1004044581
Model KVS9454
Redesigned Valley Peak 3Pc
Wicker Sectional with Flat Wicker - Gray
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this [product description]. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY KVS9454
Summary of Contents for HAMPTON BAY KVS9454
- Page 1 THANK YOU We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this [product description]. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Wicker Sectional Sofa Set Assembly......5 Safety Information ............2 Care and Cleaning............14 Product Caution ..............2 Safety Warnings ..............2 Warranty ................ 2 What is Covered ..............2 What is Not Covered .............. -
Page 3: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Please use wrench "HH"... -
Page 4: Wicker Sectional Sofa Set Package Contents
Pre-Assembly (continued) VALLEY PEAK WICKER SECTIONAL 2018 PACKAGE CONTENTS Part Description Quantity Seat assembly A Left arm A Back assembly A Seat assembly B Right arm B Back assembly B Leg A Leg B Support A Support B Support C Back cushion Arm cushion Left seat cushion... -
Page 5: Wicker Sectional Sofa Set Assembly
Valley Peak Wicker Sectional 2018 Assembly Connecting the seat assembly A to the left arm A Place the left arm A (B) onto a non-abrasive surface, such as a carpet, with its underside facing upwards. Fasten the seat assembly A (A) to the left arm A (B) by using M6x50 bolts (DD), d6.5xD13x1.0 washers (EE), and M6xP1.0 plastic nuts (FF). NOTE: Loosely tighten all the bolts using the hex wrenches (GG and HH). - Page 6 Valley Peak Wicker Sectional 2018 Assembly (continued) Connecting the support A to the seat assembly A and left arm A Fasten the support A (I) to the seat assembly A (A) by using a M6x16 bolt (AA) and d6.5xD13x1.0 washers (EE). Fasten the support A (I) to the left arm A (B) by using a M6x30 bolt (BB), d6.5xD13x1.0 washer (EE), and M6xP1.0 plastic nut (FF).
- Page 7 Valley Peak Wicker Sectional 2018 Assembly (continued) Connecting the back assembly A to the left arm A Insert the back assembly A (C) into the left arm A (B). Fasten the back assembly A (C) to the left arm A (B) by using M6x50 bolts (DD), d6.5xD13x1.0 washers (EE), and M6xP1.0 plastic nuts (FF).
- Page 8 Valley Peak Wicker Sectional 2018 Assembly (continued) Connecting the seat assembly B to the right arm B Place the right arm B (E) onto a non-abrasive surface, such as a carpet, with its underside facing upwards. Fasten the seat assembly B (D) to the right arm B (E) by using M6x50 bolts (DD), d6.5xD13x1.0 washers (EE), and M6xP1.0 plastic nuts (FF).
- Page 9 Valley Peak Wicker Sectional 2018 Assembly (continued) Connecting the support B to the seat assembly B Fasten the support B (J) to the seat assembly B (D) by using M6x30 & M6x35 bolts (BB and CC), d6.5xD13x1.0 washers (EE), and M6xP1.0 plastic nuts (FF). NOTE: Loosely tighten all the bolts using the hex wrenches (GG and HH).
- Page 10 Valley Peak Wicker Sectional 2018 Assembly (continued) Connecting the back assembly B to the support B, seat assembly B, and right arm B Insert the back assembly B (F) into the right arm B (E). Fasten the back assembly B (F) to the support B (J) by using M6x30 bolts (BB), d6.5xD13x1.0 washers (EE), and M6xP1.0 plastic nuts (FF). Fasten the back assembly B (F) to the seat assembly B (D) and the right arm B (E) by using M6x50 bolts (DD), d6.5xD13x1.0 washers (EE), and M6xP1.0 plastic nuts (FF).
- Page 11 Valley Peak Wicker Sectional 2018 Assembly (continued) Connecting the support C to the seat assembly B and seat assembly A Fasten the support C (K) to the seat assembly B (D) and the seat assembly A (A) by using M6x50 bolts (DD), d6.5xD13x1.0 washers (EE), and M6xP1.0 plastic nuts (FF).
- Page 12 Valley Peak Wicker Sectional 2018 Assembly (continued) Connecting the supports to the seat assembly A & B and back assembly A & B Fasten supports (I and K) to the seat assembly A (A), the seat assembly B (D), the back assembly A (C), and the back assembly B (F) by using M6x35 &...
- Page 13 Valley Peak Wicker Sectional 2018 Assembly (continued) Connecting the leg A to the legs B Fasten the leg A (G) to legs B (H) by using M6x30 bolts (BB) and d6.5xD13x1.0 washers (EE). NOTE: Loosely tighten all the bolts using the hex wrench (GG). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
-
Page 14: Care And Cleaning
Valley Peak Wicker Sectional 2018 Assembly (continued) Tightening the bolts Tighten all bolts that were previously loosely tightened. Turn the sectional to its upright position. Position all of the sections together as illustrated, to complete your set. Place cushions (L, M, N, O, and P) onto the frame. Care and Cleaning For best results, clean the set with a damp cloth and dry thoroughly. - Page 15 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
