- Page 1 CAMERAS WI-FI IP 100 SERIES Please read this manual thoroughly before use and keep it for future reference...
-
Page 2: Table Of Contents
Contents 1. Login Interface ................................ 1 2. Live view ................................. 2 2.1 Full-screen Preview ............................. 2 2.2 Electronic Zoom-in ............................2 2.3 PTZ Control ..............................3 3. Playback ................................. 4 4. Setup ..................................5 4.1 Device Info ..............................5 4.2 QR Code ..............................6 4.3 ePTZ Setting.............................. - Page 3 Statement The instruction is for guidance only. Detailed information is in accordance with the product. The instruction may include some technical inaccuracies or typographical error thought it is prepared with our every effort. The product or procedures described in the instruction may be changed or updated at any time without advance notice.
-
Page 4: Login Interface
1. Login Interface Input the IP address of the front-end device into the IE browser (default IP address is 192.168.1.188) to access the Login interface, as shown in the following figure: After entering into the login interface, it will prompt to install the Activex control, as shown in the following figure: User Name: admin (default setting) -
Page 5: Live View
2. Live view After login, it will enter into the live preview, as shown in the following figure. Note:The device need to insert micro-SD card for full function display interface, otherwise, it's for simple type interface. 2.1 Full-screen Preview Click the full-screen icon in the lower right corner to preview full screen. -
Page 6: Ptz Control
2.3 PTZ Control Zoom In/ Out: To adjust degree of zoom in/ out Focus: To adjust size of focus Iris: To adjust size of aperture Speed: Use the slider to regulate the PTZ speed Bright: To adjust the brightness of the screen Contrast: To adjust the contrast of the screen arrow is used to restore default settings. -
Page 7: Playback
3. Playback Click Playback enter into playback interface, click the icon , next select the date time of the calling video in need, then click the icon , the record video will search automatically, as shown in the following figure: Start: Start the current playback Stop: Stop the current playback Slow：Slow down the playback speed(1/2, 1/4, 1/8, 1/16 times optional) -
Page 8: Setup
4. Setup Note:the device need to insert micro-SD card for full function display interface, otherwise, it's for simple type interface 4.1 Device Info IP Camera Device Info interface as shown in the following figure: Device Name: Edit the camera name Device Type: Display the device type Serial No. -
Page 9: Qr Code
Note: after enable the corresponding protocol in the platform management interface, then the QR code icon will display. QR code supported: Comelit View 100. During the platform management interface, Comelit View 100_ID protocol should be matched with Comelit View 100 client. -
Page 10: Eptz Setting
4.3 ePTZ Setting IP Camera ePTZ Set interface as shown in the following figure: Protocol: Support PelcoD and PelcoP protocol Address: Support 0-255 address code adjustable Baud Rate: Support diverse baud rate selectable After complete all parameters setting, click Save and then it will take effect immediately. 4.4 Display Settings IP Camera Display Settings interface as shown in the following figure. -
Page 11: Encoding
Name: Modify the appointed channel name Main Stream OSD: Modify the appointed channel font of main stream OSD Sub Stream OSD: Modify the appointed channel font of sub stream OSD Multi OSD:Add multi user-defined OSD, it can be selected Show or not Time Format: Select different time display mode for the appointed channel Date Format: Select different date display mode for the appointed channel Bright: Adjust the brightness for the appointed channel... -
Page 12: Video Parameters
4.6 Video Parameters IP Camera Video Parameters setting interface as shown in the following figure: Day&Night Mode: Outside Trigger/ Auto/ Color/ Black White four kinds of mode selectable. Non infrared IP cameras default mode is Auto, and infrared IP cameras default mode is Outside Trigger. According to the IP camera type and actual scene, user can select the Day&Night mode optional Switching Time: Day&Night switch delay time, 0-30s selectable, and default is 3s Day-Night: 0-255 selectable, users can adjust it according to the need, default is 45... -
Page 13: Motion Detection
4.7 Motion Detection IP Camera Motion Detection setting interface as shown in the following figure: Enable: Select whether to enable the Motion Detection function. Arm Schedule: Set the alarm schedule from Monday to Sunday Mask Set: Press and darg the left mouse button in the Mask Set preview interface, then draw the small check optional to set the detective areas Clear: Click Clear to clear the current detective areas Sensitivity: The higher sensitivity, the more obvious motion detective effect... -
Page 14: Video Tampering
4.8 Video Tampering IP Camera Video Tampering setting interface as shown in the following figure: Enable: Select whether to enable the Video Tampering function. Arm Schedule: Set the alarm schedule from Monday to Sunday Mask Set: Press and darg the left mouse button in the Mask Set preview interface, then draw the small check optional to set the detective areas Clear: Click Clear to clear the current detective areas Sensitivity: The higher sensitivity, the more obvious motion detective effect... -
Page 15: Privacy Mask
4.9 Privacy Mask IP Camera Privacy Mask setting interface as shown in the following figure: Enable: Enable or disable the Privacy Mask function Area Settings: Press and drag the left mouse button in the Area Settings preview interface, then draw the check optional to set the mask area Clear: Click Clear to delete the current mask area After complete all parameters setting, click Save and then the settings will take effect immediately. -
Page 16: Wifi Config
Static IP: The device IP address is permanent DHCP: Enable DHCP, then IP camera will get the IP address from router automatically IP Address: Input the corresponding numbers to change the IP address Subnet Mask: Input the corresponding IP subnet mask Gateway: Input the corresponding gateway address DNS 1: DNS server IP address DNS2: DNS server second IP address... - Page 17 configure as follow: 1. Search Wifi device: Copy the SSID serial number in the Current Status to the blank of SSID part in the Connect Config, click Save, will automatically switch to STA mode, click Refresh, then AP List will display all the Wifi device names within the acceptable range, as shown in the following figure: 2.
