PTZOptics 20x 3G-SDI (GEN 2)
User Manual
Model Nos: PT20X-SDI-GY-G2 & PT20X-SDI-WH-G2
V1.7
(English)
Please check PTZOPTICS.com for the most up to date version of this document
Rev 1.7 8/20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PT20X-SDI-GY-G2 and is the answer not in the manual?

Questions and answers

Related Manuals for PTZOptics PT20X-SDI-GY-G2

Summary of Contents for PTZOptics PT20X-SDI-GY-G2

  • Page 1 PTZOptics 20x 3G-SDI (GEN 2) User Manual Model Nos: PT20X-SDI-GY-G2 & PT20X-SDI-WH-G2 V1.7 (English) Please check PTZOPTICS.com for the most up to date version of this document Rev 1.7 8/20...
  • Page 2 Warranty lengths are shown below. The warranty is valid only if PTZOptics receives proper notice of such defects during the warranty period. PTZOptics, at its option, will repair or replace products that prove to be defective. PTZOptics manufactures its hardware products from parts and components that are new or equivalent to new in accordance with industry standard practices.

  • Page 3: Table Of Contents

    Table of Contents Supplied Accessories………………………………………………………………………………………………………... Notes………………………………………………………………………………………………………………………… Quick Start………………………………………………………………………………………………………………….. Features……………………………………………………………………………………………………………………... Product Specifications………………………………………………………………………………………………………. Back of the Camera…………………………………………………………………………………………………………. IR Remote Controller……………………………………………………………………………………………………….. Using the IR Remote Controller……………………………………………………………………………………………. Dimensional Drawings……………………………………………………………………………………………………… RS-232 Interface……………………………………………………………………………………………………………. VISCA Command List……………………………………………………………………………………………………… Menu Settings………………………………………………………………………………………………………………. Exposure……………………………………………………………………………………………………………….. Color…………………………………………………………………………………………………………………… Image…………………………………………………………………………………………………………………... P/T/Z…………………………………………………………………………………………………………………... Noise Reduction……………………………………………………………………………………………………….. Setup…………………………………………………………………………………………………………………… Communication Setup………………………………………………………………………………………………….

  • Page 4: Supplied Accessories

    Supplied Accessories When you unpack your camera, check that all the supplied accessories are included: ⚫ Camera ........1 ⚫ AC Power Adaptor ....1 ⚫ Power Cord ......1 ⚫ RS232 Cable ......1 ⚫ IR Remote Controller ... 1 ⚫...

  • Page 5: Quick Start

    Quick Start Step 1. Please check that all connections are correct before powering on the camera. Page 2 of 49 Rev 1.7 8/20...
  • Page 6 Step 2. Set the system select switch for your desired video output resolution and frame rate. For many applications, setting 0 (1080p-60) will provide the best overall performance. For highest possible resolution, use setting 0 (1080p-60) or 6 (1080p-30), however your actual realized frame rate may be limited to a lower value than 60 fps by your software and/or network connection.

  • Page 7: Features

    Support for ultra-high FPS mode 1280x720p @ 120 frames per second over IP network stream. Supports non-simultaneous CVBS (composite video) output via 3.5mm connector (480i or 576i) • Control and Settings PTZOptics VISCA over IP IR Remote Control Web-based IP remote control interface RS232 & RS485 VISCA, Pelco-D, & Pelco-P control •...

  • Page 8: Product Specifications

    Product Specifications Model PT20X-SDI-GY-G2 and PT20X-SDI-WH-G2 Type PTZOptics 3G-SDI HD 1080p Color Video Camera (GEN 2) Features 1080p-60/50/30/25/59.94*/29.97*, 1080i-60/50/59.94*, 720p-60/50/59.94* Video System CVBS: 576i, 480i *Broadcast frame rates are considered BETA features and may not be supported by all platforms Sensor Panasonic 1/2.7", CMOS, Total Pixels: 2.12M, Effective Pixels: 2.07M...
  • Page 9 1 x RJ45: 10/100/1000M Adaptive Ethernet ports Network Interface 1-ch 3.5mm audio interface, LINE IN (embedded on IP Stream & HDMI only) (Unbalances stereo) Audio Input USB Port 1x USB 2.0 Type A Female (*no video out* for future local video file storage) 1x RS-232 In: 8pin Mini-DIN, Max Distance: 30m, Protocols: VISCA/Pelco-D/Pelco-P 1x RS-232 Out: 8pin Mini-DIN, Max Distance: 30m, Protocols: VISCA/Pelco-D/Pelco-P Control Input / Output...

