Rugged Interactive CardioWall Portrait Order And Installation Manual

Hide thumbs Also See for CardioWall Portrait:
Table of Contents

Advertisement

Quick Links

Download this manual
®
CardioWall
Portrait
Order and Installation Manual
For models from October 2023 onwards
Rugged Interactive
Unit 1, Callywith Court
Callywith Industrial Estate, Bodmin
Cornwall, UK
PL231 2RQ
+44 (0) 1726 981 123
www.rugged-interactive.com
hello@rugged-interactive.com
Issued: 25/10/2023
© Rugged Interactive
2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CardioWall Portrait and is the answer not in the manual?

Questions and answers

Related Manuals for Rugged Interactive CardioWall Portrait

Summary of Contents for Rugged Interactive CardioWall Portrait

  • Page 1 ® CardioWall Portrait Order and Installation Manual For models from October 2023 onwards Rugged Interactive Unit 1, Callywith Court Callywith Industrial Estate, Bodmin Cornwall, UK PL231 2RQ +44 (0) 1726 981 123 www.rugged-interactive.com hello@rugged-interactive.com Issued: 25/10/2023 © Rugged Interactive 2023...

  • Page 2: Table Of Contents

    Section 3 – Installation 3.1 Parts List 3.2 Tools and Components List 3.3 Installation Overview 3.4 Detailed Installation Section 4 – How to Use Section 5 – Programs Guide CardioWall Portrait System Specifications CardioWall Portrait Installation Checklist Next Steps © Rugged Interactive 2023...

  • Page 3: Section 1 - Ordering Process

    Installation manual purpose and limitations This manual is intended to provide guidance only, the installation of the Rugged Interactive product will be under your control. You will be responsible for making sure, upon completion of the installation, it is safe to use.

  • Page 4: Order And Installation Checklist

    1.2 - Order and Installation Checklist ☐ Contact the Rugged Interactive sales team or a partner / distributor to begin the process. Confirm the invoice and delivery address along with date required (lead time is at least 5 weeks), ☐...

  • Page 5: Ordering And Installation Timeline

    The CardioWall can stimulate a huge range of functional exercises and motor skills. The CardioWall Portrait features multiple game modes. A ‘blank canvas’ for PT’s to create their own routines for clients. Every routine is a game, challenging users to beat their previous best score, their friends or the leader board.

  • Page 6: Getting Started

    If further information is required, please get in touch and we will be able to provide further information and guidance. 1.6 - Place Order To begin the order process with Rugged Interactive: Email: Sales@rugged-interactive.co.uk Or call the Sales Office:...

  • Page 7: Section 2 - Safety Guidelines

    Tidy back loose cables that could become a tripping hazard. § Ensure that the playing area is clear. § Immediately inform Rugged Interactive for maintenance advice if you have concerns. Don’ts: § Do not wear shoes with leather soles or high heels.

  • Page 8: In Play Safety Guidelines

    (such as buckles, studs, toggles or alike). § Do not wear shoes with leather soles, high heels, sandals, boots or bare feet. § No food, drink or chewing gum during participation. CardioWallâ Portrait – Section 2 - Safety Guidelines © Rugged Interactive 2023...
  • Page 9 Use of this equipment is physically demanding: this is a high-impact, full body activity which requires intense focus, awareness of your body’s strengths and limitations, awareness of the environment around you and extreme caution. CardioWallâ Portrait – Section 2 - Safety Guidelines © Rugged Interactive 2023...

  • Page 10: Section 3 - Installation

    +44 (0) 1726 981 123 www.rugged-interactive.com hello@rugged-interactive.com Section 3 - Installation 3.1 - Parts List Please check off the received parts for the installation and alert Rugged Interactive immediately if anything is missing. ☐ 1 x Portrait Wall (two halves). ☐...

  • Page 11: Installation Overview

    3.3 - Installation Overview Below is an overview of the steps needed to install CardioWall Portrait. More detail for the process is provided in the following pages. Please read through ALL of this prior to beginning the installation and if you are in any doubt, contact Rugged Interactive.