-
Page 18: Platform Management
4.12 Platform Management IP camera Platform Management interface as shown in the following figure: User can open, close, edit and delete the protocol in the Management Platform interface. 4.13 Multicast Config IP Camera Multicast Config interface as shown in the following figure: Default disabling for multicast config. -
Page 19: Ntp Settings
with fixed IP address on the Internet. IP Camera network setting interface as below figure: Enable DDNS: Enable or Disable DDNS function Server Type: Select DDNS server type Server Name: Input server name Port: Input port.default port is 80 User Name: Input user name Password: Input password (max 10 char.) Confirm pwd: Input the password again to confirm it Domain: Input the hostname... -
Page 20: Email Settings
Enable NTP: Enable or disable NTP function Server Address: Input NTP server IP address NTP Port: Default port is 123 Adjust Time Interval: Input the interval time Select Time Zone: Different area time format selectable GMT: Adjust the time to make it more exact After complete all parameters setting, click Save, then the settings will take effect immediately. -
Page 21: Ftp Settings
Confirm pwd: Input the password again to confirm it (send)SMTP Server: Input the smtp server address of the outbox SMTP Port: Input the smtp server port of the outbox Sending Interval: Input the sending interval time. There are 25S/ 35S/ 45S/ 55S four options Receiver: Input the mail receiver name Email Address: Input the address of the inbox After complete all parameters setting, click Save and then the settings will take effect immediately. -
Page 22: Alarm Out
Alarm Input: Select the alarm input port, then click can implement following parameters settings Alarm In Name: Input alarm input name Trigger: Select the alarm status: Normally Open/ Normally Close Arm Schedule: Alarm schedule can be set from Monday to Sunday Email: Click Email. -
Page 23: Exception Settings
Output Relay Status: Normally Open/ Normally Close selectable Output Delay: Select the alarm output delay time(when alarm trigger is over, it will output corresponding alarm delay time) After complete all parameters setting, click Save and the settings will take effect immediately. 4.20 Exception Settings IP Camera Exception Settings interface as shown in the following figure:... -
Page 24: User Info
Exception Type: There are Network Broken/ IP Address Conflict/ Illegal Access/ three exception types selectable Record: Click Record, it will linkage to record video as any exception type triggers Alarm Output: Click Alarm Output, it will Linkage other alarm devices as any exception type triggers After complete all parameters setting, click Save and then the settings will take effect immediately. -
Page 25: System Update
4.22 System Update IP Camera System Update setting interface as shown in the following figure: File: Click Browse to find and select the upgrade kit, then click Update. NOTE: To upgrade must first be uploaded the file whose name starts with (Main fw), then the one whose name starts (Sub fw). -
Page 26: Storage Management
4.24 Storage Management IP Camera Storage Management setting interface as below figure, you can check current micro-SD card Capacity(MB)/ Free Spare (MB)/ Status, and format. As shown in the following figure: Note: Please turn off the power supply, before you insert or take out the micro-SD card. 4.25 Restore IP Camera Restore setting interface as shown in the following figure: Export: Export all configurations to PC or USB... -
Page 27: Local Setting
4.26 Local Setting IP Camera Local Setting interface as shown in the following figure: Window Mode: Set the preview window mode(Full/ 4:3/ 16:9/ Original Image optional) Preview Capture: Select and modify the preview capture file storage path Playback Capture: Select and modify the video record capture file storage path File Capture: Select and modify the file management capture file storage path Back Up: Select and modify video record backup file storage path Rec Capture: Select and modify the preview interface video record file storage path... -
Page 28: File Management
5. File Management Note:The device need to insert micro-SD card for full function display interface, otherwise, it's for simple type interface. 5.1 Search Input the concrete time, and click the button, the lower part displays searched images and videos (double click to display files) Note: It can modify video or image storage path, and later chapter will make a brief instruction (more details please refer to：Setup Local Setting) -
Page 29: Preview Capture
click the image files directly. 5.5 Preview Capture To review preview capture files, search and double click the image files directly. 5.6 File Capture To review capture files in file management, search and double click the image files directly. 5.7 Preview Videos To review preview interface video record files, search and double click the video files directly. -
Page 30: Exit
Main Type: Select the log type to check. There are All/ Alarm/ Exception Settings/ Operation / Setup optional, or click All to check all types of them Start Time/ End Time: Select the time quantum of log to check Page Num：Select the log number of each page to display on the interface After finishing all settings above, click Search and then the log information will display on the left blank area 7.
