MPC2000+ Technical Manual
9.7. MPC2000+ Data Display Pages
The following menus can be displayed by the Data Page Key:
Measured Data
Calculated Data
Logical Inputs/Contact Status
Statistical Data
Fault Data
Each data page provides the following displayed information:
Measured Data
Phase and Line Voltages
Phase Currents
Earth Fault Current
Channel Resistance
Power VA
Power KW
Power Factor
Calculated Data
Motor Load as a % of FLC
Thermal Capacity as a % of FLC
Time to Trip in Minutes and Seconds
Time to Start in Minutes and Seconds
Unbalance Current as a percentage
Logical Inputs/Contact Status
Drive Status
Contactor A N/O
Contactor A N/C
Contactor B N/O
Contactor B N/C
Plant Interlock
Isolator N/O
Isolator N/C
Start A Input
Start B Input
Stop Input
Local/Remote Control Status
PLC/Serial Port
PLC Control A
PLC Control B
PLC Reset
Speed Switch
Authorise Key
Emergency Stop
External Fault 2
External Fault 3
Statistical Data
Total Run Time [in steps of 1 Hours]
Total Number of Starts
Last Start Time
Last Starting Current
Number of Trips
Fault Data
Last Fault and Last Alarm
Fault currents, I1, I2, I3 Amps
Earth Fault Current
Fault voltages, V1, V2, V3 Volts
P&B Engineering
(+/- 1.0%)
(+/- 1.5%)
(+/- 1.5%)
(+/- 3.0%)
(+/- 5.0%)
(+/- 5.0%)
(+/- 1.0%)
(+/- 1.5%)
(+/- 2.0%)
(+/- 2.0%)
(+/- 2.0%)
(+/- 1.0%)
(+/- 1.5%)
(+/- 1.0%)
ISSUE 7 28/9/99
Page 25
