1 Drawer Bedside Chest
Assembly Instructions
003 xx 9500
- Please keep for future reference
Dimensions
Width - 50cm
Depth - 35.2cm
Height - 38.4cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08450613967
Please turn to back page for important information when contacting Customer Helpline.
Rev A - 22.02.10
PDF processed with CutePDF evaluation edition
www.CutePDF.com
Advertisement
Related Manuals for Addspace 003 9500 Series
Summary of Contents for Addspace 003 9500 Series
- Page 1 1 Drawer Bedside Chest Assembly Instructions 003 xx 9500 - Please keep for future reference Dimensions Width - 50cm Depth - 35.2cm Height - 38.4cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08450613967 Please turn to back page for important information when contacting Customer Helpline.
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on Check you have all the We do not the product, this could cause components and tools listed on recommend the damage.
- Page 3 Components - Panels Please check you have all the panels listed below Important - Thick lines indicate finished edges Left side Right side (32.4x32.8cm) (32.4x32.8cm) (50x35.2cm) Code - Code - Code - 7074 7072 7073 Drawer front x 1 (49.4x15.7cm) Code - 7274 Backpanel...
-
Page 4: Components - Exploded View
Components - Exploded View Important - Thick lines indicate finished edges 7074 624xx7002 5928 622xx7002 7072 7073 5846 7075 7274 623xx7002... - Page 5 If you have damaged or missing components, call the Components-Fittings Customer Helpline: 0845 0613967 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly, In some case more fittings may be supplied than are required.
- Page 6 Assembly Instructions Step 1 Fittings you will need for this step: Fitting dowels to top panel (x4) 7074 Note: Insert metal dowels as far as shown by arrows. Do not over tighten. Fittings you will need for this step: Step 2 Fitting cams to left Large hand end panel...
- Page 7 Assembly Instructions Step 4 Fittings you will need for this step: Attaching runners (x3) (x1) : Align the drawer runner with the finished edge of panel , the 2nd hole from 7073 the front will then line up with a pre-drilled hole, secure the runner to the Note: panel using screws...
- Page 8 Assembly Instructions Fittings you will need for this step: Step 5 Attaching runners (x3) (x1) : Align the drawer runner with the finished edge of panel , the 2nd hole from 7072 Note: Front finished edge the front will then line up Ensure these with a pre-drilled hole, holes are...
- Page 9 Assembly Instructions Fittings you will need for this step: Step 6 Drawer assembly (x2) 7274 Insert dowels into drawer front 7274 Note: Insert metal dowels as far as shown by arrows. Do not over tighten. Fittings you will need for this step: Small Right hand side (x2)
- Page 10 Assembly Instructions Step 6 - Continued Drawer assembly Continued... Slide drawer bottom 5846 into grooves in left,right drawer sides and drawer back. 5846 : Insert cams already inserted in left and right drawer sides onto dowels in drawer front 7274 7274 Turn cam 180 degrees to lock...
- Page 11 Assembly Instructions Step 7 Attach left hand and right hand panels to top panel Insert dowels in top 7074 into cams left and right 7072 7073 7074 end panels. 7073 Then lock. 7072 Turn cam 180 degrees to lock Fittings you will need for this step: Step 8 Attach bottom to left hand and...
- Page 12 Assembly Instructions Step 9 Turn unit over then square unit up Measure to external corners Important: Ensure a tape measure DIAG 1 is used to square up unit! Before securing the back 7072 7074 it is necessary to square up the unit. STEP 9 You can do this by DIAG 2...
- Page 13 Assembly Instructions Step 11 Fittings you will need for this step: Attach glide feet To locate feet to the bottom you will 7075 (x4) (x4) need to mark position with a bradawl 30mm in as shown, then screw the foot into place. Repeat in each corner.
- Page 14 Assembly Instructions Step 12 - continued Locate drawers helpful hints Pull sliding part of drawer runners so they are fully extended. Locate drawer onto runners. Locate screwdriver into second threaded hole in drawer runner Keeping screwdriver in place push the drawer closed.The screwdriver will push against the end panel and extend the...
- Page 15 Congratulations! your unit is complete. Note: Please turn over for important information.
- Page 16 All calls will be actioned asap. You can also e-mail your requests to us at: customer.helpdesk@addspacefl.co.uk Alternatively Write to us at: Customer Service Department, Addspace Furniture Limited, Braithwell Way, Hellaby Industrial Estate, Hellaby, Rotherham, South Yorkshire, S66 8QY.
