PREMIUM STRINGER 9200 User Manual page 8

3. PRE-STRETCH Selection Key :
To select the desired pre-stretch pulling over tension setting
and releasing the string to the tension setting,
press "PRE-STRETCH" key and
screen will be changed into pre-stretch mode.
Each press of the key toggles between 0%, 10% & 20%.
To get back to the main screen mode, press one of the "KNOT",
"MAIN" or "CROSS" key. The selected pre-stretch value
will be abbreviated into 1 (10%), 2 (20%) or 0 (no pre-stretch)
on the screen.
4. Memory Key :
M
To store the desired tension, press "M" key.
(If you don't press "M" key for storing the new tension setting,
you may wait for 3 seconds until a beep sound is alarmed which
means the machine has automatically memorized the new tension
setting value.)
5. Clear Key :
C
To go back to the previous tension setting, press "C" key.
It is only available before the present new tension setting is stored.
6.
+ 1.0 + 0.1
- 1.0 - 0.1
7. Start Pulling Key :
To start pulling the string, press "START" key.
(You may also pull the string by pressing the green
tensioning switch next to the string gripper directly.)
8. Reversing Key :
To release the string, press "R" key.
(You may also release the string by pressing the green
tensioning switch next to the string gripper directly.)
Tension Index Keys :
Change the tension setting in +/-1.0 or 0.1 Lb or Kg
increments. Holding the keys down will scroll the
tension setting values up or down.
8
