RX6 Digital I/O

The PP24 can be mounted above or below the RX6.
A1 - A8
Bit Addressable Digital I/O
Bits 0-7

RX8 I/O

The PP24 can be mounted above or below the RX8.
A1 - A8
Bit Addressable Digital I/O
Bits 0-7
RX6 Digital I/O connection to the PP24
B1 - B8 C1 - C8
Digital I/O Digital I/O
Byte A Bits 0-7 Byte B Bits 8-15
RX8 Digital I/O connection to the PP24
B1 - B8 C1 - C8
Digital I/O Digital I/O
Byte A Bits 0-7 Byte B Bits 8-15
