- Page 1 Leica DISTO™ with Bluetooth Smart usage Windows 8 V 1.0 December 2013...
- Page 2 The Leica DISTO™ devices with Bluetooth® Leica DISTO™ D8 Leica DISTO™ D510 Leica DISTO™ D810 touch Leica DISTO™ D3a BT (D330i) Bluetooth® 2.1 Bluetooth® Smart Bluetooth® Smart Bluetooth® 2.1 Requires Requires Requires Requires support Bluetooth® 4.0 Bluetooth®...
- Page 3 Overview DISTO™ compatibility Availability Windows 7 Windows 8 Windows Mobile Android Leica DISTO™ sketch *) Leica DISTO™ sketch *) Android 4.3 Leica DISTO™ transfer **) Android 4.3 ****) Leica DISTO™ www.disto.com transfer PPC ***) Leica DISTO™ www.disto.com transfer PC ***) Windows 8.1...
- Page 4 Prolog This presentation should provide further advice on how to use the Leica DISTO™ with Bluetooth® Smart. Also the corresponding Apps for iOS and Android are described in this document. For further information regarding using Bluetooth® 2.1 please use the document at following link: http://ptd.leica-geosystems.com/en/Leica-DISTO-D8_78069.htm...
- Page 5 Leica DISTO™ Bluetooth Smart Getting started...
-
Page 6: Bluetooth® Smart
General Bluetooth® Smart Bluetooth® Smart is compatible with Bluetooth® 4.0 or Bluetooth® Smart Ready devices Bluetooth® Smart has very low power consumption why it is by default switched on... - Page 7 Leica DISTO™ D510 Bluetooth® Smart The Bluetooth® can be switched off in the Settings of the Leica DISTO™ D510 The Leica DISTO™ D510 only supports the connection to iOS or Android 4.3 Apps Press ‘=‘ to switch on or off...
- Page 8 Leica DISTO™ D810 touch Bluetooth® Smart The Bluetooth® can be switched off in the Settings of the Leica DISTO™ D810 touch...
- Page 9 Leica DISTO™ D810 touch Bluetooth® Smart The Leica DISTO™ D810 touch provides 3 different modes for use with Bluetooth® Keyboard Spreadsheet – Mode Go to Bluetooth® Settings E.g. 7.123 decimal numbers TAB: sends a Tabulator after each value...
-
Page 10: Keyboard Mode
Keyboard Mode Windows 8 or higher Getting started... -
Page 11: How To Start
This mode is only supported by the Please use the Bluetooth® manager to pair the devices. Once the Windows 8 device and the Leica DISTO™ are paired they will immediatelly connect if both are switched on. The Leica DISTO™ will be considered as a keyboard. So by sending a measurement the Windows 8 device believes you are writing the value on a keyboard. - Page 12 Keyboard Mode for Windows 8 How to start Select „Change PC Settings“ Select „Devices“ Select „Bluetooth“ Click on device and select „Pair“ Instrument should be listed as paired device...
- Page 13 Keyboard Mode for Windows 8 How to start You need to either set the DISTO™ D810 touch to following modes (see also page 9 of this presentation) Spreadsheet mode: Use for sending decimal values without unit for further calculation ...
- Page 14 Keyboard Mode for Windows 8 How to send data and navigate in a Program After the devices are connected the favorite keys will change for sending measurement values or navigation If switched on the Arrow keys on the DISTO™ can Sends the actual value in the main-line of the DISTO™...
-
Page 15: Good To Know
To Remove a device in Windows 8 proceed to the same menu like for adding a device. When a Leica DISTO™ D810 touch is already paired with one iOS or Windows 8 device it cannot be paired with a second device at the same time, it needs to be unpaired first!
