- Page 1 WallRider Order and Installation Manual For models from January 2019 onwards Rugged Interactive Unit 1, Callywith Court Callywith Industrial Estate , Bodmin Cornwall, UK PL231 2RQ +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk © Rugged Interactive 2019...
-
Page 2: Table Of Contents
Section 3 – Installation 3.1 Parts List 3.2 Tools and Components List 3.3 Installation Overview 3.4 Detailed Installation Section 4 – How to Use Section 5 – Programs Guide WallRider System Specifications WallRider Installation Checklist Next Steps © Rugged Interactive 2019... -
Page 3: Section 1 - Ordering Process
Installation manual purpose and limitations This manual is intended to provide guidance only, the installation of the Rugged Interactive product will be under your control. You will be responsible for making sure, upon completion of the installation, it is safe to use. -
Page 4: Order And Installation Checklist
1.2 - Order and Installation Checklist ☐ Contact the Rugged Interactive sales team or a partner / distributor to begin the process. Confirm the invoice and delivery address along with date required (lead time is at least 5 weeks), ☐... -
Page 5: Ordering And Installation Timeline
With three different game programs, it is suitable for advanced users and beginners alike. A standard WallRider consists of 8 x bulletproof target pads, 1 x HUB display and sound unit with all the cables supplied. It is easy and quick to install to any suitable wooden wall with a cavity behind it. -
Page 6: Getting Started
If further information is required, please get in touch and we will be able to provide further information and guidance. 1.6 - Place Order Key Contacts at Rugged Interactive: Sales Office Address: Commercial Director – Harry Stevens Rugged Interactive, Harry@rugged-interactive.co.uk... -
Page 7: Section 2 - Safety Guidelines
Tidy back loose cables that could become a tripping hazard. ▪ Ensure that the playing area is clear. ▪ Immediately inform Rugged Interactive for maintenance advice if you have concerns. Don’ts: ▪ Do not wear shoes with leather soles or high heels. -
Page 8: In Play Safety Guidelines
WallRider Installation and Instruction Manual: Safety Guidelines 2.2 In Play Safety Guidelines Please ensure you read the following points before using the equipment: This activity can be great fun, but it can also be dangerous. There is a risk of serious injury if care is not taken when using the equipment. - Page 9 WallRider Installation and Instruction Manual: Safety Guidelines Don’ts: ▪ No more than one active user on a single trampoline at any one time. ▪ Do not attempt to use any of the equipment without undertaking instruction / training carried out by an appropriate instructor.
-
Page 10: Section 3 - Installation
+44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk Section 3 - Installation 3.1 - Parts List Please check off the received parts for the installation and alert Rugged Interactive immediately if anything is missing. 8 x Targets. ☐ 1 x Hub display assembly. -
Page 11: Installation Overview
3.3 - Installation Overview Below is an overview of the steps needed to install WallRider. More detail for the process is provided in the following pages. Please read through ALL of this prior to beginning the installation and if you are in any doubt, contact Rugged Interactive. -
Page 12: Detailed Installation
Read this manual before installing the WallRider units. Installation Guidelines: Complete a Site Survey form prior to delivery and/or installation. ▪ Send a completed Installation Checklist after any installation back to Rugged Interactive. ▪ A typical installation should take 2 people about 4 hrs. ▪... - Page 13 ▪ Installation: Layout of the WallRider targets is at the discretion of the installer / park constructor. ▪ Works well having targets 1 to 4 on the front wall in a line and side targets 5 to 8 spread evenly ▪...
- Page 14 WallRider Order and Installation Manual: Installation WallRider Installation 1. Mark out and cut the recesses for eight targets and one score box 2. Mount score box, this contains eight hanging cables for the targets, connect the CAT5 cables into their corresponding positions on the HUB.
- Page 15 WallRider Order and Installation Manual: Installation 3. Run the cables to the positions they are required for the targets. Please note, cable 1, 2 and 3 operate the quick start game functions, therefore these targets should be positioned in a suitable location.
