SANUS VuePoint F215B Instruction Manual page 7

Parts and Hardware for STEP 2
Wall Plate Template
17
Lag Bolts
19
Concrete Anchors
21
Wall Plate/Arm Assembly
18
5⁄16 2 3⁄ 4
x in.
(2)
(2)
Parts and Hardware for STEP 3
Screw
8-32 x 3⁄8 in.
Additional Hardware
Washers
5⁄16
in.
20 (2)
Washer
8-32 in.
22 23
3/16 in.
5/32 in.
5/32 in. 3/16 in.
24 25
