Furniture of America CM-BN1246 Assembly Instructions Manual

For more information contact our team: service.ec@foagroup.com

ASSEMBLY RATING

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

assembling a specific product (with 1 being

easy and 5 being difficult). For some

products, two persons are recommended.

EASY

Assembly Instructions

CM-BN1246

DIFFICULT

Tools Required For Assembly:

Allen Wrench

2 PERSONS RECOMMENDED

Page 1 of 6

(Included)

Rev: 18-07-17

Table of Contents

Do you have a question about the CM-BN1246 and is the answer not in the manual?

Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM-BN1246 ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being Allen Wrench easy and 5 being difficult).
Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 6pcs Bolt Ø5/16"x1-3/4" Cushion #2 x 1pc #B x 3pcs Leg Left Bolt Ø5/16"x3"...
Page 4 #A x 4pcs #C x 4pcs #D x 4pcs #E x 2pcs Insert dowels (#E) to the legs (#2,3), then align the legs (#2,3) to the cushion (#1). Secure by using bolts (#A) with washers (#C,D). Insert dowels (#E) to the cushion (#1), then align backrest (#4) to the unit.
Page 5 Secure legs (#2,3) to the backrest (#4) by using bolts (#A). #A x 2pcs Secure cushion to backrest by using bolts (#B) with washers (#C,D). #B x 3pcs #C x 3pcs #D x 3pcs Page 5 of 6...
Page 6 Insert corks (#F) to cover bolts. #F x 2pcs ASSEMBLY IS COMPLETED Page 6 of 6...
