Occasional table
Assembly Instructions
051 xx 0510
- Please keep for future reference
Dimensions
Width - 98cm
Depth - 49cm
Height - 33.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Rev A - 03.06.10
Advertisement
Related Manuals for Addspace 051 0510 Series
Summary of Contents for Addspace 051 0510 Series
- Page 1 Occasional table Assembly Instructions 051 xx 0510 - Please keep for future reference Dimensions Width - 98cm Depth - 49cm Height - 33.5cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline.
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on Check you have all the We do not the product, this could cause components and tools listed on recommend the damage.
- Page 3 Components - Panels Please check you have all the panels listed below Important - Thick lines indicate finished edges End panel x 2 Rail x 2 Rail x 2 (32x41.4cm) (32x10.2cm) (32x10.2cm) Code - 7558 Code - 7611 Code - 7557 Bottom (93x41.4cm) (98x49cm)
-
Page 4: Components - Exploded View
Components - Exploded View Important - Thick lines indicate finished edges 7555 7557 7611 7558 7611 7559 7556 7558 7557... - Page 5 If you have damaged or missing components, call the Components-Fittings Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly, In some case more fittings may be supplied than are required.
- Page 6 Assembly Instructions Fittings you will need for this step: Step 1 Fitting dowels to top panel (x8) 7555 Note: Insert metal dowels as far as shown by arrows. Do not over tighten. Step 2 Fittings you will need for this step: Fitting cams to Large bottom panel...
- Page 7 Assembly Instructions Fittings you will need for this step: Step 4 Fitting dowels to end panels (x6) 7558 x2 Note: Insert metal dowels as far as shown by arrows. Do not over tighten. Step 5 Fittings you will need for this step: Fitting cams to rails Large (x4)
- Page 8 Assembly Instructions Fittings you will need for this step: Step 7 Fitting cams to Large plinth (x2) Note: Ensure cam arrow points towards the edge with hole. 7559 Fittings you will need for this step: Step 8 Fitting wooden dowels to plinth (x2) Use a hammer to...
- Page 9 Assembly Instructions Step 9 7558 Attach end panel to bottom panel Locate dowels 7558 end panel into cams in bottom 7556 Then lock. 7556 Turn cam 180 degrees to lock Step 10 Attach plinth to end panel 7558 Warning: 2 people required.
- Page 10 Assembly Instructions Step 11 Attach end to bottom and plinth panels Locate dowels 7558 end panel into cams in bottom 7559 7556 and plinth Ensure wooden 7559 dowel already inserted 7559 into plinth goes into hole in end panel 7556 7558 Then lock.
- Page 11 Assembly Instructions Step 13 Turn unit over so 7557 it is positioned as shown then locate rails to end panels Locate dowels 7557 rails 7611 7558 into cams in ends 7558 7611 Ensure the four cams are tightened. 7558 Ensure spare cams are to this end.
