1 Drawer Occasional Table
Assembly Instructions
051 xx 6001
- Please keep for future reference
482/4536
Dimensions
Width - 84.6cm
Depth - 38.8cm
Height - 40.0cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Rev A - 01/10/15
Advertisement
Related Manuals for Addspace 482/4536
Summary of Contents for Addspace 482/4536
- Page 1 1 Drawer Occasional Table Assembly Instructions 051 xx 6001 - Please keep for future reference 482/4536 Dimensions Width - 84.6cm Depth - 38.8cm Height - 40.0cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline.
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on Check you have all the We do not the product, this could cause components and tools listed on recommend the damage.
- Page 3 Components - Panels Please check you have all the panels listed below Important - Thick lines indicate finished edges 0024 0025 Bottom (84.6x38.8cm) (77.6x34.4cm) 0026 End Panel x 2 (38.4x37.6m) 0029 Plinth (77.6x76cm) 0028 Back Rail (77.6x15.6cm) 684xx6520 0030 Trim x 4 Draw Front (384x30x12cm) (77.2x15.7cm)
- Page 4 If you have damaged or missing components, call the Components-Fittings Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly, In some case more fittings may be supplied than are required.
-
Page 5: Exploded View
Exploded View 684xx6520 0024 0028 0026 0025 0026 0029 684xx6520 622xx7002 624xx7007 623xx7002 7019 0030... - Page 6 Assembly Instructions Fittings you will need for this step: Step 1 Fitting dowels to top panel. 0024 Note: Insert metal dowels as far as shown by arrows. Do not over tighten. Step 2 Fittings you will need for this step: Fitting cams to the bottom panel 0025...
- Page 7 Assembly Instructions Step 4 Attaching runners to end panels Important :- Lay end panels out as shown Position the runner so that the second hole 0026 from the front of the runner lines up with the pre-drilled hole nearest to the edge of the panel. Use screws to secure the runner.
- Page 8 Assembly Instructions Step 5 Fitting cams & dowels to the end panels. 0026 Note: Ensure cam arrow points towards 0026 the edge with hole. Note: Insert metal dowels as far as shown by arrows. Do not over tighten.
- Page 9 Assembly Instructions Step 6 Small Drawer assembly 0030 Insert dowels into 0030 drawer fronts Note: Insert metal dowels as far as shown by arrows. Do not over tighten. Fittings you will need for this step: Right hand side 623xx7002 Insert small cams 622xx7002 into left and right...
- Page 10 Assembly Instructions Step 6 - Continued Drawer assembly Continued... Using glue put a few drops into grooves in drawer sides and back. Slide drawer bottom 7019 into grooves in left,right drawer sides 7019 and drawer back. Ensure foil on the FOIL FACE drawer bottom is facing upwards.
- Page 11 Assembly Instructions Step 7 Connect end panel to back rail. Connect the dowels in 0026 the end panel into the cams in the 0028 back rail 0028 Turn cams 180° to lock. 0026 Step 8 Connect end panel to bottom. Connect the dowels in the end panel 0026...
- Page 12 Assembly Instructions Step 9 Connect end panel to plinth. Cams to back of unit Connect the dowels in 0026 the end panel into the cams in the 0029 plinth Turn cams 180° to lock. Ensure plinth sits flush. 0029 Ensure plinth is not overhanging.
- Page 13 Assembly Instructions Step 11 Connect end panels to top. Stand unit upright. Warning: May require 0024 2 people Connect the dowels in 0024 0026 the top panel into the cams in the 0026 end panels Turn cams 180° to lock. 0026 Step 12 Attach silver trims...
- Page 14 Assembly Instructions Step 13 Lift unit up and locate drawer Warning: May require 2 people For this step we recommend you follow the helpful hints page. Detailed View 2nd Hole...
- Page 15 Assembly Instructions Step 14 Locate drawers helpful hints Pull sliding part of drawer runners so they are fully extended. Locate drawer onto runners. Locate screwdriver into second threaded hole in drawer runner Keeping screwdriver in place push the drawer in until the screwdriver pushes against the 2nd Hole panel.
- Page 16 All calls will be actioned asap. You can also e-mail your requests to us at: customer.helpdesk@addspacefl.co.uk Alternatively, you can write to us at: Customer Service Department, Addspace Furniture Limited, Braithwell Way, Hellaby Industrial Estate, Hellaby, Rotherham, South Yorkshire, S66 8QY.
