Lexicon MV-5 Service Manual page 7

MV-5 PROCESSOR
INDEX NO. PART NO.
1 H03-ZVE21S90264-R-1
2 H03-ZUD0301ABBK-R-9
3 H03-ZME21S07A00-R-1
4 H03-ZME21S08A00-R-2
5 H03-XDM202MD15G-R-3
6 H03-ZPE0604AA00-R-8
7 H03-ZME0615GAMW-R-5
8 H03-ZME0615GA00-R-4
9 H03-ZME21S01A00-R-6
10 H03-ZPE0602AA00-R-1
11 H03-ZPE2101AA00-R-7
12 H03-ZPE0603AA00-R-A
13 ZFNR19720SB-R-5
14 ZPC1103GAGY-R-A
15 H03-ZME21S13A00-R-6
16 H03-ZME21S14A00-R-7
17 H03-ZMD12S01C00-R-4
18 H03-SO3P5179GNN-R-9
19 H03-SOJB040131P-R-7
20 H03-SORA64105GN-R-3
21 H03-ZMD27S05A00-R-2
22 H03-SORA40RSCGN-R-8
23 H03-SORA1J440GE-R-9
24 H03-ZME21S12A00-R-5
25 H03-SORA40RSCGN-R-8
26 H03-SORA40RSAGN-R-4
27 H03-SOYKC220873-R-0
28 H03-ZMD27S09A00-R-6
29 H03-SOJW2350SNN-R-7
30 H03-SORA40021GN-R-7
31 H03-SORA60031GN-R-4
32 H03-SOR12BJ12GN-R-1
33 H03-SOYKF457009-R-2
34 SOPA96063NN-R-0
35 H03-ZME06S02A00-R-3
36 H03-ZMC12S19A00-R-A
37 H03-SOTU301ALY1-R-1
38 H03-SWSDDJE1233-R-6
39 H03-ZME21S02A00-R-7
40 H03-SORA40RSAGN-R-4
41 H03-SWPVB25FHIN-R-A
42 ZUC1201AABK-R-7
43 ZUE0601ABBK-R-5
44 ZUE0601AABK-R-7
45 ZUE2101AABK-R
L1 ZKE2195HA00-R-4
L2 ZKE2130RV00-R-4
L3 ZKE0686AA00-R-A
L4 ZKC1281HA00-R-9
L5 ZKC1222HA00-R-2
S1 ZSTWM3008BY
S2 ZSMWM3008BZ-R-7
S3 ZSTBM2508BW-R-1
S4 ZSTBM3010BB-R-5
S5 ZSMCM4008BY-R-1
S6 ZSMPM3006LB-R-A
S7 ZSTGM3010BB-R-3
S8 ZSTWM4008BB-R
SP H03-ZMB01S02200-R-6
W1 ZWM623108SZ-R-2
MV-5 EXPLODED VIEW PART LIST
ASS'Y SMPS 90~264V UNIVERSIAL KWANG SUNG
SPONGE-UL 30X30X12T BK
CHASSIS FRONT MV-5
COVER TOP MV-5
DISPLAY VFD,M202MD15GK FUTABA
BUTTON FUNCTIONAL-LED RV-5 550-13634
VOLUMN KNOB AL RV-5
VOLUMN KNOB D-SPRING RV-5
AL PANEL FRONT MV-5
FILTER VFD RV-5
PANEL FRONT PLASTIC HIPS V2 SPRAY MV-5 SHIN BO
BUTTON FUNCTIONAL RV-5 550-13633
RUBBER FOOT 19.7X19.7X2T BK
FOOT 50MM 15.8MM
CHASSIS MAIN MV-5
STANDOFF HEX M4X0.7 6X45.4H ,DONG SHIN
SHIELD DSP AVR745
JACK PHONE 3.5PI PJ0435179G
JACK RCA 4P,JB040131PG,DONGBO
JACK RCA 6P JB060132PG WWWRRR,GOLD COLOR
BKT IPOD
JACK RCA 4P JB040131QG WH BU RD GY,GOLD COLOR
JACK RCA 1P PPJ-440FEG PP ,GOLD COLOR
STANDOFF HEX M4X0.7 6X74.6H,DONG SHIN
JACK RCA 4P JB040131QG WH BU RD GY,GOLD COLOR
JACK RCA 4P JB040131ZG GN BN PP TA ,GOLD COLOR
YKC22-0873N JALCO
BKT XM DONGSHIN
JACK PHONE 3.6 EP-1401A 1P BK
JACK RCA+S-VIDEO 4P C80200212G DONGBO
JACK RCA+S-VIDEO 6P C80300312G,GOLD COLOR
JACK RCA 12P BJ120154JG R4 BU4 G4,GOLD COLOR
JACK HDMI YKF45-7009 JALCO
JACK D-SUB 9P 87204-6063 W/DUST COVER BK
BKT GND SMALL,DONG BO
BKT AC INLET
JACK AC INLET TU-301-AL-L-Y11E TECX-UNIONS
SDDJE12300 HOSODA
PANEL REAR MV-5
JACK RCA 4P JB040131ZG GN BN PP TA ,GOLD COLOR
REB161 (9x7)PVB25FHINB1-2-24PCE NOBLE
SPONGE 30X30X10T BK
SHIELD FORM GASKET 10X9X30(WxHxL)mm
SHIELD FORM
SPONGE 10X30X3.0T
LABEL LICENSE MV-5
LABEL SERIAL MV-5 TF PRINT
LABEL ORIGIN MADE IN P.R.C.
LABEL QC CHECK
LABEL RISK
SCREW ST W 3X8
SCREW M.S M3X8 W/H ZN PLATED
SCREW 2.5X8 Zinc Plate WH
SCREW ST BH 3X10
SCREW BM 4X8
SCREW.M.S.M3X6 P/HD BLACK
SCREW ST BH 3X10 GROUND
SCREW ST WPH 4X8
SPRING PLATE GND C5212 0.2T
WASHER SPRING 3
7
DESCRIPTION
END
LEXICON
Q'TY
1.0000
1.0000
1.0000
1.0000
1.0000
28.0000
1.0000
1.0000
1.0000
1.0000
1.0000
2.0000
4.0000
4.0000
1.0000
2.0000
1.0000
1.0000
2.0000
1.0000
1.0000
1.0000
1.0000
2.0000
1.0000
1.0000
4.0000
1.0000
1.0000
1.0000
1.0000
1.0000
3.0000
1.0000
1.0000
2.0000
1.0000
1.0000
1.0000
1.0000
1.0000
1.0000
9.0000
3.0000
1.0000
1.0000
1.0000
1.0000
2.0000
1.0000
25.0000
14.0000
4.0000
10.0000
5.0000
3.0000
36.0000
8.0000
1.0000
2.0000
2.0000
2.0000