  • Page 12: Detailed Installation

    Installation Guidelines: § Please complete the Site Survey form prior to delivery and/or installation. § Please send a completed Installation Checklist after any installation to Rugged Interactive. § A typical installation should take 2 people about 2 hours. § No obstructions or protrusions in the installation area: e.g. skirting boards, pipes, cables and wiring conduits.
  • Page 13 A waiting / spectating area positioned nearby is advised. § A leaderboard to go with each unit is highly recommended. § IF YOU ARE IN ANY DOUBT, CALL RUGGED INTERACTIVE DIRECTLY ON +44 (0) 1726 833 882 © Rugged Interactive CardioWallâ Portrait – Section 3 - Installation...
  • Page 14 CardioWall Portrait Installation Remove pods x 8. Retain screws, washers and pods. Remove the graphics panels from the large moulding that contains the hub (i.e. the scoring screen). Remove all the outside screws and washers. Retain screws and washers and store graphics panel in a safe place.
  • Page 15 2 people required: one to hold the main body in place; one to clearly mark holes x 5. Drill holes and insert mountings x 5. © Rugged Interactive CardioWallâ Portrait – Section 3 - Installation 2023...
  • Page 16 Tighten fixings by hand x 5. Ensure CAT5 cables are not trapped or pinched anywhere behind the lower moulding of the CardioWall. Clearly mark hole x 5. © Rugged Interactive CardioWallâ Portrait – Section 3 - Installation 2023...
  • Page 17 Drill holes and insert mountings x 5. Feed lower cables through slot. © Rugged Interactive CardioWallâ Portrait – Section 3 - Installation 2023...
  • Page 18 Ensure all cables are not trapped or pinched between the wall sections. Tighten fixings by hand x 5. Tighten fixings with tool x 10. © Rugged Interactive CardioWallâ Portrait – Section 3 - Installation 2023...
  • Page 19 PCB. Connect the power cable in the centre pod opening. Reposition the graphics panels for the top moulding. Use the screws and washers retained from earlier. © Rugged Interactive CardioWallâ Portrait – Section 3 - Installation 2023...
  • Page 20 Reinstall pods x 9. Ensure cable is not trapped when replacing pod. © Rugged Interactive CardioWallâ Portrait – Section 3 - Installation 2023...
  • Page 21 Rugged Interactive Unit 1, Callywith Court, Callywith Gate Industrial Estate, Bodmin, Cornwall, UK PL31 2RQ CardioWall – Pod Removal and Installation Removing the Pods Read this manual before removing or installing any pods. Do not worry which order the pods come off in. They can be refitted in any order.

