4 Drawer 2 Door Sideboard Assembly Instructions 041 xx 5527 - Please keep for future reference Dimensions Width - 114.6cm Depth - 38.8cm Height - 73.5cm MADE IN GREAT BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline.
Page 2
Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on Check you have all the We do not the product, this could cause components and tools listed on recommend the damage.
Page 3
Components - Panels Please check you have all the panels listed below Important - Thick lines indicate finished edges 8865 (114.6x38.8cm) 8873 Shelf x2 (36x36.9cm) 8867 8868 Left End Right End (72x38.6cm) (72x38.6cm) 0711 8866 Bottom (111.2x36.9cm) Drawer Front x4 (37.2x15.7cm) 8825 Plinth...
Page 4
If you have damaged or missing components, call the Components - Fittings Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly, In some case more fittings may be supplied than are required.
Page 6
Assembly Instructions Step 1 Fitting dowels to top panel. Insert 8 metal dowels into the top panel 8865 Note: Tighten metal 8865 dowels up fully against the panel. Do not over tighten. Step 2 Fitting cams to the plinth panel. Insert 4 cams into the plinth panel...
Page 7
Assembly Instructions Step 5 Right hand side 623xx7002 Insert small cams 622xx7002 into left and right 623xx7002 drawer sides. Left hand side 622xx7002 Drawer assembly cont. Left hand side 622xx7002 Drawer Back Insert wooden dowels 624xx7004 in drawer back 624xx7004 into holes in left 622xx7002...
Page 8
Assembly Instructions Correct Step 6 Attach hinges and handles to 2 doors Incorrect Insert hinges into holes, ensure the hinge is straight 0712 (90 degree angle). Bradawl Before securing the hinges , we recommend you pre - mark the doors 0712 using a bradawl.
Page 9
Assembly Instructions Step 7 Fitting cams to the bottom panel. Insert 4 cams into the bottom panel 8866 8866 Step 5 Step 8 Fitting dowels, cams and hingesplates to the end panels. Insert 6 metal dowels and 2 cams into the left hand end panel 8867 .
Page 10
Assembly Instructions Step 9 Attaching fittings to left division panel. Step 1 a: Insert 2 cams 8869 the division 8869 Position the runner so that the second hole from the front of the runner lines up with the pre-drilled hole nearest to the grooved edge of the panel.
Page 11
Assembly Instructions Step 11 Assembly: Finished edges to the floor. Connecting the plinth, shelf and bottom to the left end panel. Connect the cams in the 8825 plinth , the bottom 8867 8866 and the shelf to the left end 8873 8873 panel...
Page 12
Assembly Instructions Step 13 Connect the remaining shelf panel to the right division panel. Insert the cams in the shelf panel 8873 to the dowels in the right division panel 8870 8870 Turn cams 180 degrees to lock. 8873 Step 14 Connecting the plinth, shelf and bottom to the right end panel.
Page 13
Assembly Instructions Step 15 Connect the top panel to the end and division panels. 8865 Insert the dowels in the 8865 top panel into the 8867 cams in the left end panel 8867 , the right end panel , the left 8868 8869 division panel...
Page 14
Assembly Instructions Step 17 Plain chipboard surface Attach the backpanel Use the panel pin guide when locating the panel pins. This will hold the panel pins vertical and 8874 ensure the correct distance from the edge. Step 18 8867 Fitting doors With help, slot door hinges onto hinge plates.
Page 15
Assembly Instructions Step 19 Hinge adjustment To move doors up or down: loosen screws shown and move doors to suit. Re-tighten screws. To move doors in or out: loosen screw shown and move doors to suit. Re-tighten screws. To move doors left or right: loosen or tighten screw as shown.
Page 16
Assembly Instructions Step 20 Fit the drawers. For this step we recommend you follow the helpful hints on the next page. Repeat this process on all drawers. 2nd Hole 0711...
Page 17
Assembly Instructions Step 21 Locate drawers helpful hints Pull sliding part of drawer runners so they are fully extended. Locate drawer onto runners. Locate screwdriver into second threaded hole in drawer runner Keeping screwdriver in place push the drawer in until the screwdriver pushes against the 2nd Hole panel.
Page 18
Assembly Instructions Step 22 Fixing to wall We recommend that this unit is fixed to a suitable wall to prevent possible overbalancing. We have included a fixing bracket for this. No fixing screws are provided as they will need to suit the wall type, and the length of screw will depend on the distance from the...
Page 19
All calls will be actioned asap. You can also e-mail your requests to us at: customer.helpdesk@addspacefl.co.uk Alternatively, you can write to us at: Customer Service Department, Addspace Furniture Limited, Braithwell Way, Hellaby Industrial Estate, Hellaby, Rotherham, South Yorkshire, S66 8QY.
