IMPORTANT NOTES Thank you for purchasing the MINI H.R.UV-C pool sanitising system, the latest in high reflection UV technology, manufactured to the highest standards in England. To ensure years of trouble-free service, please read and follow these instructions for proper installation, maintenance and use.
3. GENERAL INSTALLATION INSTRUCTION 3.1 Mounting instructions The device should be either installed horizontally or vertically allowing enough space for the pipe connections, wiring and maintenance of lamps/quartz sleeve(s). It should be firmly secured, using the fixing kit provided, to a solid wall. NOTE: When mounting the UV, it is essential to leave a clearance space of at least 1 metre from one side of the unit to allow access to replace the lamp(s) and/or quartz...
Fig. 6 3.4 Connection The unit is supplied with unions to allow connection to 2" or 63-mm rigid pipe. Reducers are also supplied to allow connection to 50-mm or 1½" rigid pipe - see Fig 7. For pipework 63-mm or 2” in diameter. For pipework 50-mm or 1½“...
Fig. 7 All factory unions are made from ABS plastic, when gluing connections to an ABS pipe an ABS cement must be used or when using a PVC pipe, a Transition cement must be used (See Fig. 7). There is no need to use mastic or PTFE tape to connect unions to the device, use the O-rings provided to put in the groove on the end of the Manifold Assembly.
4. OPERATING INSTRUCTIONS 4.1 Flow requirements Minimum flow rate: • /hour (1,000 litres per hour) Maximum flow rate: • 30W (Mini) = 12m /hour (12,000 litres per hour) • A higher flow rate will require the installation of a bypass to prevent damage to the unit The unit should be wired in such a way that it can only be energised when the swimming pool filtration pump is energised and running, under no circumstances should the UV unit be energised without flowing water being present.
SP-UV-ORS Fig. 10 5.2 Lamp replacement and quartz sleeve cleaning Removing the lamp and quartz sleeve Unclamping the clip from body 1. Pull the clip in shown direction to Unscrew all the highlighted fasteners unlock from body 2. Pull the second side after unlocking the side Remove Lamp holder Clip from Hard cap Unmount the Hard cap from Blue lamp Holder...
Page 11
Carefully remove the blue lamp holder shroud white plastic electrical end caps from the lamp end Gently slide the lamp out ensuring that no Unscrew the blue quartz sleeve locking nut pressure is applied to the glass quartz anticlockwise. Both ends must be unscrewed sleeve.
• Firstly, slide the clean dry quartz glass sleeve into the unit. • Locate the ’O’ rings carefully on the ends of the quartz sleeve. • Make sure the threads are clean, wipe a little silicone grease onto the threads. As these threads are only serviced periodically, this lubrication will help to prevent them binding together.
7. WARRANTY This product is guaranteed from the date of purchase against faulty workmanship and materials for: – two years within Europe – one year outside Europe • The manufacturer will replace or repair, at its discretion, any faulty units or components returned to the Company for inspection.