  • Page 22: Section 4 - How To Use

    4.2.2 Menu Section 4 - 9 4.2.3 5 Pod Menu Section 4 - 12 4.3.4 SoundBoard Section 4 - 13 4.2.5 End of Program Section 4 - 14 CardioWallâ Portrait – Section 4 - How to Use © Rugged Interactive 2023...
  • Page 23 [Figure 4.1]. Menu ClearOut 1 minute Dot Matrix 5 Pod Menu ClusterShot 1 minute Chaser 1 minute CardioBeat LowFive Figure 4.1: CardioWall Idle State CardioWallâ Portrait – Section 4 – How to Use © Rugged Interactive 2023...
  • Page 24 ClearOut, ClusterShot or Chaser respectively [Figure 4.2]. Dot Matrix Return to idle state ClusterShot ClearOut Chaser Figure 4.2: CardioWall Menu CardioWallâ Portrait – Section 4 – How to Use © Rugged Interactive 2023...
  • Page 25 The difficulty level will be shown on the time display. NOTE: For ClearOut and Chaser programs, the select difficulty level option is unavailable as there is only one level setting available. CardioWallâ Portrait – Section 4 – How to Use © Rugged Interactive 2023...
  • Page 26 Figure 4.5: CardioWall Lowest Pod Selection NOTE: At any time, if the CardioWall behaves unexpectedly, wait for at least 20 seconds for the unit to reset to its idle state. CardioWallâ Portrait – Section 4 – How to Use © Rugged Interactive 2023...
  • Page 27 CardioWall’s idle state. NOTE: At any time, if the CardioWall behaves unexpectedly, wait for at least 20 seconds for the unit to reset to its idle state. CardioWallâ Portrait – Section 4 – How to Use © Rugged Interactive 2023...
  • Page 28 Figure 4.7: “Would you like to play again?” NOTE: At any time, if the CardioWall behaves unexpectedly, wait for at least 20 seconds for the unit to reset to its idle state. CardioWallâ Portrait – Section 4 – How to Use © Rugged Interactive 2023...
  • Page 29 [Figure 4.8]. Menu ClearOut 1 minute 5 Pod Menu ClusterShot 1 minute Chaser 1 minute SoundBoard LowFive Figure 4.8: CardioWall Idle State CardioWallâ Portrait – Section 4 – How to Use © Rugged Interactive 2023...
  • Page 30 ClearOut, ClusterShot or Chaser respectively [Figure 4.9]. Dot Matrix Return to idle state ClusterShot ClearOut Chaser Figure 4.9: CardioWall Menu CardioWallâ Portrait – Section 4 – How to Use © Rugged Interactive 2023...
  • Page 31 The difficulty level will be shown on the time display. NOTE: For ClearOut and Chaser programs, the select difficulty level option is unavailable as there is only one level setting available. CardioWallâ Portrait – Section 4 – How to Use © Rugged Interactive 2023...
  • Page 32 Figure 4.12: CardioWall Lowest Pod Selection NOTE: At any time, if the CardioWall behaves unexpectedly, wait for at least 30 seconds for the unit to reset to its idle state. CardioWallâ Portrait – Section 4 – How to Use © Rugged Interactive 2023...
  • Page 33 CardioWall’s idle state. NOTE: At any time, if the CardioWall behaves unexpectedly, wait for at least 30 seconds for the unit to reset to its idle state. CardioWallâ Portrait – Section 4 – How to Use © Rugged Interactive 2023...
  • Page 34 Figure 4.14: CardioWall SoundBoard NOTE: At any time, if the CardioWall behaves unexpectedly, wait for at least 30 seconds for the unit to reset to its idle state. CardioWallâ Portrait – Section 4 – How to Use © Rugged Interactive 2023...
  • Page 35 Figure 4.15: “Would you like to play again?” NOTE: At any time, if the CardioWall behaves unexpectedly, wait for at least 30 seconds for the unit to reset to its idle state. CardioWallâ Portrait – Section 4 – How to Use © Rugged Interactive 2023...

