- Page 1 Service Guide SW-5.1 1505 SERVICE GUIDE KYE SYSTEMS CORP. SW-5.1 1505 Version : 1.0 Page 1 of 17...
-
Page 2: Revision History
Service Guide SW-5.1 1505 Revision History Version Date Change 6/24/2009 Version : 1.0 Page 2 of 17... -
Page 3: Table Of Contents
Service Guide SW-5.1 1505 Table of Contents Revision History …………………………………………………………………….2 Table of Contents ……………………………………………………………………3 Getting Started ………………………………………………………………………4 Conventions Used in this Guide ……………………………………….4 Safety Precautions ……………………………………………………..4 Chapter 1. How to Handle Defective Returns……………………………………..5 1.1 Overview …………………………………………………………..5 1.2 Problems …………………………………………………………...6 1.2.1 One or more channels no sound ………………..…7 1.2.2 Wired Control no function..……………………..…7 1.2.3 Power LED (indicator) no light………………..…8 1.2.4 Volume , Bass no function...……..……….………..8... -
Page 4: Getting Started
Service Guide SW-5.1 1505 Getting Started Conventions Used in this Guide Pay Special Attention : Instructions that are important to remember and may prevent mistakes . Caution : Information that, if not followed, may result in damage to the product . Safety Precautions The following precautions should be observed in handling the speaker Described in this guide :... -
Page 5: Chapter 1. How To Handle Defective Returns
Service Guide SW-5.1 1505 Chapter 1. How to Handle Defective Returns 1.1 Overview Receiving Defective speakers from Customers Verifying problems Proceeding necessary tests Function NG Analyzing possible malfunction causes Deciding & proceeding the Function NG rectification methods Function OK Replace necessary defective parts Proceeding tests to Verify if the speaker is functioning normally... -
Page 6: Problems
Service Guide SW-5.1 1505 1.2 Problems Item Problem Description 1.2.1 One or more channels no sound 1.2.2 Wired Control no function 1.2.3 Power LED (indicator) no light 1.2.4 Volume , Bass no function Version : 1.0 Page 6 of 17... -
Page 7: One Or More Channels No Sound
Service Guide SW-5.1 1505 Attention Please follow the numbered sequence marked within parenthesis given in individual Flow chat, in that this is the best-recommended sequence to rectify the problems. 1.2.1 One or more channels no sound 1.2.1 One or more channels no sound One or more channels no sound Problem Analyzer and... -
Page 8: Power Led (Indicator) No Light
Service Guide SW-5.1 1505 1.2.3 Power LED (indicator) no light Power LED (indicator) no light Problem Defective D2~D5 Power switch or LED AC cord of transformer Analyzer and POWER , R2 , LED defective disconnected or defective wired control cable Identify the Causes Re-solder or replace defective component(s) -
Page 9: Chapter 2. Specifications
Service Guide SW-5.1 1505 Chapter 2. Specifications Woofer NO. Description Unit Specifications ≧ 17 Out Power at THD 10% 130 ± 30 Sensitivity 30 ~ 150 ± 10% Freq. Response (Top -3dB) ≧ 70 S/N ratio ≦ 2 Hum & Noise (Vol.: max) Center NO. -
Page 10: Chapter 3. Block Diagram
Service Guide SW-5.1 1505 Chapter 3. Block Diagram AUDIO IN FR,FL. Satellite Wired Control Box SR,SL. Satellite Power Volume Amplifier Control Center Woofer Woofer Volume FILTER Transformer & AC IN Rectifier Version : 1.0 Page 10 of 17... -
Page 11: Chapter 4. Exploded View
Service Guide SW-5.1 1505 Chapter 4. Exploded View Woofer Version : 1.0 Page 11 of 17... - Page 12 Service Guide SW-5.1 1505 Satellite Version : 1.0 Page 12 of 17...
- Page 13 Service Guide SW-5.1 1505 Wired Control Box Version : 1.0 Page 13 of 17...
-
Page 14: Chapter 5. Part List
Service Guide SW-5.1 1505 Chapter 5. Part List DESCRIPTION UNIT Part No. 1 SW-5.1 1505/Body/Satellite-FL 29-101-01 2 SW-5.1 1505/Body/Satellite-FR 29-101-02 3 SW-5.1 1505/Body/Satellite-SL 29-101-03 4 SW-5.1 1505/Body/Satellite-SR 29-101-04 5 SW-5.1 1505/Body/Satellite-Center 29-101-05 6 Loud speaker-front, 3” 4 ohm 6W 29-100-01 7 Loud speaker-surround, 3”... - Page 15 Service Guide SW-5.1 1505 Audio cable, 3.5mm (orange) to E1066-32 RCA jack (red/white) Audio cable, 3.5mm (blue) to E1066-33 RCA jack (red/white) 28 3 pin cable, SW-5.1 3005 E1066-47 29 Wired Control 29-101-11 30 S/N Label ( on woofer & Gift Box ) 29-102-01 31 Manual, SW-5.1 1505 12030396100-A...
-
Page 16: Chapter 6. Schematic Diagram
Service Guide SW-5.1 1505 Chapter 6. Schematic Diagram Version : 1.0 Page 16 of 17... -
Page 17: Chapter 7. Important Notes
Service Guide SW-5.1 1505 Chapter 7. Important Notes 7.1 Packing Requirement for Sending the PCB Assembly by Post PCB assembly is a kind of sophisticated electronic circuit board. Well packing will be required when sending them by post. * Some sophisticated IC components are mounted on the PCB assembly, hence it is necessary to pack each PCB assembly with a separate static protecting bag, in order to avoid static electricity.
