ASSEMBLY INSTRUCTIONS
Quadro Loop
4P workstation
Sizes: 1200, 1400, 1600, 1800 mm
STEP 04
Attach beam (E) to legs (B) and Connector frame (D)
using nut insert in legs. See point attached
TOP VIEW
www.jasonl.com.au
Need help!
Call us on
1300 527 665
STEP 05
G
G
Frame looks like this. Using Allen Key, attach beam (E) with Socket (G)
G
G
G
G
G
G