  • Page 36: Section 5 - Programs Guide

    For gameplay greater than or equal to 10 minutes, wait for at least 2 minutes for the unit to reset to its idle state. This longer time-out period is designed to allow multiplayer circuit training. CardioWallâ Portrait – Section 5 - Programs Guide © Rugged Interactive 2023...
  • Page 37 For gameplay greater than or equal to 10 minutes, wait for at least 2 minutes for the unit to reset to its idle state. This longer time-out period is designed to allow multiplayer circuit training. CardioWallâ Portrait – Section 5 - Programs Guide © Rugged Interactive 2023...
  • Page 38 For gameplay greater than or equal to 10 minutes, wait for at least 2 minutes for the unit to reset to its idle state. This longer time-out period is designed to allow multiplayer circuit training. CardioWallâ Portrait – Section 5 - Programs Guide © Rugged Interactive 2023...
  • Page 39 Level increases by 0.1 point for each pod hit e.g. L7.2 NOTE: At any time, if the CardioWall behaves unexpectedly, wait for the program to end and for the unit to reset to its idle state. CardioWallâ Portrait – Section 5 - Programs Guide © Rugged Interactive 2023...
  • Page 40 1 minute NOTE: At any time, if the CardioWall behaves unexpectedly during gameplay, wait for at least 30 seconds for the unit to reset to its idle state. CardioWallâ Portrait – Section 5 - Programs Guide © Rugged Interactive 2023...
  • Page 41 3 minutes NOTE: At any time, if the CardioWall behaves unexpectedly during gameplay, wait for at least 30 seconds for the unit to reset to its idle state. CardioWallâ Portrait – Section 5 - Programs Guide © Rugged Interactive 2023...
  • Page 42 +1 point for each pod hit NOTE: At any time, if the CardioWall behaves unexpectedly during gameplay, wait for at least 30 seconds for the unit to reset to its idle state. CardioWallâ Portrait – Section 5 - Programs Guide © Rugged Interactive 2023...
  • Page 43 Rugged Interactive Unit 1, Callywith Court, Callywith Industrial Estate, Bodmin, Cornwall, UK PL31 2RQ +44 (0) 1726 981 123 www.rugged-interactive.com hello@rugged-interactive.com CardioWall Portrait System Specifications Dimensions and Weights: Approx. Shipment Details Fully Assembled Details Size (mm) Weight Size (mm) Weight...
  • Page 44 CardioWall â Portrait Order and Installation Manual: System Specifications 1220 Figure 1: CardioWall Portrait mounting points (Dimensions in mm) CardioWallâ Portrait - © Rugged Interactive 2023 System Specifications...
  • Page 45 Power Supply Specification for 5~9V) Features ‧  ‧  ‧  ‧  ‧  ‧  ‧  ‧   ‧  ‧  ‧ ℃ ‧ Ⅱ ‧  ‧  ‧  ‧   ...
  • Page 46 Power Supply Specification SPECIFICATION PRODUCT GSM60B12-P1J SAFETY MODEL NO. GSM60B12 DC VOLTAGE Note.2 RATED CURRENT CURRENT RANGE 0 ~ 5A RATED POWER (max.) OUTPUT RIPPLE & NOISE (max.) 100mVp-p Note.3 ±3.0% VOLTAGE TOLERANCE Note.4 ±1.0% LINE REGULATION Note.5 ±3.0% LOAD REGULATION SETUP, RISE TIME 1000ms, 30ms / 230VAC 1500ms, 30ms / 115VAC at full load...
  • Page 47 Power Supply Specification Derating Curve Static Characteristics (HORIZONTAL) ℃ AMBIENT TEMPERATURE ( ) INPUT VOLTAGE (VAC) 60Hz Mechanical Specification Case No. GSM60B Unit:mm ± U 2464 16AWG 1000 50mm for 5 ~ UL1185 16AWG 1500±50mm for 18 ~ 48V 31.5 POWER LED ±...
  • Page 48 PL31 2RQ +44 (0) 1726 981 123 www.rugged-interactive.com hello@rugged-interactive.com CardioWall Portrait Installation Checklist Please complete this checklist after any installation: Check 1: Pre-power up checks. Equipment is stable, secure and (if applicable) mounted to a wall of a suitable construction ☐...
  • Page 49 ☐ Instruction / training carried out by an appropriate instructor to all new users. If anything unexpected occurs or problems persist after troubleshooting, call Rugged Interactive directly on +44 (0) 1726 833 882. * If no external volume control is provided (usual for most CardioWalls), the volume can be adjusted on the main hub.
  • Page 50 Next Steps Train team members Train your team members on how to use CardioWall Portrait, having knowledge of the gameplay will help them encourage users. Inspire them to cheer and celebrate with the users when they achieve high scores. Maintenance General care and maintenance procedures for your Rugged Interactive product.
  • Page 51 Congratulations! Congratulations on your new Rugged Interactive product! Your customers are going to love this, and it is a great addition to your venue! If there is anything we can assist with or if you would be interested in information about any other Rugged Interactive products, then please do not hesitate to get in contact.
