Smart series 2.0
Before using this device, please read this manual carefully and keep it safe for future
IP Cameras,
User manual
reference
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smart Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Comelit Smart Series

Summary of Contents for Comelit Smart Series

  • Page 1 IP Cameras, Smart series 2.0 User manual Before using this device, please read this manual carefully and keep it safe for future reference    ...
  • Page 2 Safety instructions This manual is designed to ensure correct use of the product by the user, without risks or material damage. Please read it carefully and keep it safe for future reference. Precautionary measures are divided into “warnings” and “precautions”, as described below: Warnings: obscuring the warnings may lead to death or serious injury.
  • Page 3 Keep the product in a dry environment with a non-corrosive atmosphere, away from direct sunlight, places with poor ventilation and sources of heat such as radiators and heating systems (non-observance of this warning may present a fire hazard). To avoid damaging the IPC, do not place it in areas subject to soot or steam, excessively high temperatures or large amounts of dust.

  • Page 4: Table Of Contents

    Index CHAPTER 1 - INTRODUCTION ........................... 6 1.1 PRODUCT SPECIFICATIONS ........................6 CHAPTER 2 - OPERATING INSTRUCTIONS ....................7 2.1 NETWORK CONNECTION ..........................7 ........................7 2.1.1 W IRED NETWORK CONNECTION 2.2 FINDING AND EDITING THE IP ADDRESS ................... 7 2.3 SETTING THE NETWORK CAMERA ON THE WAN .................
  • Page 5 ..................................36 7.5.1 I MAGE 7.5.2 OSD ..................................40 6.6 EVENTS ................................41 CHAPTER 7 - FREQUENTLY ASKED QUESTIONS ................53    ...

  • Page 6: Chapter 1 - Introduction

    Chapter 1 - Introduction 1.1 Product specifications This section introduces the IPC specifications, allowing the user to familiarise themselves with the device. Video functions and instant acquisitions The network camera supports video recording and the instant acquisition function. Mirror image function The network camera supports the horizontal, vertical and horizontal-vertical video flip function.

  • Page 7: Chapter 2 - Operating Instructions

    Chapter 2 - Operating instructions 2.1 Network connection To view and configure the network camera on the network, the IP camera must be connected to the computer in use and the Smart Search tool or the Smart CMS software installed to find and edit the IP address of your network camera. The tool and the software is available to download from our website https://www.comelitgroup.com 2.1.1 Wired network connection...

  • Page 8: Setting The Network Camera On The Wan

    Figure 2-3 Using Smart CMS software to search for online devices. Step 2：Modificare l'indirizzo IP e la maschera di sottorete impostandola sulla stessa sottorete del computer. In the Smart Search tool, select the IP editing device. The IP and gateway can be edited and the password entered on the right-hand side of the interface.

  • Page 9: Dynamic Ip Connection

    The router is connected to the network camera, as shown in figure 2-4: Figure 2-4 The steps are as follows: Step 1: Connect the network camera to the router. Step 2: Assign the IP address, the subnet mask and the gateway. For more details, please refer to paragraph 7.3.1.
  • Page 10 Note: The IP address obtained is assigned dynamically via PPPoE, therefore the IP address always changes after the camera has been restarted. To overcome the inconvenience of the dynamic IP address, you need to obtain a domain name from the DDNS provider (e.g.

  • Page 11: Chapter 3 - Accessing The Ipc Via Web Client

    Chapter 3 - Accessing the IPC via web client 3.1 Installing HsWebplugin.exe controls Note: If the IP address for your network camera has already been changed, log in with the new IP address. Open the browser and enter the IP address of the IPC in the address bar (the default address is 192.168.1.150).
  • Page 12 Figure 3-1 (3) Figure 3-1 (4) Figure 3-1 (5)    ...

  • Page 13: Login/Logout Options And Changing The Password

    Figure 3-1 (6) Click “Finish”. Note If the system indicates an “installation error”, deselect “Enable Protected Mode” in the “Internet Options” “Security” tab and enter a “Custom level” for settings relating to ActiveX control, as shown in Figure 3-2. Reinstall HsWebplugin.exe and save the settings. Figure 3-2 3.2.

