Anchoring the Unit
After the unit has been installed and leveled, it is rec-
ommended that it be anchored to the surrounding cabi-
netry. This will assure a secure installation.
IMPORTANT NOTE: Be sure the unit is level before
anchoring it to the surrounding cabinetry.
Anchoring Procedure:
1. Open the grille, then install anchor screws through
the grille frame clearance holes and the grill frame
support brackets into the cabinetry
22). There are several hole locations provided.
2. At the unit roller base assemblies, locate the
anchoring holes, one in each assembly. Install
anchor screws, keeping in mind that they will need
to be driven in at an angle
(See Figure 2-
(See Figure 2-23).
ANCHOR SCREWS
Figure 2-22. Anchoring at Top of Unit
ANCHOR SCREW
Figure 2-23. Anchoring at Bottom of Unit
