Sideboard
Assembly Instructions
041 xx 5500
- Please keep for future reference
Dimensions
Width - 116cm
Depth - 39cm
Height - 73cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Rev A - 31.03.15
Advertisement
Related Manuals for Addspace 041 5500 Series
Summary of Contents for Addspace 041 5500 Series
- Page 1 Sideboard Assembly Instructions 041 xx 5500 - Please keep for future reference Dimensions Width - 116cm Depth - 39cm Height - 73cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline.
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on Check you have all the We do not the product, this could cause components and tools listed on recommend the damage. - Page 3 Components - Panels Please check you have all the panels listed below Important - Thick lines indicate finished edges Right hand division Door x 2 Left hand division Rail x 4 (65x35cm) (48.4x38.4cm) (65x35cm) (65x18.8cm) Code - Code - 7010 7499 Code - 7502 Code -...
-
Page 4: Components - Exploded View
Components - Exploded View Important - Thick lines indicate finished edges 7500 7502 7504 7502 7498 7506 7502 7504 7503 7499 7398 7504 7010 7504 7010 622xx7002 7501 624xx7007 7502 623xx7002 7019 7505... - Page 5 If you have damaged or missing components, call the Components-Fittings Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly, In some case more fittings may be supplied than are required.
- Page 6 Assembly Instructions Step 1 Fittings you will need for this step: Fitting dowels to top panel (x12) 7500 Note: Insert metal dowels as far as shown by arrows. Do not over tighten. Step 2 Fittings you will need for this step: Fitting cams to Large shelves...
- Page 7 Assembly Instructions Step 4 Fittings you will need for this step: Fitting hingeplates to left hand division (x2) 7498 Notch in Hingeplate points towards edge. Step 5 Fittings you will need for this step: Fitting hingeplates to right hand division (x2) 7499 Notch in Hingeplate points...
- Page 8 Assembly Instructions Step 7 Fittings you will need for this step: Attaching runners (x3) (x1) : Align the drawer runner with the 7498 edge of panel the 2nd hole from the front will then line up Note: with a pre-drilled hole, Ensure these secure the runner to the holes are...
- Page 9 Assembly Instructions Fittings you will need for this step: Step 8 Attaching runners (x3) (x1) Align the drawer runner with the 7499 edge of panel the 2nd hole from the front will then line up with a pre-drilled hole, secure the runner to the panel using screws 7499 Note:...
- Page 10 Assembly Instructions Step 9 Fittings you will need for this step: Attach hinges and handles to doors (x8) (x2) (x4) (x4) Important: Insert hinges into holes, ensure the hinge is straight (90 degree angle). 7010x2 Before securing the 7010x2 hinges , we recommend you pre - mark the doors using a bradawl.
- Page 11 Assembly Instructions Step 10 Fittings you will need for this step: Drawer assembly (x2) 7505 Insert dowels into 7505 drawer fronts Note: Insert metal dowels as far as shown by arrows. Do not over tighten. Fittings you will need for this step: Small Right hand side (x2)
- Page 12 Assembly Instructions Step 10 - Fittings you will need for this step: Continued Drawer assembly Continued... (x1) Using glue put a few drops into grooves in drawer sides and back. Slide drawer bottom 7019 into grooves in left,right drawer sides 7019 and drawer back.
- Page 13 Assembly Instructions Step 11 Attach left and right hand divisions to shelf Locate cams in shelf 7503 onto dowels 7499 left 7498 and right hand divisions. Then lock. 7499 7503 7498 Turn cam 180 degrees to lock Step 12 Attach left and right hand divisions to top panel Locate cams...
- Page 14 Assembly Instructions Step 13 Locate shelves to rails Ensure cam holes to Locate cams in shelves top. 7504 onto dowels 7502 7502 in rails Then lock. 7504 7504 7502 7502 7504 Turn cam 180 degrees to lock 7504 7502 Step 14 Attach rails to top panel 7502...
- Page 15 Assembly Instructions Step 15 Locate backpanels into grooves in left and right hand end divisions 7506 FOIL FACE 7506 Locate backpanel into grooves in left hand 7498 7498 and right hand 7499 slide the 7506 backpanel all the way down to the top 7499 panel.
- Page 16 Assembly Instructions Fittings you will need for this step: Step 17 Attach feet To locate feet to the bottom you will 7501 (x10) (x5) need to mark position with a bradawl 15mm PLEASE NOTE: BOTTOM PANEL and 38mm in as shown, EDGED IN SILVER.
- Page 17 Assembly Instructions Step 18 continued Locate drawers helpful hints Pull sliding part of drawer runners so they are fully extended. Locate drawer onto runners. Locate screwdriver into second threaded hole in drawer runner Keeping screwdriver in place push the drawer in until the screwdriver pushes against the 2nd Hole...
- Page 18 Assembly Instructions Step 19 Hanging doors With help, slot door hinges onto hinge plates Ensure screw on hinge slides into the slot 7010 on hingeplate See Diagrams 1,2 and 3. Tighten screw shown to lock hinges in position. Repeat a and b for opposite door.
- Page 19 Assembly Instructions Step 20 Hinge adjustment To move doors up or down: loosen screws shown and move doors to suit. Re-tighten screws. To move doors in or out: loosen screw shown and move doors to suit. Re-tighten screws. To move doors left or right: loosen or tighten screw as shown Be careful not to fully...
- Page 20 All calls will be actioned asap. You can also e-mail your requests to us at: customer.helpdesk@addspacefl.co.uk Alternatively Write to us at: Customer Service Department, Addspace Furniture Limited, Braithwell Way, Hellaby Industrial Estate, Hellaby, Rotherham, South Yorkshire, S66 8QY.
