Summary of Contents for KYE Systems Corp. Genius SW-5.1 3005
- Page 1 Service Guide SW-5.1 3005 SERVICE GUIDE KYE SYSTEMS CORP. SW-5.1 3005 Version : 1.0 Page 1 of 17...
- Page 2 Service Guide SW-5.1 3005 Revision History Version Date Change 1/19/2009 Version : 1.0 Page 2 of 17...
-
Page 3: Table Of Contents
Service Guide SW-5.1 3005 Table of Contents Revision History …………………………………………………………………….2 Table of Contents ……………………………………………………………………3 Getting Started ………………………………………………………………………4 Conventions Used in this Guide ……………………………………….4 Safety Precautions ……………………………………………………..4 Chapter 1. How to Handle Defective Returns……………………………………..5 1.1 Overview …………………………………………………………..5 1.2 Problems …………………………………………………………...6 1.2.1 One or more channels no sound ………………..…7 1.2.2 Power LED (indicator) no light………………..…8 1.2.3 Volume , Bass no function...……..……….………..8 Chapter 2. -
Page 4: Getting Started
Service Guide SW-5.1 3005 Getting Started Conventions Used in this Guide Pay Special Attention : Instructions that are important to remember and may prevent mistakes . Caution : Information that, if not followed, may result in damage to the product . Safety Precautions The following precautions should be observed in handling the speaker Described in this guide :... -
Page 5: Chapter 1. How To Handle Defective Returns
Service Guide SW-5.1 3005 Chapter 1. How to Handle Defective Returns 1.1 Overview Receiving Defective speakers from Customers Verifying problems Proceeding necessary tests Function NG Analyzing possible malfunction causes Deciding & proceeding the Function NG rectification methods Function OK Replace necessary defective parts Proceeding tests to Verify if the speaker is functioning normally... -
Page 6: Problems
Service Guide SW-5.1 3005 1.2 Problems Item Problem Description 1.2.1 One or more channels no sound 1.2.2 Power LED (indicator) no light 1.2.3 Volume , Bass no function Version : 1.0 Page 6 of 17... - Page 7 Service Guide SW-5.1 3005 Attention Please follow the numbered sequence marked within parenthesis given in individual Flow chat, in that this is the best-recommended sequence to rectify the problems. 1.2.1 One or more channels no sound One or more channels no sound Problem Analyzer and Defective...
- Page 8 Service Guide SW-5.1 3005 1.2.2 Power LED (indicator) no light Power LED (indicator) no light Problem Defective D81~D84, Power switch or LED AC cord of transformer Analyzer and POWER , R8 , LED defective disconnected or defective Identify the Causes Re-solder or replace defective component(s) Solutions...
-
Page 9: Chapter 2. Specifications
Service Guide SW-5.1 3005 Chapter 2. Specifications Woofer NO. Description Unit Specifications ≧ 25 Out Power at THD 10% 130 ± 30 Sensitivity 20 ~ 166 ± 10% Freq. Response (Top -3dB) ≧ 70 S/N ratio ≦ 2 Hum & Noise (Vol.: max) Center NO. -
Page 10: Chapter 3. Block Diagram
Service Guide SW-5.1 3005 Chapter 3. Block Diagram AUDIO IN FR,FL. Satellite SR,SL. Satellite Power Volume Amplifier Control Center Woofer Woofer Volume FILTER Transformer & AC IN Rectifier Version : 1.0 Page 10 of 17... -
Page 11: Chapter 4. Exploded View
Service Guide SW-5.1 3005 Chapter 4. Exploded View Woofer Version : 1.0 Page 11 of 17... - Page 12 Service Guide SW-5.1 3005 Satellite Version : 1.0 Page 12 of 17...
-
Page 13: Chapter 5. Part List
Service Guide SW-5.1 3005 Chapter 5. Part List DESCRIPTION UNIT Part No. 1 SW-5.1 3005/Body/Satellite-FL 26-101-01 2 SW-5.1 3005/Body/Satellite-FR 26-101-02 3 SW-5.1 3005/Body/Satellite-SL 26-101-03 4 SW-5.1 3005/Body/Satellite-SR 26-101-04 5 SW-5.1 3005/Body/Satellite-Center 26-101-05 6 Loud speaker-front, 3” 4 ohm 10W E1049-36 7 Loud speaker-surround, 3”... -
Page 14: Chapter 6. Schematic Diagram
Service Guide SW-5.1 3005 27 Carton, SW-5.1 3005 12100298100-A Chapter 6. Schematic Diagram Version : 1.0 Page 14 of 17... - Page 15 Service Guide SW-5.1 3005 Version : 1.0 Page 15 of 17...
- Page 16 Service Guide SW-5.1 3005 Version : 1.0 Page 16 of 17...
-
Page 17: Chapter 7. Important Notes
Service Guide SW-5.1 3005 Chapter 7. Important Notes 7.1 Packing Requirement for Sending the PCB Assembly by Post PCB assembly is a kind of sophisticated electronic circuit board. Well packing will be required when sending them by post. * Some sophisticated IC components are mounted on the PCB assembly, hence it is necessary to pack each PCB assembly with a separate static protecting bag, in order to avoid static electricity.
