- Page 1 TrailBlazer ® Traverse HEX Installation and Instruction Manual For models from August 2017 onwards Rugged Interactive Unit 1, Callywith Court, Callywith Industrial Estate, Bodmin, Cornwall, UK PL31 2RQ +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk © Rugged Interactive 2019...
-
Page 2: Table Of Contents
3.1 Parts List 3.2 Tools and Components List 3.3 Installation Overview 3.4 Detailed Installation Section 4 – How to Use Section 5 – Programs Guide TrailBlazer Traverse HEX System Specifications TrailBlazer Traverse HEX Installation Checklist Next Steps © Rugged Interactive 2019... -
Page 3: Section 1 - Ordering Process
Installation manual purpose and limitations This manual is intended to provide guidance only, the installation of the Rugged Interactive product will be under your control. You will be responsible for making sure, upon completion of the installation, it is safe to use. -
Page 4: Order And Installation Checklist
1.2 - Order and Installation Checklist ☐ Contact the Rugged Interactive sales team or a partner / distributor to begin the process. Confirm the invoice and delivery address along with date required (lead time is at least 5 weeks), ☐... -
Page 5: Ordering And Installation Timeline
Lead time will also be affected by graphics guidelines, approval and payment delays. TrailBlazer ® Traverse HEX – Section 1 - Ordering Process © Rugged Interactive 2019... -
Page 6: Getting Started
If further information is required, please get in touch and we will be able to provide further information and guidance. 1.6 - Place Order Key Contacts at Rugged Interactive: Sales Office Address: Commercial Director – Harry Stevens Rugged Interactive, Harry@rugged-interactive.co.uk... -
Page 7: Section 2 - Safety Guidelines
Tidy back loose cables that could become a tripping hazard. ▪ Ensure that the playing area is clear. ▪ Immediately inform Rugged Interactive for maintenance advice if you have concerns. ▪ Don’ts: Do not wear shoes with leather soles or high heels. -
Page 8: In Play Safety Guidelines
Make sure you have control before leaving the trampolines, obstacles or activity equipment. ▪ Don’ts: No more than four active users on the equipment at any one time. ▪ TrailBlazer ® Traverse HEX – Section 2 - Safety Guidelines © Rugged Interactive 2019... - Page 9 Maximum weight restriction per user is 18st/115kg. TrailBlazer ® Traverse HEX – Section 2 - Safety Guidelines © Rugged Interactive 2019...
-
Page 10: Section 3 - Installation
+44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk Section 3 - Installation 3.1 - Parts List Please check off the received parts for the installation and alert Rugged Interactive immediately if anything is missing. 12 x Wall Mouldings. ☐ 1 x Hub control box. -
Page 11: Tools And Components List
Cordless drill – with torque adjuster to avoid over-tightening the screws. ☐ A set of No.2 Pozi bits. ☐ A set of screwdrivers. ☐ A set of Hex keys. ☐ Spirit level. ☐ TrailBlazer ® Traverse HEX – Section 2 - Installation © Rugged Interactive 2019... -
Page 12: Installation Overview
3.3 - Installation Overview Below is an overview of the steps needed to install TrailBlazer Traverse HEX. More detail for the process is provided in the following pages. Please read through ALL of this prior to beginning the installation and if you are in any doubt, contact Rugged Interactive. -
Page 13: Detailed Installation
+44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk 3.4 – Detailed Installation Read this manual before installing the TrailBlazer Traverse HEX climbing wall. Installation Guidelines: Please complete a Site Survey form prior to delivery and/or installation. ▪ Please send a completed Installation Checklist after any installation to Rugged Interactive. - Page 14 A waiting / spectating area positioned nearby is advised. ▪ A leaderboard to go with each unit is highly recommended. ▪ IF YOU ARE IN ANY DOUBT, CALL RUGGED INTERACTIVE DIRECTLY ON +44 (0) 1726 833 882 TrailBlazer ® Traverse HEX –...
- Page 15 Continue working anti-clockwise, and repeat steps with mouldings 3T, 4T and 5T. (See Figure 2.2.) Do not fit moulding 1T at this stage. Tubes without aluminium insert Figure 2.2: Top moulding positions TrailBlazer ® Traverse HEX – Section 3 - Installation © Rugged Interactive 2019...
- Page 16 45 mm of the tube protruding at the top. (See Figure 2.4.) This also may take some wiggling. Tubes with aluminium insert Figure 2.4: Fitting moulding 1T TrailBlazer ® Traverse HEX – Section 3 - Installation © Rugged Interactive 2019...
