3. GENERAL INSTALLATION INSTRUCTION
3.1 Mounting instructions
The H.R.UV-C SPA should be either installed horizontally or vertically allowing enough space for the pipe
connections, wiring and maintenance of lamps/quartz sleeve. It should be firmly secured, using the fixing
kit provided, to a solid wall.
NOTE:
When mounting the UV, it is essential to leave a clearance space of at least 1 metre
from one side of the unit to allow access to replace the lamp(s) and/or quartz
sleeve(s) when required. Both the lamps and the quartz sleeve can be replaced
from either end of the unit; if installing vertically the 1m clearance space must be
above or below the unit, if installing horizontally the 1m clearance space must be to
the left or right of the unit.
WARNING: The
H.R.UV-C SPA
any case where water or moisture enters the enclosure the warranty will be void.
Caution:
If the H.R.UV-C SPA is unused during the winter months; it must be drained to prevent
frost damage. Water must not be allowed to freeze inside the unit as this will cause severe
damage.
See Fig. 3 for mounting instructions when securing to the wall.
must be installed within a dry, permanent weather-proof area. In
Fig. 3
5