  • Page 10: Back Of The Camera

    Back of the Camera 1. Audio LINE IN Interface (IP Stream & HDMI only) 7. Network (IP streaming and control) 2. CVBS (composite video SD) Interface 8. HDMI 1.3 (Digital Video Output) 3. System select dial (resolution) 9. 3G-SDI (Serial Digital Video Output) 4.

  • Page 11: Ir Remote Controller

    IR Remote Controller 1. Standby Button Press this button to enter standby mode. Press it again to enter normal mode. NOTE: Power consumption in standby mode is approximately half of the normal mode. 2. Position Buttons To set preset or call preset. 3.
  • Page 12 12. Multiple Function Buttons Function 1. Set camera IR address Press 3 keys contiguously can set camera IR address as follow: [*] + [#] + [F1]: Address 1 [*] + [#] + [F2]: Address 2 [*] + [#] + [F3]: Address 3 [*] + [#] + [F4]: Address 4 Function 2.

  • Page 13: Using The Ir Remote Controller

    2. Zoom Control Using the IR Remote Controller When the camera is operational, you can use the remote controller to perform panning, tilting, zooming and focusing, as well as store and call back preset positions. Button Instructions： 1. In these instructions, ‘press the button’ means to press and release.
  • Page 14 4. BACKLIGHT. L/R SET and P/T RST Controls 6. Presets - Setting and Clearing Reverse Pan controls direction: Press and hold [L/R SET] button while pressing [1] aka [STD] button for normal pan controls. Press and hold [L/R SET] button while pressing [2] aka [REV] button for reversed pan controls.
  • Page 15 7. Recalling Presets 9. Camera IR Address Set Press 3 buttons in the sequence shown below to set/change the camera’s IR address. This allows up to 4 cameras to be controlled from the same IR remote control. Be sure that only one camera is picking up the IR signal when you perform this function.

  • Page 16: Dimensional Drawings

    Dimensional Drawings (mm) Page 13 of 49 Rev 1.7 8/20...

  • Page 17: Rs-232 Interface

    RS-232 Interface Camera PC/Controller DB-9 1.DTR 1.CD 2.DSR 2.RXD 3.TXD 3.TXD 4.GND 4.DTR 5.RXD 5.GND 6.GND 6.DSR 7.IR OUT 7.RTS 8.NC 8.CTS 9.RI For Control Daisy Chain Camera Camera Mini DIN Function 1.DTR 1.DTR 2.DSR 2.DSR 3.TXD 3.TXD 4.GND 4.GND 5.RXD 5.RXD 6.GND...
  • Page 18 Serial Communication Control In default working mode, the camera is able to connect to a VISCA controller with an RS232C serial interface. ➢ RS232 Communication Control The camera can be controlled via RS232. The parameters of RS232C are as follows: Baud rate: 2400, 4800 or 9600 bps.

