Model KTS807K
USE AND CARE GUIDE
Wilson KD SPLIT BACK SLING STACK
CHAIR - EMERALD COAST / BRONZE FRAME (2-Pack)
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
y through the purchase of this chair. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY KTS807K
Summary of Contents for HAMPTON BAY KTS807K
- Page 1 We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
-
Page 2: Safety Warnings
Table of Contents Table of Contents ............2 Chair Assembly............5 Safety Information ............2 Care and Cleaning............8 Product Caution ..............2 Safety Warnings ..............2 Warranty ................ 2 What is Covered ..............2 What is Not Covered ..............2 Pre-Assembly .............. -
Page 3: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity... - Page 4 Pre-Assembly (continued) CHAIR PACKAGE CONTENTS Part Description Quantity Back assembly A Back assembly B Seat assembly Left arm Right arm...
-
Page 5: Chair Assembly
Chair Assembly Connecting the chair back A to the chair back B Place the back assembly (A and B) onto a non-abrasive surface, such as a carpet. Insert the back assembly A (A) into the back assembly B (B). Fasten the back assembly A (A) to the back assembly B (B) by using ST4.2x12 screw (AA). NOTE: Loosely tighten all the bolts using the hex wrench (FF). - Page 6 Chair Assembly Connecting the chair seat to the chair back Insert the seat assembly (C) into the back assembly B (B). At the rear of the seat, fasten the seat assembly (C) to the back assembly B (B) by using M6x64 bolts (DD) and d6.5xD13x1.0 washers (EE).
- Page 7 Chair Assembly (continued) Connecting the chair arms to the chair seat and chair back Fasten the arms (D and E) to the seat assembly (C) by using M6x16 bolts (BB) and d6.5xD13x1.0 washers (EE) at the front of the seat assembly (C).
-
Page 8: Care And Cleaning
Chair Assembly (continued) Tightening the bolts Once all of the bolts are in place, fully tighten the bolts. Turn the chair right side up. Care and Cleaning For best results, clean the chair with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate. - Page 9 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
