SkyClimb
Order and Installation Manual
For models from January 2021 onwards
Rugged Interactive
Unit 1, Callywith Court
Callywith Industrial Estate, Bodmin
Cornwall, UK
PL231 2RQ
+44 (0) 1726 981 123
www.rugged-interactive.co.uk
hello@rugged-interactive.co.uk
Updated 17/02/2021
© Rugged Interactive
2021
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Rugged Interactive SkyClimb
Summary of Contents for Rugged Interactive SkyClimb
- Page 1 SkyClimb Order and Installation Manual For models from January 2021 onwards Rugged Interactive Unit 1, Callywith Court Callywith Industrial Estate, Bodmin Cornwall, UK PL231 2RQ +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk Updated 17/02/2021 © Rugged Interactive 2021...
-
Page 2: Table Of Contents
Section 3 – Installation 3.1 Parts List 3.2 Tools and Components List 3.3 Installation Overview 3.4 Detailed Installation Section 4 – How to Use Section 5 – Programs Guide SkyClimb System Specifications SkyClimb Installation Checklist Next Steps © Rugged Interactive 2021... -
Page 3: Section 1 - Ordering Process
Installation manual purpose and limitations This manual is intended to provide guidance only, the installation of the Rugged Interactive product will be under your control. You will be responsible for making sure, upon completion of the installation, it is safe to use. -
Page 4: Order And Installation Checklist
1.2 - Order and Installation Checklist ☐ Contact the Rugged Interactive sales team or a partner / distributor to begin the process. Confirm the invoice and delivery address along with date required (lead time is at least 5 weeks), ☐... -
Page 5: Ordering And Installation Timeline
1.3 - SkyClimb Overview Add an exciting, interactive element to your climbing wall. SkyClimb is a versatile test of agility and climbing ability, encouraging competition and the motivation to climb for longer. Players score points with every correct hit, competing individually to build a huge score or directly against another player (SkyClimb Duo). -
Page 6: Getting Started
If further information is required, please get in touch and we will be able to provide further information and guidance. 1.6 - Place Order To begin the order process with Rugged Interactive: Email: Sales@rugged-interactive.co.uk Or call the Sales Office:... -
Page 7: Section 2 - Safety Guidelines
Tidy back loose cables that could become a tripping hazard. § Ensure that the playing area is clear. § Immediately inform Rugged Interactive for maintenance advice if you have concerns. Don’ts: § Do not wear shoes with leather soles or high heels. -
Page 8: In Play Safety Guidelines
SkyClimb Installation and Instruction Manual: Safety Guidelines 2.2 In Play Safety Guidelines Please ensure you read the following points before using the equipment: This activity can be great fun, but it can also be dangerous. There is a risk of serious injury if care is not taken when using the equipment. - Page 9 SkyClimb Installation and Instruction Manual: Safety Guidelines Don’ts: § No more than one active user on the equipment at any one time. § Do not attempt to use any of the equipment without undertaking instruction / training carried out by an appropriate instructor.
-
Page 10: Section 3 - Installation
2 x DATA to NUC cables Grey 10m (RJ45 to USB). ☐ ☐ 1 x Set of leaderboard connection cables. * Please note, quantities are for a single SkyClimb, if a SkyClimb Duo has been ordered, double these quantities. © Rugged Interactive SkyClimb –... -
Page 11: Tools And Components List
SkyClimb Order and Installation Manual: Installation 3.2 - Tools and Components List Arrange the necessary tools and the team to install the product. Ladder. Jigsaw. ☐ Hole saw. ☐ Industrial vacuum cleaner. ☐ Dustpan and brush. ☐ SDS impact drill. -
Page 12: Installation Overview
3.3 - Installation Overview Below is an overview of the steps needed to install SkyClimb. More detail for the process is provided in the following pages. Please read through ALL of this prior to beginning the installation and if you are in any doubt, contact Rugged Interactive. -
Page 13: Detailed Installation
Installation Guidelines: § Complete the Site Survey form prior to delivery and/or installation. § Send a completed Installation Checklist after any installation to Rugged Interactive. § A typical installation should take 2 people about 3 hours. § No obstructions or protrusions in the installation area: e.g. skirting boards, pipes, cables and wiring conduits. - Page 14 Instruction / training carried out by an appropriate instructor to all new users. § A waiting / spectating area positioned nearby is advised. IF YOU ARE IN ANY DOUBT, CALL RUGGED INTERACTIVE DIRECTLY ON +44 (0) 1726 833 882. © Rugged Interactive SkyClimb –...
- Page 15 SkyClimb Order and Installation Manual: Installation Display / Score Box (HUB) Installation § Fix HUB using any suitable self-tapping or wood screws into the surface material. The HUB can be recessed to be flush with the surface or affixed on top if necessary.
- Page 16 SkyClimb Order and Installation Manual: Installation SkyClimb Installation Pods: Pods should be mounted onto a wall using the three 6 mm mounting points on each pod using the supplied wood screws. Figure 3.4.1 shows a typical Pod installation. Plywood Base Layer (if applicable)
- Page 17 SkyClimb Order and Installation Manual: Installation Pods to Score Box (HUB) Installation Notes: § All supplied CAT5 cables will be numbered. Attach correctly numbered cable to the designated Hanging cable exiting the rear of the HUB. Pods 2 and 3 are the quick start buttons. These pods should be located in a suitable, easy to reach §...
