3 Product information

3.1 Functional Description

The product is a compact welding fumes filter device that extracts welding
fumes at the point where they are produced and extracts them with a filter
efficiency of more than 99%.
The extracted contaminated air is cleaned using a 2-stage filter method
and then fed back into the workspace.
The product is equipped with a flexible extraction arm whose extraction
hood is easy to move and is self-supporting in any position.
Pos. Designation
1 Extraction hood
2 Extraction arm
3 Maintenance door
4 Filter insert
5 Operating controls/Control
unit box
3.2 Distinguishing feature – W3/IFA certified
The product is manufactured in two versions:
• Version – non-IFA certified
1502763-02
Fig. 11: Product description
Pos. Designation
6
7
8
9
Tab. 10: Positions on the product
- 52 -
Handle bar
Cable holder
Swivel castor with brake
Rear wheel