- Page 17 14. Once all pods are connected correctly, fully secure all interactive pods with the remaining fixings. (NB: Do not overtighten grip screws.) 15. Use box trunking to tidy away and secure the cables along the top of the wall mouldings. TrailBlazer ® Traverse HEX – Section 3 - Installation © Rugged Interactive 2019...
- Page 18 Traverse HEX Order and Installation Manual: Installation ® TrailBlazer Traverse HEX Display / Score Box (HUB) Installation Fix HUB using any suitable self-tapping or wood screws into the surface material. The HUB can be ▪ recessed to be flush with the surface or affixed on top of the foam-backed vinyl if necessary.
- Page 19 Retain all screws & washers. NOTES: Ensure CAT5 cable is not strained or trapped. Do not overtighten grip screws. Power on the TrailBlazer Climbing wall and check operation. Removing the Grips TrailBlazer ® Traverse HEX – Section 3 - Installation © Rugged Interactive 2019...
-
Page 20: Section 4 - How To Use
NOTE: At any time, if the TrailBlazer behaves unexpectedly, wait for at least 30 seconds (1 minute during FreePlay) for the unit to reset to its idle state. TrailBlazer ® Traverse HEX – Section 4 - How to Use © Rugged Interactive 2019... - Page 21 Figure 4.2: TrailBlazer Traverse Trampoline Programs NOTE: At any time, if the TrailBlazer behaves unexpectedly, wait for at least 30 seconds for the unit to reset to its idle state. TrailBlazer ® Traverse HEX – Section 4 - How to Use © Rugged Interactive 2019...
-
Page 22: Section 5 - Programs Guide
NOTE: At any time, if the CardioWall behaves unexpectedly during gameplay, wait for at least 30 seconds of inactivity for the unit to reset to its idle state. TrailBlazer ® Traverse HEX – Section 5 - Programs Guide © Rugged Interactive 2019... - Page 23 NOTE: At any time, if the CardioWall behaves unexpectedly during gameplay, wait for at least 30 seconds of inactivity for the unit to reset to its idle state. TrailBlazer ® Traverse HEX – Section 5 - Programs Guide © Rugged Interactive 2019...
- Page 24 NOTE: At any time, if the CardioWall behaves unexpectedly during gameplay, wait for at least 30 seconds of inactivity for the unit to reset to its idle state. TrailBlazer ® Traverse HEX – Section 5 - Programs Guide © Rugged Interactive 2019...
- Page 25 NOTE: At any time, if the CardioWall behaves unexpectedly during gameplay, wait for at least 1 minute of inactivity for the unit to reset to its idle state. TrailBlazer ® Traverse HEX – Section 5 - Programs Guide © Rugged Interactive 2019...
- Page 26 Rugged Interactive Unit 1, Callywith Court, Callywith Industrial Estate, Bodmin, Cornwall, UK PL31 2RQ +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk TrailBlazer Traverse HEX System Specifications Dimensions and Weights: Approx. Shipment Details Fully Assembled Details Size (mm) Weight Size (mm) Weight...
- Page 27 TrailBlazer Traverse HEX Order and Installation Manual: System Specifications ® 1090 Figure 1: Mounting Points (Dimensions in mm) Figure 2: Panel Orientations TrailBlazer ® Traverse HEX - System Specifications © Rugged Interactive 2019...
- Page 28 TrailBlazer Traverse HEX Order and Installation Manual: System Specifications ® 1100 R 170 120 2540 2245 Figure 3: Hex Footprint TrailBlazer ® Traverse HEX - System Specifications © Rugged Interactive 2019...
- Page 29 Bodmin, Cornwall, UK PL31 2RQ +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk TrailBlazer Traverse HEX Installation Checklist Please complete this checklist after any installation: Check 1: Pre-power up checks. ☐ Equipment is stable and secure capable of supporting its weight and gameplay.
- Page 30 ☐ Instruction / training carried out by an appropriate instructor to all new users. If anything unexpected occurs or problems persist after troubleshooting, call Rugged Interactive directly on +44 (0) 1726 833 882. * The volume can be adjusted on the scorebox. The volume control (a black dial) is located on the bottom edge of the scorebox between the speakers.
- Page 31 Next Steps Train team members Train your team members on how to use TrailBlazer Traverse HEX, having knowledge of the gameplay will help them encourage users. Inspire them to cheer and celebrate with the customers when they achieve high scores.
- Page 32 Congratulations! Congratulations on your new Rugged Interactive product! Your customers are going to love this, and it is a great addition to your venue! If there is anything we can assist with or if you would be interested in information about any other Rugged Interactive products, then please do not hesitate to get in contact.
