PTZOptics PT20X-USB Quick Start Manual

Share Your Vision
PTZOPTICS
Broadcast & Conference Camera
The PTZOptics 20X-USB is a 1080p camera with 20X optical zoom for capturing HD images at long
distances. With support for USB 3.0, HDMI, and IP streaming (H.264, H.265, & MJPEG), this camera is
ideal for broadcasting high definition video signals for broadcast, recording, or video conferencing
applications.

KEY FEATURES

•
60.7 degree wide-angle lens.
•
High performance in low light scenarios with Wide Dynamic Range.
•
Full 1920x1080p HD Resolutions up to 60 frames per second.
•
2D and 3D noise reduction with our latest "low noise CMOS sensor".
•
UVC 1.5 (USB), RS232 & RS485 (Serial), and IP (LAN/WAN) control
•
H.264, H.265, & MJPEG Streaming over RJ-45 LAN port
•
HDMI, USB 3.0, & IP streaming (all 3 simultaneously)
•
RTMP & RTSP IP streaming
•
5-year warranty
•
Photobooth capable
Camera & Lens
Video Sensor
Frame Rates
Frame Rates (CVBS)
Focal Length
Lens Zoom
Field of View
Min Lux
Shutter Speed
SNR
Vertical Flip & Mirror
Horizontal Angle of View
Vertical Angle of View
Working Environment
Pan & Tilt Movement
Pan Movement
Tilt Rotation
Presets
Please check PTZOPTICS.com for the most up to date version of this document
1/2.7" CMOS, 2.12 Mega Pixels
1080p-60/50/30/25, 1080i-60/50,
720p-60/50/30/25
576i-30, 480i-30
20x, F4.42mm-88.5mm, F1.8-F2.8
20x
60.7°
0.05 Lux (@F1.8, AGC ON)
1/30s - 1/10000s
≥55dB
Supported
3.36° (tele) to 60.7° (wide)
1.89° (tele) to 34.1°(wide)
Indoor
±170°
Up: 90°, Down: 30°
10 via IR (255 via Serial or IP)
®
Rear Board Connectors
Video Output HDMI, USB 3.0, IP Streaming, CVBS
Interface
Network Interface RJ45
Audio Interface Line In, 3.5mm (USB & IP Stream Only)
Communication RS-232, RS-485, PELCO-D/P, UVC 1.5
Interface
Baud Rate 2400/4800/9600 bits
Power Supply JEITA type Power Adapter (DC IN 12V)
Interface
USB 3.0 Interface USB 3.0 (Requires Quad Core Processor)
USB 2.0 Interface Future Use
Electrical Index
Power Supply 12W (Max)
Input Voltage 12V DC (10.8 - 13.0V DC)
Physical Specifications
Dimension (in.) 5.6W x 6.5H x 6.3D (7.5H max w/ Tilt)
Dimensions (mm) 142W x 164H x 160D (189H max w/ Tilt)
9" x 9" x 10" | 229mm x 254mm x 229mm
Box Dimensions
Camera Weight 2.95 lbs. (1.34 kg)
Boxed Weight 5.4 lbs. (2.45 kg)
Model Number:
PT20X-USB-GY-G2 (gray)
PT20X-USB-WH-G2 (white)
http://ptzoptics.com/usb/
WHAT'S IN THE BOX
20X Zoom USB 3.0 Camera
Power Adapter + Cord
USB 3.0 Cable
IR Remote Control
RS-232C Cable
Quick Start Guide
(2) AAA Batteries
Rev. 1.6 8/20
