1 Door Corner Robe
Assembly Instructions
001 xx 4057
- Please keep for future reference
Dimensions
Width - 64.7cm
Depth - 64.7cm
Height - 179.9cm
MADE IN
GREAT BRITAIN
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Rev B - 22/01/2016
Advertisement
Related Manuals for Addspace Helsinki OA580
Summary of Contents for Addspace Helsinki OA580
- Page 1 1 Door Corner Robe Assembly Instructions 001 xx 4057 - Please keep for future reference Dimensions Width - 64.7cm Depth - 64.7cm Height - 179.9cm MADE IN GREAT BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline.
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on Check you have all the We do not the product, this could cause components and tools listed on recommend the damage.
- Page 3 Components - Panels Please check you have all the panels listed below Important - Thick lines indicate finished edges 9369 9384 9380 9381 9383 Door (168.4x32.9cm) Right End Left Back Right Back Left End (178.4x39.5cm) (178.4x63.0cm) (178.4x61.3cm) (178.4x39.5cm) 9382 Plinth (34.4x9.2cm) 740006000 9378...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly, In some case more fittings may be supplied than are required.
-
Page 5: Exploded View
Exploded View 9378 9379 9380 9381 9384 9383 9369 9379 9382... - Page 6 Assembly Instructions Step 1 Fitting cams into the back panels. Insert 16 metal cams 9381 into the right back 9380 and left back 9381 9380 Step 2 Fitting dowels to back panels. Insert 12 metal dowels 9381 into the right back and left back 9380 Note: Tighten metal...
- Page 7 Assembly Instructions Correct Step 3 Attach hinges to the door Insert hinges into holes, ensure the hinge is straight (90 degree angle). 9369 Before securing the Bradawl hinges , we recommend you pre - mark the doors using a bradawl. 9369 Secure hinges doors using screws...
- Page 8 Assembly Instructions Step 4 Fitting hingeplates, dowels and cams to the left end panel. Hingeplates can also be inserted into the right end. Insert 3 hinge plates into the left end panel 9383 9383 Ensure arrow on hingeplate points towards nished edge.
- Page 9 Assembly Instructions Step 6 Fitting cams to the bottom panels. Insert 8 cams into 9379 bottom panel 9379 Repeat on the second bottom panel. Step 7 Fitting dowels to the top panel. Insert 8 metal dowels 9378 into the top panel 9378 Step 8 Fitting back connector...
- Page 10 Assembly Instructions Step 10 Connect the bottom panels to the back panel. Connect the cams in the bottom panels 9379 the dowels in the right 9381 back panel 9379 We recommend that you build the unit on the cardboard packaging to slightly elevate the unit.
- Page 11 Assembly Instructions Step 12 Connect the left and right end panel to the back and bottom panels. Connect the cams in the 9383 9379 bottom panels the left back 9380 9379 the right back 9381 the dowels in the left end 9383 and right end 9380...
- Page 12 Assembly Instructions Step 14 Hanging door With help, slot door hinges onto hinge plates. Ensure screw on hinge slides into the slot on hingeplate. See Diagrams 1, 2 and 3. Tighten screw shown to lock hinges in position. See ‘Hinge adjustment’ page if the door needs adjusting.
- Page 13 Assembly Instructions Step 15 Hinge adjustment To move door up or down: loosen screws shown and move door to suit. Re-tighten screws. To move door in or out: loosen screw shown and move doors to suit. Re-tighten screws. To move door left or right: loosen or tighten screw as shown.
- Page 14 Assembly Instructions Step 16 Fitting the hanging rail After selecting which side you would like the hanging rail, secure the bracket with 2 screws . Secure the second bracket on the opposite panel. Fixing to wall We recommend that this unit is fixed to a suitable wall to prevent possible overbalancing.
- Page 15 All calls will be actioned asap. You can also e-mail your requests to us at: customer.helpdesk@addspacefl.co.uk Alternatively, you can write to us at: Customer Service Department, Addspace Furniture Limited, Braithwell Way, Hellaby Industrial Estate, Hellaby, Rotherham, South Yorkshire, S66 8QY.