  • Page 19: Visca Command List

    VISCA Command List Part 1: Camera-Issued Messages ACK/Completion Message Function Command Command Packet Comments z0 4y FF Returned when the command is accepted. ACK/Completion (y: Socket No.) Messages z0 5y FF Completion Returned when the command has been executed. (y: Socket No.) Error Messages Function Command...
  • Page 20 Part 2: VISCA Command List Command Function Command Packet Comments 8x 01 04 00 02 FF CAM_Power Power ON/OFF 8x 01 04 00 03 FF Stop 8x 01 04 07 00 FF Tele (Standard) 8x 01 04 07 02 FF Wide (Standard) 8x 01 04 07 03 FF CAM_Zoom...
  • Page 21 pq: Color Temperature position 0x00: 2500K ~ Direct 8x 01 04 20 0p 0q FF 0x37: 8000K Full Auto 8x 01 04 39 00 FF Automatic Exposure mode Manual 8x 01 04 39 03 FF Manual Control mode CAM_AE Shutter priority 8x 01 04 39 0A FF Shutter Priority Automatic Exposure mode Iris priority...
  • Page 22 Down 8x 01 06 01 VV WW 03 02 FF speed) WW: Tilt speed 0x01 (low speed) to 0x14 (high Left 8x 01 06 01 VV WW 01 03 FF speed) Right 8x 01 06 01 VV WW 02 03 FF YYYY: Pan Position Upleft 8x 01 06 01 VV WW 01 01 FF...
  • Page 23 Medium 8x 0B 01 02 FF 8x 0B 01 03 FF 8x 0B 01 04 FF CAM_MulticastMode Multicast Mode 8x 0B 01 23 0p FF p=1: On, p=2: Off PTZ Motion Sync On 8x 0A 11 13 02 FF CAM_PTZMotionSync PTZ Motion Sync Off 8x 0A 11 13 03 FF MS Lower Speed Limit...
  • Page 24 CAM_BacklightMode y0 50 02 FF 8x 09 04 33 FF y0 50 03 FF y0 50 02 FF Auto Noise 2D CAM_Nosise2DMode 8x 09 04 50 FF y0 50 03 FF Manual Noise 3D CAM_Nosise2DLevel 8x 09 04 53 FF y0 50 0p FF Noise Reduction (2D) p: 0 to 5 CAM_Noise3DLevel...
  • Page 25 y0 50 00 FF High CAM_AWBSensitivit y0 50 01 FF Normal 8x 09 04 A9 FF yInq y0 50 02 FF y0 50 02 FF CAM_UACInq 8x 2A 02 A0 04 FF y0 50 03 FF Block Inquiry Command List Command Command packed Inquiry Packet...
  • Page 26 Part 4: VISCA over IP Command List Command Function Command Packet Comments 81 01 04 00 02 FF CAM_Power Power ON/OFF 81 01 04 00 03 FF Stop 81 01 04 07 00 FF Tele (Standard) 81 01 04 07 02 FF Wide (Standard) 81 01 04 07 03 FF CAM_Zoom...
  • Page 27 pq: Color Temperature position 0x00: 2500K ~ Direct 81 01 04 20 0p 0q FF 0x37: 8000K Full Auto 81 01 04 39 00 FF Automatic Exposure mode Manual 81 01 04 39 03 FF Manual Control mode CAM_AE Shutter priority 81 01 04 39 0A FF Shutter Priority Automatic Exposure mode Iris priority...
  • Page 28 Down 81 01 06 01 VV WW 03 02 FF speed) WW: Tilt speed 0x01 (low speed) to 0x14 (high Left 81 01 06 01 VV WW 01 03 FF speed) Right 81 01 06 01 VV WW 02 03 FF YYYY: Pan Position Upleft 81 01 06 01 VV WW 01 01 FF...
  • Page 29 Medium 81 0B 01 02 FF 81 0B 01 03 FF 81 0B 01 04 FF CAM_MulticastMode Multicast Mode 81 0B 01 23 0p FF p=1: On, p=2: Off PTZ Motion Sync On 81 0A 11 13 02 FF CAM_PTZMotionSync PTZ Motion Sync Off 81 0A 11 13 03 FF MS Lower Speed Limit...
  • Page 30 CAM_BacklightMode 90 50 02 FF 81 09 04 33 FF 90 50 03 FF 90 50 02 FF Auto Noise 2D CAM_Nosise2DMode 81 09 04 50 FF 90 50 03 FF Manual Noise 3D CAM_Nosise2DLevel 81 09 04 53 FF 90 50 0p FF Noise Reduction (2D) p: 0 to 5 CAM_Noise3DLevel...
  • Page 31 90 50 00 FF High CAM_AWBSensitivit 90 50 01 FF Normal 81 09 04 A9 FF yInq 90 50 02 FF 90 50 02 FF CAM_UACInq 81 2A 02 A0 04 FF 90 50 03 FF Part 6: Pelco-D Protocol Command List Function Byte1 Byte2...
  • Page 32 Part 7: Pelco-P Protocol Command List Function Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7 Byte8 0xA0 Address 0x00 0x08 Pan Speed Tilt Speed 0xAF Down 0xA0 Address 0x00 0x10 Pan Speed Tilt Speed 0xAF Left 0xA0 Address 0x00 0x04 Pan Speed Tilt Speed 0xAF Right...

