BattleBaskets
Order and Installation Manual
For models from August 2021 onwards
Rugged Interactive
Unit 1, Callywith Court
Callywith Industrial Estate , Bodmin
Cornwall, UK
PL231 2RQ
+44 (0) 1726 981 123
www.rugged-interactive.co.uk
hello@rugged-interactive.co.uk
Updated: 24/11/2021
© Rugged Interactive
2021
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Rugged Interactive BattleBaskets
Summary of Contents for Rugged Interactive BattleBaskets
- Page 1 BattleBaskets Order and Installation Manual For models from August 2021 onwards Rugged Interactive Unit 1, Callywith Court Callywith Industrial Estate , Bodmin Cornwall, UK PL231 2RQ +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk Updated: 24/11/2021 © Rugged Interactive 2021...
-
Page 2: Table Of Contents
Section 3 – Installation 3.1 Parts List 3.2 Tools and Components List 3.3 Installation Overview 3.4 Detailed Installation Section 4 – How to Use Section 5 – Programs Guide BattleBaskets System Specifications BattleBaskets Installation Checklist Next Steps © Rugged Interactive 2021... -
Page 3: Section 1 - Ordering Process
Installation manual purpose and limitations This manual is intended to provide guidance only, the installation of the Rugged Interactive product will be under your control. You will be responsible for making sure, upon completion of the installation, it is safe to use. -
Page 4: Order And Installation Checklist
1.2 - Order and Installation Checklist ☐ Contact the Rugged Interactive sales team or a partner / distributor to begin the process. Confirm the invoice and delivery address along with date required (lead time is at least 5 weeks), ☐... -
Page 5: Ordering And Installation Timeline
An interactive solution for your Basketball hoops. Perfect for individuals to build the highest score they can within the time limit or for competing against friends to see who can achieve the biggest score. A brightly lit scoreboard that will flash and make sounds when a basket is scored. BattleBaskets brings Basketball to life. -
Page 6: Getting Started
If further information is required, please get in touch and we will be able to provide further information and guidance. 1.6 - Place Order To begin the order process with Rugged Interactive: Email: Sales@rugged-interactive.co.uk Or call the Sales Office:... -
Page 7: Section 2 - Safety Guidelines
Tidy back loose cables that could become a tripping hazard. § § Ensure that the playing area is clear. § Immediately inform Rugged Interactive for maintenance advice if you have concerns. Don’ts: Do not wear shoes with leather soles or high heels. § §... -
Page 8: In Play Safety Guidelines
BattleBaskets Installation and Instruction Manual: Safety Guidelines 2.2 In Play Safety Guidelines Please ensure you read the following points before using the equipment: This activity can be great fun, but it can also be dangerous. There is a risk of serious injury if care is not taken when using the equipment. - Page 9 BattleBaskets Installation and Instruction Manual: Safety Guidelines Don’ts: § No more than one active user on a single trampoline at any one time. § Do not attempt to use any of the equipment without undertaking instruction / training carried out by an appropriate instructor.
-
Page 10: Section 3 - Installation
+44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk Section 3 - Installation 3.1 - Parts List Please check off the received parts for the installation and alert Rugged Interactive immediately if anything is missing. ☐ Top light display unit (optional). ☐... -
Page 11: Tools And Components List
BattleBaskets Order and Installation Manual: Installation 3.2 - Tools and Components List Arrange the necessary tools and the team to install the product. Ladder. ☐ ☐ Socket set. ☐ Industrial vacuum cleaner. ☐ Dustpan and brush. ☐ Spanner set. ☐... -
Page 12: Installation Overview
3.3 - Installation Overview Below is an overview of the steps needed to install BattleBaskets. More detail for the process is provided in the following pages. Please read through ALL of this prior to beginning the installation and if you are in any doubt, contact Rugged Interactive. -
Page 13: Detailed Installation
Installation Guidelines: § Complete the Site Survey form prior to delivery and/or installation. § Send a completed Installation Checklist after any installation to Rugged Interactive. A typical installation should take 4 hours. § § No obstructions or protrusions in the installation area: e.g., skirting boards, pipes, cables and wiring conduits. - Page 14 Instruction / training carried out by an appropriate instructor to all new users. § A waiting / spectating area positioned nearby is advised. IF YOU ARE IN ANY DOUBT, CALL RUGGED INTERACTIVE DIRECTLY ON +44 (0) 1726 833 882. BattleBaskets – Section 3 - Installation ©...
- Page 15 BattleBaskets Order and Installation Manual: Installation BattleBaskets Score Box Installation § The score box requires one power socket and controls the system. § The score box can be centrally mounted to the post, side mounted, or wall mounted. § Fix the score box using the supplied mount for the required installation method.
