PARTS I N CLU DE D:
A
[1]
HEADBOARD PANEL
B
[1]
FOOTBOARD PANEL
C
[2]
SIDE RAILS
D
[3]
SLATS
E
[3]
CENTER LEGS
F
[2]
PLATFORM PANELS
TOO L S N E E D E D :
Phillips-Head Screwdrive ( not included)
ASS E M B LY I N ST R U CT IO N S :
STEP 1:
Insert the Threaded Rods (1) into the posts of the
Headboard (A) and Footboard (B).
B
AS H BY FU LL PA NEL BE D
NO.
ITEM
1
2
3
4
5
(1)
Page 1 of 4
DESCRIPTION
Threaded Rod 5/16" x 3"
Curved Slotted Washer 5/16"
Hex Nut 5/16" x 12mm
Hex Wrench 12 mm
Screws 8 x 30 mm
A
QTY.
8 pcs.
8 pcs.
8 pcs.
1 pc.
34 pcs.
