Co6z LED Zoom Flood IP65 270W RGBW
LED floodlight

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Co6z LED Flood and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ignition Co6z LED Flood

Summary of Contents for Ignition Co6z LED Flood

  • Page 1 Co6z LED Zoom Flood IP65 270W RGBW LED floodlight...
  • Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 22.05.2020, ID: 472138 (V2)

  • Page 3: Table Of Contents

    Table of contents Table of contents General information......................4 1.1 Further information......................4 1.2 Notational conventions....................4 1.3 Symbols and signal words................... 5 Safety instructions......................... 6 Features............................9 Installation..........................10 Starting up..........................12 Connections and controls....................13 Operating..........................16 7.1 Starting the device....................... 16 7.2 Main menu........................

  • Page 4: General Information

    General information General information This user manual contains important information on the safe operation of the device. Read and follow all safety notes and all instructions. Save this manual for future refer‐ ence. Make sure that it is available to all persons using this device. If you sell the device to another user, be sure that they also receive this manual.

  • Page 5: Symbols And Signal Words

    General information 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided.

  • Page 6: Safety Instructions

    Safety instructions Safety instructions Intended use This device is intended for use as an electronic lighting effect by means of LED tech‐ nology. The device is designed for professional use and is not suitable for use in households. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage.
  • Page 7 Safety instructions WARNING! Eye damage caused by high light intensity Never look directly into the light source. WARNING! Risk of epileptic shock Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons should avoid looking at strobe lights. WARNING! Risk of injury caused by falling objects Make sure that the installation complies with the standards and rules that apply in your country.
  • Page 8 Safety instructions NOTICE! Risk of fire by exceeding the maximum current The device can power further devices via a lockable Power Twist output socket. The current consumption of all further devices connected in series must not exceed 10 A, otherwise injuries and irreparable damage to the device can occur.

  • Page 9: Features

    Features Features The high-performance LED floodlight with zoom optics is particularly suitable for architectural and stage lighting. Special features of the device: 18 × RGBW LEDs (each 15 W), background lighting: 42 × 0.2 W RGB LEDs Three separately controllable LED rows Motorized zoom Operation in stand-alone and DMX mode (8 different modes) Simple operation via display and buttons on the unit...

  • Page 10: Installation

    Installation Installation Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. DANGER! Hazardous voltage The wiring, as well as all maintenance and repair work on the electrical...
  • Page 11 Installation NOTICE! Possible data transmission errors For error-free operation make use of dedicated DMX cables and do not use ordinary microphone cables. Never connect the DMX input or output to audio devices such as mixers or amplifiers. NOTICE! Possible damage due to moisture Moisture entering into open connectors (plugs and couplers) of DMX or power cords can cause short circuits.

  • Page 12: Starting Up

    Starting up Starting up Create all connections while the device is off. Use the shortest possible high-quality cables for all connections. Take care when running the cables to prevent tripping hazards. Connections in DMX mode Connect the DMX input of the device to the DMX output of a DMX controller or another DMX device.

  • Page 13: Connections And Controls

    Connections and controls Connections and controls Overview Zoom motor Adjustable LED panel Locking screw for the LED panel Radio antenna Control panel with display membrane button Co6z LED Zoom Flood IP65 270W RGBW LED floodlight...
  • Page 14 Connections and controls Front panel [MODE] Activates the main menu and toggles between menu items. Closes an opened submenu. Display [UP] Navigates upwards in a menu list. Increases the displayed value by one. [W-DMX LED] Status LED. LED lights up as soon as a DMX signal from the W-DMX module is present. [DOWN] Navigates downwards in a menu list.
  • Page 15 Connections and controls Rear panel [POWER IN] Connection for power supply, designed as Power Twist IP65 [POWER OUT] Connection for power supply of other units, designed as Power Twist IP65 (output current max. 10 A) [DMX IN] DMX input (3-pin XLR chassis plug, IP65 design) [DMX OUT] DMX output (3-pin XLR chassis socket, IP65 design) Co6z LED Zoom Flood IP65 270W RGBW...

