Epoch Design SE-OS-SD-WH Assembly Instructions

P1
E D
POCH ESIGN
, LLC
Congratulations on the purchase of your Under Bed Storage Drawer. This storage drawer has been crafted to the
highest standards of quality and safety and will give you many years of enjoyment and practical use.
Because this storage drawer is composed of wood there will be variations in color and grain, and minor checking
may occur. This is normal and does not compromise the integrity of your trundle.
On this insert you will nd a list of hardware and parts necessary for assembly, as well as detailed instructions.
Assembly is quite simple and requires only a Phillips Head screwdriver. The use of a power drill with
the torque setting on low and a Phillips Head attachment is helpful but not necessary. Assembly will be most easily
accomplished if you take the time to carefully sort the hardware and familiarize yourself with the function of each piece.
If you need assistance with assembly, part replacement or any other matter, contact the Toll-Free Epoch Design
Service Center from anywhere in the Continental United States, Monday through Friday, 9AM - 5PM Paci c Standard Time
at 1-800-589-7990. You may also fax your request or comments to 425-284-0885 or email info@epochbydesign.com
and a customer service representative will respond.
8x 35mm Bolt
Used to attach front
back and end panels
1x Hex key
mm 10 20 30
1x Storage Drawer
Front Panel
1x Middle Plank Brace
HAVE QUESTIONS OR CONCERNS? CALL US FIRST: 1-800-589-7990
Under Bed Storage Drawer
5100: SE-OS-SD-WH
5102: SE-OS-SD-CO
HARDWARE LIST
6x 30mm Wood Screws
Used to attach plank braces
4x Wheels
DRAWER PARTS
1x Storage Drawer
Back Panel
2x Bottom Planks
Copyright 2018 Epoch Design™ All rights reserved
©
5101: SE-OS-SD-NB
4x Wooden Dowels
2x Drawer Divider
31-May-2018
Thank you and Enjoy
46x 20mm Screws
Used to attach attach wheels
and bottom plank
4x Wire Retainers
2x Storage Drawer
End Panel
2x Plank Brace