  • Page 14: Changing The Password

    Figure 3-3 When logging in for the first time, enter the default username: admin and the default password: admin and select the system language. 3.2.2 Changing the password After successfully logging in, the interface will prompt you to change the password, as shown in figure 3-4: Figure 3-4 To increase account security, click “Modify”, entering the user interface to change the...

  • Page 15: Logging Out Of The System

    1: Enter the old password and the new password in the Password and Confirm Password fields; 2: Enter security questions 1, 2, 3 in accordance with your own requirements. This is optional and you do not have to complete these sections; 3: Click “Save”...

  • Page 16: Chapter 4 - Live Preview

    Chapter 4 - Live preview 4.1 Live preview Click to access the screen shown in figure 4-1: Figure 4-1 Change window size. Click the buttons in the top left-hand corner to change the screen size, choosing from the available options (4:3, 16:9, X1, whole screen). Change stream.

  • Page 17: Chapter 5 - Playback

    Enable/Disable electronic zoom function. Click the electronic zoom function and press and hold the left mouse button to select the electronic zoom area. The selected area is shown on the screen Enable/Disable audio Open/Close intercom Table 4-1 Chapter 5 - Playback On the main screen, click to retrieve the videos recorded on the micro-SD card.
  • Page 18 Figure 5-1 You can select the video type (normal, alarm) and video time here. Search video. Select the day on the calendar, the start time, the end time, the file type (normal or alarm) and click Playback/Stop. After searching for a video, click to start video playback and click stop video playback.

  • Page 19: Chapter 6 - Configuration

    Zoom in on the time bar. Click the button on the right side of the time bar to enlarge it. Zoom out from the time bar. When the time bar is enlarged, click the button to return to the standard time bar. Search and download video file.

  • Page 20: Local Configuration

    Click in the main window to access the local configuration page. This section can be used to set the system parameters, as well as parameters relating to the network, video, images, events and other parameters. 6.1 Local Configuration On the main screen, click “Configuration → Local Configuration” to access the relevant page, as shown below in figure 6-1: Figure 6-1 Record File Settings.

  • Page 21: System

    Export parameters. Export parameters path. Set the store location for IP export parameters. Import parameters. Import parameters path. Set the store location for IP import parameters. 6.2 System On the main screen, click “Configuration → System” to access the relevant page. 6.2.1 System Configuration On the main screen, click “Configuration →...
  • Page 22 Figure 6-3 Time Zone. View the current device time zone. Camera time. View the current device time. NTP. The IPC time will be synchronised with the network; different time zones can be selected. Click “Save” after completing the settings. Set Manually. Used to manually set the IPC date and time. Click “Save” after completing the settings.

  • Page 23: Log Search

    Figure 6-4 Maintenance On the main screen, click “Configuration → System → System Configuration → Maintenance” to access the relevant page, as shown below in figure 6-5: Figure 6-5 Reboot System. The IPC will restart after you click “Reboot System”. Default.

  • Page 24: Security

    Figure 6-7 Search. Set the start and end time and click “Search” to find the desired files. Clear. Click “Clear” to clear all logs. Log export. Used to save the content of the selected log in txt format. 6.2.4 Security On the main screen, click “Configuration →...
  • Page 25 Figure 6-9 Warning In order to improve product security, change the password regularly. We recommend changing the password every 3 months. If the network camera is used in an environment with a high security risk, we recommend changing it once a month, or every week.

  • Page 26: Sd Card (Sd/Emmc)

    6.2.5 SD Card (SD/EMMC) On the main screen, click “Configuration” → Storage → Storage management and choose “SD Card” or “EMMC” (internal memory) to access the relevant page. Here you can view information relating to the micro-SD card / internal memory and format them, as shown in figure 6-10: Figure 6-10 Formatting...