  • Page 33: Menu Settings

    Menu Settings EXPOSURE Mode Auto 1. MENU ExpCompMode Press the [MENU] button to display the On Screen Display Backlight menu on the normal screen, using the arrow button to move Gain Limit the cursor to the item to be set. Press the [HOME] button to Anti-Flicker 60Hz enter the corresponding sub-menu.

  • Page 34: Color

    3. COLOR 4. IMAGE Move the main menu cursor to [COLOR], and press the Move the main menu cursor to [IMAGE], and press the [HOME] key to enter the color page, as shown in the [HOME] key to enter the image page, as shown in the following figure.

  • Page 35: Noise Reduction

    P/T/Z NOISE REDUCTION SpeedByZoom NR2D-Level 1 AF-Zone Center NR3D-Level 3 AF-Sense High L/R Set Select Item Display Info Change Value [Menu] Back Image Freeze Digital Zoom NR2D Level: 2D noise reduction, optional items: Close, Call Preset Speed Auto, 1 ~ 5. Pre Zoom Speed NR3D Level: 3D noise reduction, optional items: Off, 1 ~ 8.

  • Page 36: Communication Setup

    V_Address: Camera VISCA address: optional items: 1 ~ Lens: Optional items: Type1, Type2 Auto Scan Shoot: Optional items: Off, On V-AddrFix: Fixed VISCA address: optional items: Off, Auto Focus L: Lock focus in current position, optional items: Off, On Net Mode: Optional items: Serial, Paral OSD TimeOut: Auto close OSD, optional items: 2.5min, Baudrate: Optional items: 2400, 4800, 9600, 38400 P_D_Address: Pelco-D Address, optional items: 0 - 254...

  • Page 37: Network Connection

    Network Connection 1. Operating Environment Operating System: Windows 2000/2003/XP/Vista/7/8.1/10 Network Protocol: TCP/IP Client PC: P4 / 128M RAM / 40GHD / support for scaled graphics card, support for DirectX8.0 or more advanced version. 2. Equipment Installation 1) Connect camera to your network via a CAT5 or CAT6 patch cable or directly to your PC via a CAT5 or CAT6 cross over cable.

  • Page 38: Setting Up A Network Video Stream

    2. Next, go online and download the IP Address Settings Tool. It’s available for Windows & Mac OS at ptzoptics.com/download. 3. Once you complete the download, launch the “Upgrade v2.8C” tool. Select your network connection type from the “Interface”...
  • Page 39 From the Web Interface, you have two (2) ways to view the video feed. a. Set the secondary stream to MJPEG. b. Install the PTZOptics ActiveX Plugin and use Internet Explorder. i. For more detail, go to help.ptzoptics.com. 7. From the Web Interface, you can control the camera using the arrows on the left side. You can also adjust many of your camera’s settings via this IP interface.

  • Page 40: Additional Network Info

    Additional Network Info Discovering your Network IP range You can discover the IP range of your network by using the Command Prompt for Windows, or the Terminal app for Macs and following the steps below. Windows 1. Type “CMD” into the search bar in the start menu. 2.

  • Page 41: Camera Web Interface

    Camera Web Interface The Web Interface allows you to control the camera, view the video feed, and adjust many of the camera’s settings. Menu The Menu allows you to traverse the Web Interface. By default, the “Live” option is selected. Live This tab allows you to view the video feed of the camera.

  • Page 42: Video

    Video 720p120: Allows camera to output 720p at 120 FPS via the IP Network Stream. Set to ‘On’ or ‘Off’. (Note: Setting to ‘On’ will override and lockout other video settings). Video Format: Supports 50Hz (PAL), 60Hz (NTSC), & Dial Priority formats.

  • Page 43: Image

    Image Brightness: Brightness slider. Default: 7 Saturation: Saturation slider. Default: 4 Contrast: Contrast slider. Default 10 Sharpness: Sharpness slider. Default: 3 Hue: Hue slider. Default: 7 Flip & Mirror: Check the Flip and/or Mirror buttons to rotate the image accordingly. Audio Audio Switch: Enable / Disable audio embedding Audio Type: AAC...