  • Page 16: Operating

    Operating Operating 7.1 Starting the device Connect the device to the power supply to start operation. The display shows ‘Software-Update ‘Please Wait - Welcome to LED Wash Zoom’’ . During the start-up process, the display shows the model name and the software version of the device successively.
  • Page 17 Operating Press [MODE] and [ENTER] simultaneously to go directly to the last edited submenu. All previously made settings are retained even when you disconnect the device from the power grid. To restart with default values, use the function ‘Factory Reset’ . The following table shows the setting options.
  • Page 18 Operating Main menu Menu level 2 Menu level 3 Menu level 4 Meaning 103…127 Strobe-burst effect with decreasing duration of inter‐ ruptions 128…250 Strobe effect with increasing speed 251…255 Open strobe ‘Red’ 0…255 Intensity Red (0 % to 100 %) ‘Green’...
  • Page 19 Operating Main menu Menu level 2 Menu level 3 Menu level 4 Meaning 81…105 Automatic show 4 106…130 Automatic show 5 131…155 Automatic show 6 156…180 Automatic show 7 181…205 Automatic show 8 206…230 Automatic show 9 231…255 Automatic show 10 ‘Auto speed’...
  • Page 20 Operating Main menu Menu level 2 Menu level 3 Menu level 4 Meaning ‘Cold White’ Cold white ‘Settings’ ‘Display Rev’ Display inversion ‘ON’ On. Display is rotated by 180° ‘OFF’ Off. Normal display ‘Display’ Automatic display shutdown when not in use ‘ON’...

  • Page 21: Operating Mode 'Dmx

    Operating Main menu Menu level 2 Menu level 3 Menu level 4 Meaning ‘Fan Set’ Fan speed ‘Regular’ Automatic fan speed control ‘Silent’ Low fan speed, reduced brightness ‘Wireless DMX’ Wireless DMX control ‘No’ Disabled ‘Yes’ Enabled ‘Test’ Function tests ‘ALL’...

  • Page 22: Operating Mode 'Slave

    Operating If the device is controlled via ‘W-DMX’, the status LED [ W-DMX LED] flashes on its front panel. The display shows the signal strength in the top row. Display no signal weak signal medium signal strong signal Status LED [W-DMX LED] LED off No connection to DXM controller LED flashes quickly Disconnected from DMX controller...

  • Page 23: Menu Overview

    Operating 7.3 Menu overview Co6z LED Zoom Flood IP65 270W RGBW LED floodlight...

  • Page 24: Functions In 3-Channel Dmx Mode

    Operating 7.4 Functions in 3-channel DMX mode Channel Value Function 0…255 Zoom (0 % to 100 %) 0…255 Dimmer (0 % to 100 %) Colour macro 0…5 Blackout 6…13 14…21 Amber 22…29 Yellowish-amber coloured 30…37 Yellow 38…45 Green 46…53 Turquoise 54…61 Cyan 62…69...

  • Page 25: Functions In 4-Channel Dmx Mode 1

    Operating 7.5 Functions in 4-channel DMX mode 1 Channel Value Function 0…255 Zoom (0 % to 100 %) 0…255 Dimmer (0 % to 100 %) Stroboscope functions 0…5 Open strobe 6…10 Closed strobe 11…250 Strobe effect, increasing speed 251…255 Open strobe Colour macro 0…5 Blackout...

  • Page 26: Functions In 4-Channel Dmx Mode 2

    Operating 7.6 Functions in 4-channel DMX mode 2 Channel Value Function 0…255 Zoom (0 % to 100 %) 0…255 Intensity Red (0 % to 100 %) 0…255 Intensity Green (0 % to 100 %) 0…255 Intensity Blue (0 % to 100 %) 7.7 Functions in 5-channel DMX mode Channel Value...

  • Page 27: Functions In 16-Channel Dmx Mode 1

    Operating 7.8 Functions in 16-channel DMX mode 1 Channel Value Function 0…255 Zoom (0 % to 100 %) 0…255 Dimmer (0 % to 100 %) 0…255 Dimmer fine setting (0 % to 100 %) Stroboscope functions 0…5 Open strobe 6…10 Closed strobe 11…250 Strobe effect, increasing speed...
  • Page 28 Operating Channel Value Function 192…255 Colour transition effect, increasing speed Dimmer curve 0…5 No function 6…63 Linear 64…127 Exponential 128…191 Logarithmic 192…255 S-shaped Special functions. Settings are enabled or retained if the corresponding DMX value is held for five seconds. 0…5 No function 6…55...

  • Page 29: Functions In 16-Channel Dmx Mode 2

    Operating 7.9 Functions in 16-channel DMX mode 2 Channel Value Function 0…255 Zoom (0 % to 100 %) 0…255 Intensity red (0 % to 100 %), LED row 1 0…255 Intensity green (0 % to 100 %), LED row 1 0…255 Intensity blue (0 % to 100 %), LED row 1 0…255...