- Page 18 SkyClimb Order and Installation Manual: Installation Multiplayer Launch Box (MPL) Installation This section is only relevant if installing a SkyClimb Duo WITHOUT a leader board upgrade. The MPL will not be supplied unless a Standard SkyClimb duo has been ordered. §...
- Page 19 SkyClimb Order and Installation Manual: Installation Optional: If you have purchased the Large Display Leaderboard Upgrade, the following steps will apply. Large Display Screen Installation § The screen should be installed in suitable a position, these screens will display the in-game scores.
- Page 20 SkyClimb Order and Installation Manual: Installation Touchscreen Installation § The touchscreen is used to start two player games and to add names to the leaderboard. § The touchscreen should be positioned in an easy to reach location. § The touchscreen must be within 3 meters of the control box.
- Page 21 Note: Number of Hubs to be connected will depend on order. 49” Screen Figure 3.4.2: Typical SkyClimb Duo Display Installation Note: If a single SkyClimb system is ordered there will only be one hub in the above. SkyClimb – Section 3 - Installation ©...
- Page 22 Touchscreen for 2-player game launch and leader board data entry. Figure 3.4.3: Typical SkyClimb Duo with Leaderboard Upgrade Installation Note, the touchscreen must be within 3m of the NUC (Control Box) and the display screen within 5m of the NUC.
-
Page 23: Section 4 - How To Use
Section 4 - How to Use On power up, SkyClimb will sound a ‘laugh’ and will turn to its idle state. Initially the dot matrix on the display box will display the Hub Software Version Number for the SkyClimb. -
Page 24: Section 5 - Programs Guide
+1 point for each pod hit Duration: 1 minute NOTE: At any time, if SkyClimb behaves unexpectedly during gameplay, wait for at least 20 seconds for the unit to reset to its idle state. SkyClimb – Section 5 - Programs Guide ©... - Page 25 +1 point for each red pod Duration: 1 minute NOTE: At any time, if the SkyClimb behaves unexpectedly during gameplay, wait for at least 20 seconds for the unit to reset to its idle state. © Rugged Interactive SkyClimb –...
- Page 26 Rugged Interactive Unit 1, Callywith Court, Callywith Industrial Estate, Bodmin, Cornwall, UK PL31 2RQ +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk SkyClimb System Specifications Dimensions and Weights: Approx. Shipment Details Fully Assembled Details Size (mm) Weight Size (mm) Weight Pod (single unit) 205 Ø...
- Page 27 SkyClimb Order and Installation Manual: System Specifications 120° Figure 1: Pod Mounting Points (Dimensions in mm) Figure 2: Pod Dimensions (Dimensions in mm) © Rugged Interactive SkyClimb - System Specifications 2021...
- Page 28 Power Supply Specification for 5~9V) Features ‧ ‧ ‧ ‧ ‧ ‧ ‧ ‧ ‧ ‧ ‧ ℃ ‧ Ⅱ ‧ ‧ ‧ ‧ ...
- Page 29 Power Supply Specification SPECIFICATION PRODUCT GSM60B12-P1J SAFETY MODEL NO. GSM60B12 DC VOLTAGE Note.2 RATED CURRENT CURRENT RANGE 0 ~ 5A RATED POWER (max.) OUTPUT RIPPLE & NOISE (max.) 100mVp-p Note.3 ±3.0% VOLTAGE TOLERANCE Note.4 ±1.0% LINE REGULATION Note.5 ±3.0% LOAD REGULATION SETUP, RISE TIME 1000ms, 30ms / 230VAC 1500ms, 30ms / 115VAC at full load...
- Page 30 Power Supply Specification Derating Curve Static Characteristics (HORIZONTAL) ℃ AMBIENT TEMPERATURE ( ) INPUT VOLTAGE (VAC) 60Hz Mechanical Specification Case No. GSM60B Unit:mm ± U 2464 16AWG 1000 50mm for 5 ~ UL1185 16AWG 1500±50mm for 18 ~ 48V 31.5 POWER LED ±...
- Page 31 Protective plastic sheet from each pod removed. Check 2: Power up. ☐ All pods light up. ☐ Text appears on the hub display and is as expected. E.g. SkyClimb. ☐ Sound volume is at a suitable level*. Large display screen is displaying graphics. (if included) ☐...
- Page 32 SkyClimb Order and Installation Manual: Installation Checklist Check 4: Select ClearOut (Speed) via the MPL or Touchscreen (SkyClimb Duo only). ☐ Program counts down from 3 and begins on both units simultaneously. ☐ All pods active and operational. ☐ Check all pods for colours: red, green, blue.
- Page 33 Next Steps Train team members Train your team members on how to use SkyClimb, having knowledge of the gameplay will help them encourage users. Inspire them to cheer and celebrate with the customers when they achieve high scores. Maintenance General care and maintenance procedures for your Rugged Interactive product.
- Page 34 Congratulations! Congratulations on your new Rugged Interactive product! Your customers are going to love this, and it is a great addition to your venue! If there is anything we can assist with or if you would be interested in information about any other Rugged Interactive products, then please do not hesitate to get in contact.