- Page 16 BattleBaskets Order and Installation Manual: Installation Centre Post Mounted Attach the centre post bracket to the score box Hold the main body in place, and ensure it is level. with the supplied screws (3 per corner). Use supplied bolts, nuts, and washers to mount The box is clamped around the post.
- Page 17 BattleBaskets Order and Installation Manual: Installation Side Post Mounted Attach the side post bracket to the score box Hold the main body in place, and ensure it is level. with the supplied screws (3 per corner). Use supplied bolts, nuts, and washers to mount The box is clamped around the post.
- Page 18 BattleBaskets Order and Installation Manual: Installation BattleBaskets Sensor § The sensor is to be mounted ABOVE the hoop. § The sensor is connected to the score box via CAT5 cables. The sensor will be attached to a mounting plate. Select the best fixings for the installation.
- Page 19 BattleBaskets Order and Installation Manual: Installation Foam can be added but ensure no foam is obstructing the sensor. Note: Cables exit from the rear of the box. Make sure everything is tight and secure and that no cables are trapped.
- Page 20 BattleBaskets Order and Installation Manual: Installation Layout § Layout of BattleBaskets is at the discretion of the installer / park constructor § Score boxes should be mounted outside of the gameplay area but in an easily visible location. Figure: A typical layout of BattleBaskets.
-
Page 21: Section 4 - How To Use
Scoring one point per successful basket, build the highest score within the game time as possible. The game will end on with a klaxon sounding. NOTE: At any time, if BattleBaskets behaves unexpectedly, wait for at least 30 seconds for the unit to reset to its idle state. -
Page 22: Section 5 - Programs Guide
+1 point for each successful basket. Duration: 1 minute. NOTE: At any time, if BattleBaskets behaves unexpectedly during gameplay, wait for at least 20 seconds for the unit to reset to its idle state. BattleBaskets – Section 5 - Programs Guide ©... - Page 23 Rugged Interactive Unit 1, Callywith Court, Callywith Industrial Estate, Bodmin, Cornwall, UK PL31 2RQ +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk BattleBaskets System Specifications Dimensions and Weights: Approx. Shipment Details Fully Assembled Details Size (mm) Weight Size (mm) Weight Sensor (Including mount)
- Page 24 BattleBaskets Order and Installation Manual: System Specifications Mounting Points and Dimensions: Graphics Support Struts Clamp Adjustable Figure 1: Side view of the optional top mount. All dimensions in mm. BattleBaskets - System Specifications © Rugged Interactive 2021...
- Page 25 Power Supply Specification for 5~9V) Features ‧ ‧ ‧ ‧ ‧ ‧ ‧ ‧ ‧ ‧ ‧ ℃ ‧ Ⅱ ‧ ‧ ‧ ‧ ...
- Page 26 Power Supply Specification SPECIFICATION PRODUCT GSM60B12-P1J SAFETY MODEL NO. GSM60B12 DC VOLTAGE Note.2 RATED CURRENT CURRENT RANGE 0 ~ 5A RATED POWER (max.) OUTPUT RIPPLE & NOISE (max.) 100mVp-p Note.3 ±3.0% VOLTAGE TOLERANCE Note.4 ±1.0% LINE REGULATION Note.5 ±3.0% LOAD REGULATION SETUP, RISE TIME 1000ms, 30ms / 230VAC 1500ms, 30ms / 115VAC at full load...
- Page 27 Power Supply Specification Derating Curve Static Characteristics (HORIZONTAL) ℃ AMBIENT TEMPERATURE ( ) INPUT VOLTAGE (VAC) 60Hz Mechanical Specification Case No. GSM60B Unit:mm ± U 2464 16AWG 1000 50mm for 5 ~ UL1185 16AWG 1500±50mm for 18 ~ 48V 31.5 POWER LED ±...
- Page 28 Cornwall, UK PL31 2RQ +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk BattleBaskets Installation Checklist Please complete this checklist after any installation: Check 1: Pre-power up checks. ☐ All parts mounted to a construction capable of supporting its weight and gameplay.
- Page 29 Play area is clear. ☐ Instruction / training carried out by an appropriate instructor to all new users. If anything unexpected occurs or problems persist after troubleshooting, call Rugged Interactive directly on +44 (0) 1726 833 882. BattleBaskets - Installation Checklist ©...
- Page 30 Next Steps Train team members Train your team members on how to use BattleBaskets, having knowledge of the gameplay will help them encourage users. Inspire them to cheer and celebrate with the customers when they achieve high scores. Maintenance General care and maintenance procedures for your Rugged Interactive product.
- Page 31 Congratulations! Congratulations on your new Rugged Interactive product! Your customers are going to love this, and it is a great addition to your venue! If there is anything we can assist with or if you would be interested in information about any other Rugged Interactive products, then please do not hesitate to get in contact.