  • Page 27: Network

    Figure 6-11 6.3 Network On the main screen, click “Configuration → Network” to access the relevant page. The network settings are divided into a basic setup configuration and an advanced setup configuration. 6.3.1 Basic Setup TCP/IP On the main screen, click “Configuration → Network → Basic Setup → TCP/IP” to access the relevant page.
  • Page 28 Figure 6-12 If the DHCP is disabled, the IP address of the IPC can be edited manually, along with the subnet mask, the default gateway and information on the preferred DNS server. When you have finished, click “Test” to check whether the IP address is available on the LAN. Click “Save”...
  • Page 29 Wifi connection In the Wifi interface, choose the Wifi router connection write the Wifi password Press SAVE button and disconnect the LAN cable Using “search tool” check the Wifi IP address in order to connect to the new one  ...

  • Page 30: Advanced Setup

    DDNS function, select the type and enter the server name, username and password, as shown in figure 6-14: Figure 6-14 DDNS. Used to enable/disable the function. DDNS Type. Select the service type (e.g. Comelit DNS). Server Name. Enter the domain name. Username. Enter the username. Password Enter the password.
  • Page 31 Confirm Password. Enter the password again. Status. Show the device status. Service Type. Show the user type. Links to service providers. Show service provider information. On the main screen, click “Configuration → Network → Advanced Setup → FTP” to access the relevant page, which can be used to set the FTP server address, the port, the user name and the password, as well as to set the archive location and to select the file format.
  • Page 32 Overwrite. If enabled, the oldest files will automatically be overwritten when the FTP server is full. Upload Via FTP. In the drop-down menu, select the FTP file format (JPEG for images and AVI for videos). Click “Save” after completing the settings. SMTP On the main screen, click “Configuration →...
  • Page 33 P2P is a private network penetration technology. Devices can be added using the two methods below. 1) Download the Comelit View Smart app and register an account. 2) Access the P2P platform and add the device by scanning the QR code.
  • Page 34 Figure 6-18 Cloud Storage Type. You can view the cloud storage type (Google only). Web Page. Show the URL to copy in the Internet Explorer address bar to register the device. Authentication Code. View the code used to access the registration page for the Google device.

  • Page 35: Video

    App Encryption Enabled. If enabled, connection with the Comelit View Smart app is encrypted. 6.4 Video On the main screen, click “Configuration → Video” to access the relevant page, which can be used to set video, audio and other functions.

