1003368493
Model KTS677K
USE AND CARE GUIDE
Plymouth KD FULL BUCKET SLING STACK
CHAIR - CONLEY CHILI / BRONZE FRAME (2-Pack)
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
y through the purchase of this chair. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY 1003368493
Summary of Contents for HAMPTON BAY 1003368493
- Page 1 We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
- Page 2 Table of Contents Chair of Contents ............2 Chair Assembly.............5 Safety Information ............2 Care and Cleaning............7 Product Caution ..............2 Safety Warnings ..............2 Warranty ................ 2 What is Covered ..............2 What is Not Covered ..............
- Page 3 Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity...
- Page 4 Pre-Assembly (continued) CHAIR PACKAGE CONTENTS Part Description Quantity Seat Assembly Left Leg Right Leg...
- Page 5 Chair Assembly Connecting the chair legs into the chair seat assembly Insert the legs (B and C) into the seat assembly (A), fasten them by using M6x35 bolts (AA) and steel washers (CC). NOTE: Loosely tighten all the bolts using the hex wrench (DD). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 6 Chair Assembly (continued) Connecting the chair seat assembly to the chair legs At the back of the chair, fasten the seat assembly (A) to the legs (B and C) by using M6x35 bolts (AA) and d6.5xD13x1.0 washers (BB). NOTE: Loosely tighten all the bolts using the hex wrench (DD).
- Page 7 Chair Assembly (continued) Tightening the bolts Turn the chair to its upright position. Once all of the bolts are in place, fully tighten the bolts. Ensure all connections are secure before use. Care and Cleaning For best results, clean the chair with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate.
- Page 8 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