  • Page 30: Functions In 22-Channel Dmx Mode

    Operating 7.10 Functions in 22-channel DMX mode Channel Value Function 0…255 Zoom (0 % to 100 %) 0…255 Zoom with decreasing speed 0…255 Dimmer (0 % to 100 %) 0…255 Dimmer fine setting (0 % to 100 %) Stroboscope functions 0…5 Open strobe 6…10...
  • Page 31 Operating Channel Value Function 94…101 Pink 102…109 Warm white 110…117 White 118…125 Cold white 126…127 No colour change effect 128…191 Colour change effect, increasing speed 192…255 Colour transition effect, increasing speed Rainbow effect 0…5 Effect off 6…21 Rainbow effect 1 22…37 Rainbow effect 2 38…53...
  • Page 32 Operating Channel Value Function 156…180 Automatic show 7 181…205 Automatic show 8 206…230 Automatic show 9 231…255 Automatic show 10 0…255 Running speed automatic show, increasing 0…255 Automatic Fade effect Dimmer curve 0…5 No function 6…63 Linear 64…127 Exponential 128…191 Logarithmic 192…255 S-shaped...
  • Page 33 Operating Channel Value Function 54…61 Cyan 62…69 Blue 70…77 Lavender 78…85 Mauve 86…93 Magenta 94…101 Pink 102…109 Warm white 110…117 White 118…125 Cold white 126…127 No colour change effect 128…191 Colour change effect, increasing speed 192…255 Colour transition effect, increasing speed Co6z LED Zoom Flood IP65 270W RGBW LED floodlight...

  • Page 34: Functions In 34-Channel Dmx Mode

    Operating 7.11 Functions in 34-channel DMX mode Channel Value Function 0…255 Zoom (0 % to 100 %) 0…255 Zoom with decreasing speed 0…255 Dimmer (0 % to 100 %) 0…255 Dimmer fine setting (0 % to 100 %) Stroboscope functions 0…5 Open strobe 6…10...
  • Page 35 Operating Channel Value Function 94…101 Pink 102…109 Warm white 110…117 White 118…125 Cold white 126…127 No colour change effect 128…191 Colour change effect, increasing speed 192…255 Colour transition effect, increasing speed Rainbow effect 0…5 Effect off 6…21 Rainbow effect 1 22…37 Rainbow effect 2 38…53...
  • Page 36 Operating Channel Value Function 156…180 Automatic show 7 181…205 Automatic show 8 206…230 Automatic show 9 231…255 Automatic show 10 0…255 Running speed automatic show, increasing 0…255 Automatic Fade effect Dimmer curve 0…5 No function 6…63 Linear 64…127 Exponential 128…191 Logarithmic 192…255 S-shaped...
  • Page 37 Operating Channel Value Function 0…255 Strobe effect background colour, increasing speed (0% to 100%) 0…255 Background intensity red (0 % to 100 %) 0…255 Background intensity green (0 % to 100 %) 0…255 Background intensity blue (0 % to 100 %) Colour macro background 0…5 Blackout...

  • Page 38: Technical Specifications

    Technical specifications Technical specifications Light source 18 × RGBW LEDs (15 W each), Backlight: 42 × 0.2 W RGB LEDs Optical properties Beam angle 7°…58° Control DMX, W-DMX, buttons and display on the unit Number of DMX channels 3, 4, 5, 16, 22 or 34 Input connections Voltage supply lockable input socket...

  • Page 39: Plug And Connection Assignments

    Plug and connection assignments Plug and connection assignments Introduction This chapter will help you select the right cables and plugs to connect your valuable equipment so that a perfect light experience is guaranteed. Please take our tips, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into a socket, the result of an incorrect connection may be a destroyed DMX controller, a short circuit or ‘just’...

  • Page 40: Troubleshooting

    Troubleshooting Troubleshooting In the following we list a few common problems that may occur during operation. We give you some suggestions for easy troubleshooting: Symptom Remedy The unit does not work, no light Check the mains connection and main fuse. One colour does not work or the colours differ Check the settings in the ‘White Balance’...

  • Page 41: Cleaning

    Cleaning Cleaning Optical lenses Clean the optical lenses, that are accessible from the outside, regularly in order to optimize the light output. The frequency of cleaning depends on the operating envi‐ ronment: wet, smoky or particularly dirty surroundings can cause more accumulation of dirt on the optics of the device.

  • Page 42: Protecting The Environment

    Protecting the environment Protecting the environment Disposal of the packaging material For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
  • Page 44 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
