1003183454
Model KTS60EH
USE AND CARE GUIDE
Crestridge Padded Sling Spring Dining Chair - Taupe Putty (2-Pack)
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
y through the purchase of this dining set. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HAMPTON BAY KTS60EH
Summary of Contents for HAMPTON BAY KTS60EH
- Page 1 We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
-
Page 2: Safety Warnings
Table of Contents Table of Contents ............2 Chair Assembly.............5 Safety Information ............2 Care and Cleaning............9 Product Caution ..............2 Safety Warnings ..............2 Warranty ................ 2 What is Covered ..............2 What is Not Covered .............. -
Page 3: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity... - Page 4 Pre-Assembly (continued) CHAIR PACKAGE CONTENTS Part Description Quantity Seat Assembly Left Leg Right Leg Support...
-
Page 5: Chair Assembly
Chair Assembly Connecting the chair support to the chair legs Insert the support (D) to the legs (B and C). Fasten them by using M6x35 bolts (AA) and steel washers (DD). NOTE: Loosely tighten all the bolts using the hex wrench (EE). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance. - Page 6 Chair Assembly (continued) Connecting the chair seat assembly to the chair legs At the front of the chair, fasten the seat assembly (A) to legs (B and C) by using M6x16 bolts (BB) and d6.5xD13x1.0 washers (CC). NOTE: Loosely tighten all the bolts using the hex wrench (EE). Keep 3mm Gap. Don’t fully tighten the Bolts.
- Page 7 Chair Assembly (continued) Connecting the chair seat assembly to the chair legs At the back of the chair, fasten the seat assembly (A) to legs (B and C) by using M6x35 bolts (AA) and d6.5xD13x1.0 washers (CC). NOTE: Loosely tighten all the bolts using the hex wrench (EE). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
-
Page 8: Care And Cleaning
Chair Assembly (continued) Tightening the bolts Turn the chair to its upright position. Once all of the bolts are in place, fully tighten the bolts. Ensure all connections are secure before use. Care and Cleaning For best results, clean the set with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate. - Page 9 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
