7.3 Firmware Update


Right-click on the reader and select Firmware update menu

On the Firmware update window, click on the Browse button. The default location of the firmware files installed with
PROS is in the PROS folder under "Firmware" folder. If you have a newer version, use browse to locate it.

Select the firmware file with a "xhc" extension

Check the firmware version. If the version is not greater than the existing version of the reader then do not upgrade
with this file unless specified by the Installer or manufacturer of the device.

Click on the Upload button

Wait for the update end message

Close the Firmware update window

7.4 Read reader settings


Right-click on the reader and select the Get settings menu

7.5 Upload configuration to a reader


Right-click on the reader and select the Send configuration menu

See the events panel to check the configuration flow

7.6 Sensor calibration


Right-click on the reader and select the Calibrate menu

See the events panel to check the Calibration flow
It is recommended to perform a sensor calibration once the reader has been mounted. Clean the fingerprint sensor
before calibration.

7.7 Selecting a finger for fingerprint enrollment

At least two fingerprints should be enrolled for each user in case of any abnormal situation like having an injured finger
or carrying an object by hand.
In case of low recognition, the user can register the same fingerprint twice to increase the recognition rate.