  • Page 44: Network

    Network LAN Settings: The Lan Settings section allows you to adjust the IP parameters of the camera. The default IP address of the camera is 192.168.100.99. You cannot change the MAC address. IP Configuration Type: Fixed IP Address (Static) & Dynamic IP Address (DHCP). IP Address: Camera’s IP address.
  • Page 45 DNS Address: Network Domain Name Server address. MAC Address: The camera’s MAC address. Apply & Cancel Buttons: Apply or cancel the changes made to the LAN Settings section. Port Settings: The Port Settings section allows you to adjust the network ports of the camera. HTTP Port: This port is used for HTTP-CGI control, and for the web application.

  • Page 46: Information

    Main Time Show: Enable / Disable Main Time Position: Main Time position Sub Time Show: Enable / Disable Sub Time Position: Sub Time position Apply & Cancel Buttons: Apply or cancel the changes made to the Network Settings section. Information The Information section displays the device information, firmware version, &...
  • Page 47 Focus Control http://[Camera IP]/cgi-bin/ptzctrl.cgi?ptzcmd&[Action]&[Focus Speed] [Action]: FOCUSIN, FOCUSOUT, FOCUSSTOP [Focus Speed]: 1 (Slowest) – 7 (Fastest) Focus Lock Control http://[Camera IP]/cgi-bin/param.cgi?ptzcmd&[Action]_mfocus [Action]: LOCK, UNLOCK Preset Control http://[Camera IP]/cgi-bin/ptzctrl.cgi?ptzcmd&[Action]&[Position Number] [Action]: POSSET, POSCALL [Position Number]: 0 – 89 (Range 1), 100 – 254 (Range 2) Home Position Recall http://[Camera IP]/cgi-bin/ptzctrl.cgi?ptzcmd&home PT Reset...
  • Page 48 OSD Menu Selection Control http://[Camera IP]/cgi-bin/param.cgi?navigate_mode&[Mode] [Mode]: CONFIRM, OSD_BACK HTTP-CGI – Image Adjustment Image Settings Control http://[Camera IP]/cgi-bin/param.cgi?post_image_value&[Mode]&[Level] [Mode]: BRIGHT, SATURATION, CONTRAST, SHARPNESS, HUE [Level]: 0 - 14 Image Orientation Control http://[Camera IP]/cgi-bin/param.cgi?post_image_value&[Mode]&[State] [Mode]: FLIP, MIRROR [State]: 1 (Flip / Mirror), 0 (Default) Default Image Settings http://[Camera IP]/cgi-bin/param.cgi?get_image_default_conf HTTP-CGI –...

  • Page 49: Photobooth Functionality

    Photobooth Functionality Your PTZOptics camera can quickly and easily take a series of four (4) still image or video files that are stored on the camera and made accessible with a standard web browser on the same network. Photos You have two (2) options to initiate a series of four (4) still images being captured…...
  • Page 50 second delay between four (4) ten (10) second videos being captured. To retrieve your series of four (4) videos, you will need to open a standard web browser with network access to the camera and use the following HTTP strings to retrieve the still image files as desired. Video 1: http://[Camera IP]/video1.mp4 Video 2: http://[Camera IP]/video2.mp4 Video 3: http://[Camera IP]/video3.mp4...

  • Page 51: Maintenance And Troubleshooting

    Maintenance and Troubleshooting Camera Maintenance ⚫ If the camera will not be used for a long time, please turn off the power switch. ⚫ Use a soft cloth or lotion-free tissue to clean the camera body. ⚫ Use a soft dry lint-free cloth to clean the lens. If the camera is very dirty, clean it with a diluted neutral detergent. Do not use any type of solvent or harsh detergent, which may damage the surface.
  • Page 52 VISCA address). Copyright Notice The entire contents of this manual, whose copyright belongs to PTZOptics, may not be cloned, copied or translated in any way without the explicit permission of the company. Product specifications and information referred to in this document are for reference only and as such are subject to updating at any time without prior notice.
