- Page 1 USER GUIDE BURGER MACHINE GGM GASTRO INTERNATIONAL GMBH WEİNERPARK 16 – 48607 OCHTRUP (0) 2553 / 7220 0 – FAX: +49 (0) 2553 7220 200 TEL:+49 www.ggmgastro.com – info@ggmgastro.com...
-
Page 2: Table Of Contents
CONTENTS A – GENERAL INFORMATION Page 3 A1 – PRODUCT DESCRIPTION Page 4 A2 – TECHINICAL INFORMATION Page 4 A3 – TRANSPORTATION AND STORAGE CONDITIONS Page 4 A4 – UNPACKING Page 5 B – INSTALLATION Page 5 C – SAFETY INSTRUCTIONS Page 6 D –... -
Page 3: A - General Information
A – GENERAL INFORMATION READ CAREFULLY ALL INSTRUCTIONS AND WARNINGS IN THIS USER MANUAL. THIS MANUAL CONTAINS IMPORTANT INFORMATION ABOUT THE SAFE INSTALLATION, USE AND MAINTENANCE OF YOUR PRODUCT AND NECESSARY WARNINGS FOR YOU TO USE THE MOST USEFUL FROM YOUR DEVICE. KEEP THIS MANUAL IN A SAFE AND EASY REACH FOR FUTURE USE. -
Page 4: A1 - Product Description
A1 – PRODUCT DESCRIPTION This appliance is a burger machine designed for use in industrial kitchens and recommended for use by professional users. A2 – TECHINICAL INFORMATION Product Code GGM-BRG01-E15-0001 Dimensions (mm) 400x810x500 Weight (kg) Gross Dimensions (mm) 450x830x640 Gross Weight (kg) Electric Input (V) Cable (mm²) -
Page 5: A4 - Unpacking
A4 – UNPAKING - Please unpack the package according to the security codes and ordinances of current country and get rid from the pack. Parts which contacts with food are produced by stainless steel. All plastic parts are marked by material’s symbol. - Please check that all parts of appliance had come completely and if they are damaged or not during the shipping. -
Page 6: C - Safety Instructions
- No control circuit should be connected to the supply line of the device. Cables that carry the sensor and input signals to the device should be carried as far as possible and separately from the supply, control, switched inductive load cables and they should be prevented from being affected. -
Page 7: D - Operation Information
D – OPERATION INFORMATION It should payed attention to warnings as below: When the device is energized, no button should be touched until the ON / OFF button lights up. Information about the touch type is given in figure 1 above. Figure 1: Touch Alerts... - Page 8 Figure 2: Control Paneel If P1 stage is selected while the device is on, RL1 gives an output for a preset of 10 seconds. Press button to change the duration of P1 step. Hold buttons to change. For registration keep button pressed.
- Page 9 If P4 stage is selected while the device is on, RL1 gives an output for a preset of 40 seconds. Press button to change the duration of P4 step. Hold buttons to change. For registration keep button pressed . If P5 stage is selected while the device is on, RL1 gives an output for a preset of 50 seconds.
-
Page 10: E - Cleaning And Maintenance
E – CLEANING AND MAINTENANCE Cleaning and maintenance after every use; Make sure that the plug is not plugged in or the switch is turned off while cleaning the device. Clean the surface of the device after each use. ... -
Page 11: F - Troubleshooting
F – TROUBLESHOOTING PROBLEM REASON HOW TO REMOVE The device may not be - Check the electrical connection. THE APPLIANCE receiving electricity. DOESN’T - Check the fuse box Circuit breaker may not be OPERATE connection. open. The device may stop due to DEVICE STOPPED - Check the voltage. -
Page 12: G - Exploding Drawing And Spare Part List
G – EXPLODING DRAWING AND SPARE PART LIST... - Page 13 G – EXPLODING DRAWING AND SPARE PART LIST BURGER MACHINE PART NAME P.CODE BASE FRAME OMK-YP-00028 BUTTON BUFFER RED LED OMK-YP-00029 SWITCH OMK-YP-00045 PLASTIC OMK-YP-00057 FEET OMK-YP-00058 ENERGY INPUT OMK-YP-00059 BUTTON APPARAT OMK-YP-00067 BUTTON OMK-YP-00088 MAGNET OMK-YP-00165 THERMOSTAT OMK-YP-00195 BUTTON BUFFER OMK-YP-00196 SWITCH OMK-YP-00285...
-
Page 14: H - Electrical Circuit Diagram
H – ELECTRICAL CIRCUIT DIAGRAM LID SWITCH BOTTOM THERMOSTAT TOP THERMOSTAT MAGNET DIODE BOTTOM THERMOSTAT SIGNAL LAMP TOP THERMOSTAT SIGNAL LAMP BOTTOM RESISTANCE GROUP 2X1500 W TOP RESISTANCE GROUP 2X1500 W...
