P&B MPC2000+ Technical Manual page 44

Motor protection controller
Table of Contents

Advertisement

MPC2000+ Technical Manual
PIN NUMBER.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Page 40
CONNECTOR 7, 16 WAY, DIGITAL INPUTS.
SIGNAL.
SPEED SWITCH.
AUX. LIVE.
PLC CONTROL B.
PLC CONTROL A.
AUX. LIVE.
PLC RESET.
AUTHORISE KEY.
AUX. LIVE.
PLC \ SERIAL PORT.
LOCAL \ REMOTE.
AUX. LIVE.
PLANT INTERLOCK.
START B.
AUX. LIVE.
START A.
STOP.
ISSUE 7 28/9/99
TERMINAL NUMBER.
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
