Case No. GSM60B Unit:mm ± U 2464 16AWG 1000 50mm for 5 ~ UL1185 16AWG 1500±50mm for 18 ~ 48V 31.5 POWER LED ±...
  • Page 32 Check 2: Plug into a mains socket and power up. ☐ All pods light up. ☐ Text appears on the hub display and is as expected. E.g. TrailBlazer Traverse. ☐ Sound volume is at a suitable level*. Check 3: Select Cascade via Quick Start.
  • Page 33 ☐ Instruction / training carried out by an appropriate instructor to all new users. If anything unexpected occurs or problems persist after troubleshooting, call Rugged Interactive directly on +44 (0) 1726 833 882. * The volume can be adjusted on the scorebox. The volume control (a black dial) is located on the bottom edge of the scorebox between the speakers.
  • Page 34 Next Steps Train team members Train your team members on how to use TrailBlazer Traverse, having knowledge of the gameplay will help them encourage users. Inspire them to cheer and celebrate with the customers when they achieve high scores.
  • Page 35 Congratulations! Congratulations on your new Rugged Interactive product! Your customers are going to love this, and it is a great addition to your venue! If there is anything we can assist with or if you would be interested in information about any other Rugged Interactive products, then please do not hesitate to get in contact.
