- Page 1 SYSTEMS CORP. Version:1.0 Total 16 Pages (Cover Page included)
-
Page 2: Revision History
ervice SW-HF2.1 3000 uide Revision History Version Date Changes Official Release 1．0 Version: 1.0 Page 1/15... -
Page 3: Table Of Contents
ervice SW-HF2.1 3000 uide Table of Contents Revision History ……………………………………………………………………..1 Table of Contents………………………………………………… ………….2 Getting Started………………………………………………… ……….……………..3 Conventions Used in this Guide………………… ………...……………….3 Safety Precautions……………………………… ………………...………..3 Chapter1. How to Handle Defective Returns………………… ……………………….4 1.1 Overview……………………………………………………………….4 1.2 Problems………………………………………………………………..5 1.2.1 Power LED (indicator) Unlighted………………...……………..6 1.2.2 Does not work or one channel no sound……………………….…..7 1.2.3 Noise……………………………………………………………….7 Chapter2. -
Page 4: Getting Started
ervice SW-HF2.1 3000 uide Getting Started Conventions Used in this Guide Pay Special Attention: Instructions that are important to remember and may prevent mistakes. Attention Caution: Information that, if not followed, may result in damage to the product. Safety Precautions The following precautions should be observed in handling the speaker described in this guide: Place the speakers on a flat level and stable surface. -
Page 5: Chapter1. How To Handle Defective Returns
ervice SW-HF2.1 3000 uide Chapter 1. How to Handle Defective Returns 1.1 Overview Receiving Defective Speakers from Customers Verifying problems& Proceeding necessary tests Functioning NG Analyzing possible Malfunction causes Deciding & proceeding Functioning OK the rectification methods Functioning NG Replacing necessary Defective parts Proceeding tests To verify if the speaker is... -
Page 6: Problems
ervice SW-HF2.1 3000 uide 1.2 Problems Item Problem descriptions 1.2.1 Power LED (indicator) unlighted 1.2.2 Does not work or one channel no sound 1.2.3 Noise Version: 1.0 Page 5/15... -
Page 7: Power Led (Indicator) Unlighted
ervice SW-HF2.1 3000 uide Please follow the numbered sequence marked within parenthesis given in individual Flow chart, in that this is the best-recommended sequence to rectify the problems. Attention 1.2.1 Power LED (indicator) unlighted Problem Power LED （indicator）unlighted Analyze Secondary wire Of CheckD1.2 Check Defective power... -
Page 8: Does Not Work Or One Channel No Sound
ervice SW-HF2.1 3000 uide 1.2.2 Does not work or one channel no sound Problem Does not work or One channel no sound Analyze and Defective Broken or Defective IC Identify the Audio cable Short circuit (TDA2030A) Causes Replace Check solder Solutions Check and replace Audio cable... -
Page 9: Chapter2. Specifications
ervice SW-HF2.1 3000 uide Chapter 2. Specifications Satellite NOMINAL LIMIT No DESCRIPTION UNIT ≥19 FRONT OUTPUT POWER @THD 10% ±50 SENSITIVITY（1KHz）@RATED O/P POWER ±20 SENSITIVITY(1KHz)@1W O/P POWER ±40 MAX INPUT LEVEL@1% FREQUENCY RESPONSE(1KHz=0dB) ±1 120Hz ±0.5 ±1 ≥70 S/N @RATED O/P POWER ≤0.5 CHANNEL UNBALANCE @REF O/P POWER... -
Page 10: Chapter3. Block Diagram
ervice SW-HF2.1 3000 uide Chapter 3. Block Diagram Version: 1.0 Page 9/15... -
Page 11: Chapter4. Exploded View
ervice SW-HF2.1 3000 uide Chapter 4. Exploded View Subwoofer Version: 1.0 Page 10/15... - Page 12 ervice SW-HF2.1 3000 uide Chapter 4. Exploded View SATELLITE Version: 1.0 Page 11/15...
-
Page 13: Chapter5. Part List
ervice SW-HF2.1 3000 uide Chapter 5. Part List Subwoofer Description Ref. No. RS Part No. Part No. Knob,HIPS Silver Color 026900958 FRONT COVER HIPS, Silver Color 026300708 Speaker 6.5" 8Ω 40W 010403038 Screw BAΦ3.5x16 , zincification Black Color 017903268 Frame HIPS Φ218xD15 020002048 Wood-box, 12T MDF 035201978... - Page 14 ervice SW-HF2.1 3000 uide Chapter 5. Part List Satellite Description Ref. No. RS Part No. Part No. Frame HIPS 128*225*6 020002058 Screw BAΦ3.0x12 , zincification Black Color 017903258 Speaker 4"4Ω 20W 010403058 Screw BAΦ3.0x12 , zincification Black Color 017903258 Speaker 1″4Ω10W 010403028 Wood-box, 9T MDF 035301658...
-
Page 15: Chapter6. Important Notes
ervice SW-HF2.1 3000 uide Chapter 6. Important Notes 6.1 Packing requirement for sending the PCB assembly by post PCB assembly is a kind of sophisticated electronic circuit board. Well packing Will be required when sending them by post. *Some sophisticated IC components are mounted on the PCB assembly, hence it is necessary to pack each PCB assembly with a separate static protecting bag, in order to avoid static electricity. -
Page 16: Chapter7. Circuit Schematic
ervice SW-HF2.1 3000 uide Chapter 7. Schematic Diagram -9.1V +9.1V Version: 1.0 Page 15/15...