- Page 16 WallRider Order and Installation Manual: Installation Figure 3.4.1: A Possible WallRider Layout Figure 3.4.2: A Possible WallRider Layout Figure 3.4.3: A Possible WallRider Layout Figure 3.4.4: A Possible WallRider Layout WallRider – Section 3 - Installation © Rugged Interactive 2019...
- Page 17 1500 – 2000mm 500 – 750mm Figure 3.4.5: Recommended WallRider installation heights. (Installation layout and heights are at the discretion of the installer. Wall heights and primary user groups should be considered. We recommend having the scorebox in a location visible for the player when using the main 4 targets.)
- Page 18 WallRider Order and Installation Manual: Installation Figure 3.4.6: Typical WallRider Installation WallRider – Section 3 - Installation © Rugged Interactive 2019...
-
Page 19: Section 4 - How To Use
+44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk Section 4 - How to Use On power up, WallRider will sound a ‘laugh’ and will turn to its idle state. WallRider has three programs: 1. Beginner – 1 minute 2. Intermediate – 1 minute 3. -
Page 20: Section 5 - Programs Guide
+1 for the red target, +2 for the orange and yellow targets, +3 for the green target. Scoring system: 1 minute Duration: NOTE: If at any time WallRider behaves unexpectedly during gameplay, wait for at least 60 seconds for the unit to reset to its idle state. WallRider – Section 5 - Programs Guide ©... - Page 21 +1 for the red target, +2 for the orange and yellow targets, +3 for the green target. Scoring system: 1 minute Duration: NOTE: If at any time WallRider behaves unexpectedly during gameplay, wait for at least 60 seconds for the unit to reset to its idle state. WallRider – Section 5 - Programs Guide ©...
- Page 22 +1 for the red target, +2 for the orange and yellow targets, +3 for the green target. Scoring system: 1 minute Duration: NOTE: If at any time WallRider behaves unexpectedly during gameplay, wait for at least 60 seconds for the unit to reset to its idle state. WallRider – Section 5 - Programs Guide ©...
- Page 23 Indoors: keep dry and out of direct sunlight. Mount to a wall of a suitable construction. Optimum ambient temperature: 5°C to 30°C. Avoid extreme fluctuations of temperature. Other: All parts designed for easy maintenance. If you have any concerns, please contact Rugged Interactive.
- Page 24 WallRider Order and Installation Manual: System Specifications Cut out sizes: Each target and the HUB/Score box will require a recess cut out of the wall for them to sit flush to the wall. Target Figure 1: Score box and target cut out size required for installation.
- Page 25 WallRider Installation and Instruction Manual: System Specifications Mounting Points and Dimensions: Figure 2: Score box Mounting Points and Dimensions (Dimensions in mm) Figure 3: Target Mounting Points and Dimensions (Dimensions in mm) WallRider - System Specifications © Rugged Interactive 2019...
- Page 26 Cornwall, UK PL31 2RQ +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk WallRider Installation Checklist Please complete this checklist after any installation: Check 1: Pre-power up checks. ☐ Mounted onto a wall of a construction capable of supporting its gameplay. ☐...
- Page 27 +44 (0) 1726 833 882. * The volume control for WallRider can be located on the reverse of the score box in the bottom left corner. The dial can be twisted clockwise to increase the volume and anti-clockwise to reduce it.
- Page 28 Next Steps Train team members Train your team members on how to use WallRider, having knowledge of the gameplay will help them encourage users. Inspire them to cheer and celebrate with the customers when they achieve high scores. Maintenance General care and maintenance procedures for your Rugged Interactive product.
- Page 29 Congratulations! Congratulations on your new Rugged Interactive product! Your customers are going to love this, and it is a great addition to your venue! If there is anything we can assist with or if you would be interested in information about any other Rugged Interactive products, then please do not hesitate to get in contact.
