Balanced Body Rialto with Riser Konnector Installing

Installing the Balanced Body
Konnector
The Konnector is compatible with Balanced Body Rialto
Reformers ONLY. If you aren't sure whether this system will
work with your equipment, please contact Balanced Body at
1-800-PILATES (US and Canada), or +1-916-388-2838 (all other
countries).
To view the installation podcast, please visit
www.pilates.com/instructions
TOOLS REQUIRED (NOT INCLUDED):
» Power Drill
» Phillips Head screw driver
PARTS LIST (INCLUDED):
ITEM
Konnector Rope
Tri-Loops (Grey)
Tri-Loops (Black) with pulleys
Twist lock flanged post ASM
Under carriage ASM
Pulley Assembly for Wood
Shoulder brackets
Riser tube assembly
Wood Template
#10 x 5/8 Phillips Pan Head Screw
1/4-20 x 1/2 Flat head screws black
1/4" Flat Washer
1/4-20 Hex Nut
1/4-20 Acorn Nut
5/16" Drill bit
3/32" (2.5 mm) Allen wrench
5/32" Allen wrench
7/16" Wrench
1 2
™
PART NO.
210-076
210-061
210-060
616-401
624-002
620-083
607-546
607-547
607-542
GEN9143
GEN6671
GEN9204
GEN9056
GEN9181
TOL1059
TOL1605
GEN9282
616-113
3
Rialto with Riser
®
WARNING: Using the existing shoulder posts with a Konnector
system can cause the loops to fall off the posts during use
which may cause injury.
REMOVE ROPES, SHOULDER BRACKETS AND PADS
1. Remove the ropes and loops from your Reformer, they are no
longer needed.
2. Unthread each knob from the shoulder rest bracket by hand
and completely remove them from the shoulder rest bracket.
Remove the shoulder rest bracket from the carriage. Repeat
on the other side.
3. Using the provided small Allen wrench, remove the four flat
head screws from each shoulder bracket as shown in Figure
QTY
A. Keep theses screws, repeat on the other side.
1
2
2
2
2
2
2
1
1
4
4
6
6
2
Figure A
1
1
1
1
WARNING: If you are only using some of the loops, the
unused loops MUST be stored on the flanged shoulder
posts.
4
Contact Us
1-800-PILATES | +1-916-388-2838
pilates.com | info@pilates.com
400-454 | 10.24.18
