Control Panel - PREMIUM STRINGER 9200 User Manual

1. KG/LB Conversion Key :
KG/LB
To change the tension display from Lbs to Kgs,
press the "KG/LB" key and then
"KG" or "LB" will be displayed on the screen.
Each press of the key toggles between Lbs and Kgs.
2. SPEED Selection Key :
SPEED
To select the desired string pulling speed, press the "SPEED" key
and screen will be changed into the speed mode.
Each press of the key toggles between
HI SPEED, MID SPEED & LOW SPEED.
To get back to the main screen mode,
press one of the "KNOT", "MAIN" or "CROSS" key
and the selected speed will be abbreviated into
H (HIGH SEED), M (MID SPEED) or L (LOW SPEED)
on the screen.

CONTROL PANEL

Screen :
Hi / Mid / Low Speed
7
H 0 Main 4.5 KG
10%/20% / 0% Pre-Stretch
Main/Cross/Knot String
Tension
KGS/LBS
