Summary of Contents for Leica 3D Disto
- Page 1 Leica 3D Disto Tutorial PROJECTOR Quick Start...
- Page 2 Leica 3D Disto PROJECTOR Quick Start Create a DXF or CSV file with the pattern you need to set out.
- Page 3 Leica 3D Disto PROJECTOR Quick Start Copy the file to the 3D Disto Data folder on the desktop. Start the 3D Disto software Projector application.
- Page 4 Leica 3D Disto PROJECTOR Quick Start Select a projection..and measure the reference.
- Page 5 Leica 3D Disto PROJECTOR Quick Start Import the design data. Fit to the reference and click the checkmark.
- Page 6 Leica 3D Disto PROJECTOR Quick Start Tip on a blue design point and press DIST. The laser indicates the correct position. Irregularities on the surface are considered; the projection is always error-free.
- Page 7 Leica 3D Disto PROJECTOR Quick Start Continue on the floor in case of obstacles. Following points can be set out remotely The 3D Disto plumbs down correctly. without touching the computer.
- Page 8 Leica 3D Disto Registration at myWorld Register your 3D Disto on myWorld for: warranty extension license keys more tutorials free software updates support manuals www.myworld.leica-geosystems.com...