  • Page 36: Audio

    Bitrate Type. Select the output mode from the drop-down menu (CBR: constant bitrate, VBR: variable bitrate). I-Frame Interval. The IPC keyframe interval can be set to 1-5 s. Profile. You can select Main Profile (default setting), Baseline or High Profile. 7.4.2 Audio On the main screen, click “Configuration →...
  • Page 37 Figure 6-22 Brightness/Contrast/Saturation/Sharpness. You can set the value of these parameters. Valid values fall between 0 and 255; drag the cursor to make the setting (the default value is 128), as shown in figure 6-23: Figure 6-23 IR Light. The default value for infrared lighting mode is “Auto”; the sensitivity level is 3, the filtering time is 3 seconds and the brightness is 100, as shown in figure 6-24 (1).
  • Page 38 setting the sensitivity and the filtering time. Figure 6-24 (1) - When the infrared lighting mode is set to “Scheduled Switch”, you can set the Dawn Time and Dark Time (start and end time) parameters and the brightness level, as shown in figure 6- 24 (2): Figure 6-24 (2) - When the infrared lighting mode is “Day”, the device video is always in colour.
  • Page 39 default setting is “OFF”. When set to “ON”, you can set the “BLC level”, “Strong light intensity” and “Dark area boost”, as shown in figure 6-26 below. Figure 6-26 White Balance. The default setting is “Auto”. If you select “Manual”, you can set the gain for red, green and blue (interval 0-255), as shown in figure 6-27: Figure 6-27 Video Adjustment.
  • Page 40 WDR level. The default setting is “OFF”; you can select “Automatic”, “Weak”, “Moderate”, “Strong” or “Super” from the drop-down menu. Defog Mode. Used to set the defog mode and level, as shown in figure 6-30. Figure 6-30 Defog Mode. The default setting is “OFF”; you can select “ON” or “Automatic” from the drop- down menu.
  • Page 41 both). Corridor mode. The default setting is “OFF”. You can select a rotation of 90 degrees or 270 degrees for corridor installation. 6.6 Events On the main screen, click “Configuration → Events” to access the relevant page, which can be used to set parameters relating to motion detection, privacy mask, notifications and other events.
  • Page 42 Figure 6-32 Enable. Used to enable/disable the motion detection alarm. Area Settings. Select the area in which to set motion detection. Select All. Select the whole area (396 (22 x 18) squares). Manually draw the alarm area. Click and hold the left mouse button to select the area; release the left mouse button to complete alarm area selection.
  • Page 43 motion detection schedules (the default setting is all day). To program the motion detection schedule: Method 1: Click the time bar and manually set the start and end times. Click “Save”. If you need to delete the time period, click “Delete”. Method 2: Click the time bar, which will show two circles at both ends.
  • Page 44 Figure 6-34 Privacy Mask On the main screen, click “Configuration → Events → Privacy Mask” to access the relevant page, as shown in figure 6-35: Figure 6-35 Here you can select up to 3 privacy masks. Press and hold the left mouse button and drag the cursor to set the area.
  • Page 45 Figure 6-36 Enable. Used to enable/disable the video tampering alarm. Area Settings. Select the area to set video tampering. Drawing Area. Click “Drawing Area”, then click on the screen and press and hold the left mouse button to select the desired area. Release the left mouse button and click “Stop Drawing”...
  • Page 46 If you need to set the same arming time for other days, click the button on the right of the time bar, select “Select All” or a day, then click “OK”. Click “Save” to complete configuration. Figure 6-37 Linkage Type. Various alarm connections are available, as shown in figure 6-38. Select All.
  • Page 47 Figure 6-38 Alarm Input On the main screen, click “Configuration → Events → Alarm Input” to access the relevant page. Alarm Output On the main screen, click “Configuration → Events → Alarm Output” to access the relevant page. Arming Schedule. As shown in figure 6-39, you can view, edit and delete programmed video tampering detection schedules (the default setting is all day).
  • Page 48 Figure 6-39 Linkage Type. Various alarm connections are available, as shown in figure 6-40. Select All. Select all connection types. Upload Via SMTP. Select to send alarm information to the recipient’s email address. Upload Via FTP. Select to send alarm information to the FTP server. Linkage Alarm Output.
  • Page 49 Figure 6-41 Use this page to set the “Cable Disconnected” and “IP Address Conflict” alarms, as well as the alarm output mode. Click “Save”. Set the value of the quantising parameter “Relative QP” or “QP absolute” for the relevant zone (ROI). Up to 3 “fixed areas” can be set. On the main screen, click “Configuration → Events →...
  • Page 50 1: [Set area]. Click and hold the left mouse button and drag the cursor to set the area. 2: [Set the “Relative QP” or “QP absolute” value]. Select “Relative QP” or “QP absolute” in the corresponding position for the area and enter the relevant value. 3: Move the scroll bar to set the framerate for the non-ROI area and click.
  • Page 51 In the Area Settings screen, you can enable the selected function using enable and set the corresponding parameters: draw the shape within an image (a line for line crossing and an area for functions requiring a zone within which to perform the analysis) using the drawing area menu select the warn region set detection sensitivity select the line crossing direction...
  • Page 52 The linkage type menu can be used to select which actions we want to link with the occurrence of the set event.    ...
  • Page 53 Chapter 7 - Frequently Asked Questions 1. Why can’t the camera be accessed via Internet Explorer? Answer: there may be 3 possible reasons. a. Is there a network access issue? Connect the network cable to a PC and make sure the network cable is intact and working properly.
