  • Page 1 Co6 LED Flood IP65 270W RGBW LED floodlight...
  • Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 07.02.2019, ID: 443193 (V2)

  • Page 3: Table Of Contents

    7.8 Functions in 12-channel DMX mode..............25 7.9 Functions in 14-channel DMX mode..............26 7.10 Functions in 26-channel DMX mode..............29 Technical specifications....................32 Plug and connection assignments................33 Troubleshooting........................34 Cleaning............................ 35 Protecting the environment................... 36 Co6 LED Flood IP65 270W RGBW LED floodlight...
  • Page 4 Co6 LED Flood IP65 270W RGBW LED floodlight...

  • Page 5: General Information

    The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. Displays Texts and values displayed on the device are marked by quotation marks and italics. Examples: ‘24ch’ , ‘OFF’ . Co6 LED Flood IP65 270W RGBW LED floodlight...

  • Page 6: Symbols And Signal Words

    Warning signs Type of danger Warning – high-voltage. Warning – dangerous optical radiation. Warning – suspended load. Warning – danger zone. Co6 LED Flood IP65 270W RGBW LED floodlight...

  • Page 7: Safety Instructions

    Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. Do not use the device if covers, protectors or optical components are missing or damaged. Co6 LED Flood IP65 270W RGBW LED floodlight...
  • Page 8 PVC floor and after some time cause permanent dark stains. In case of doubt, do not put the rubber feet directly on the floor, but use felt-pad floor protectors or a carpet. Co6 LED Flood IP65 270W RGBW LED floodlight...

  • Page 9: Features

    UV rays). The seals and screw connections of the equipment must be checked regularly to ensure a fault-free operation. In cases of doubt, consult a specialist workshop in due time. Co6 LED Flood IP65 270W RGBW LED floodlight...

  • Page 10: Installation

    When mounting the device onto a stand, ensure that the stand is in a safe and stable position and that the weight of the device does not exceed the maximum permissible load capacity of the stand. Co6 LED Flood IP65 270W RGBW LED floodlight...
  • Page 11 Always work from a stable platform whenever installing, moving or servicing the unit. In doing so, the area underneath the unit must be cordoned off. 1 Openings for safety cable 2 Quick-lock openings for omega bracket Co6 LED Flood IP65 270W RGBW LED floodlight...

  • Page 12: Starting Up

    Then connect the DMX output of the first slave device to the DMX input of the second slave device and so on. Please note that this device must not be connected to a dimmer. Co6 LED Flood IP65 270W RGBW LED floodlight...

  • Page 13: Connections And Controls

    Navigates upwards in a menu list. Increases the displayed value by one. [DOWN] Navigates downwards in a menu list. Decreases the displayed value by one. [ENTER] Selects an option of the respective operating mode, confirms the set value. Co6 LED Flood IP65 270W RGBW LED floodlight...
  • Page 14 Rear panel [POWER IN] Connection supply voltage incoming (Power Twist IP65) [POWER OUT] Connection supply voltage outgoing (Power Twist IP65) [DMX OUT] DMX output (IP65 design) [DMX IN] DMX input (IP65 design) Co6 LED Flood IP65 270W RGBW LED floodlight...

  • Page 15: Operating

    The device is then ready for use. The dis‐ play shows the operating mode that was selected when the unit was last powered off. Co6 LED Flood IP65 270W RGBW LED floodlight...

  • Page 16: Main Menu

    Automatic Fade effect ‘Auto Jumping’ 0…255 Automatic Jump effect ‘Static’ ‘Dimmer’ 0…255 Setting the overall brightness ‘Strobe’ Strobe effect 0…5 Open strobe 6…10 Closed strobe 11…33 Random Pulse effect with increasing speed Co6 LED Flood IP65 270W RGBW LED floodlight...
  • Page 17 70…85 Rainbow effect 5 86…101 Rainbow effect 6 102…117 Rainbow effect 7 118…133 Rainbow effect 8 134…149 Rainbow effect 9 150…165 Rainbow effect 10 166…181 Rainbow effect 11 182…197 Rainbow effect 12 Co6 LED Flood IP65 270W RGBW LED floodlight...
  • Page 18 Fade speed for auto‐ matic shows ‘Color Macro’ Pre-defined colour ‘Red’ ‘Amber’ Amber ‘Yellow Amber’ Yellowish-amber coloured ‘Yellow’ Yellow ‘Green’ Green ‘Turquoise’ Turquoise ‘Cyan’ Cyan ‘Blue’ Blue ‘Lavender’ Lavender ‘Mauve’ Mauve ‘Magenta’ Magenta ‘Pink’ Pink Co6 LED Flood IP65 270W RGBW LED floodlight...
  • Page 19 ‘25 kHz’ Refresh rate of the LEDs: 25 kHz ‘White Balance’ White balance ‘Red’ 0…255 Red proportion ‘Green’ 0…255 Green proportion ‘Blue’ 0…255 Blue proportion ‘White’ 0…255 White proportion ‘Fan Set’ Fan speed Co6 LED Flood IP65 270W RGBW LED floodlight...

  • Page 20: Operating Mode 'Dmx

    The display flashes if no DMX signal is received. If the device is controlled via ‘W-DMX’, the LED [W-DMX LED] flashes on its front panel. The display shows the signal strength in the top row. Co6 LED Flood IP65 270W RGBW LED floodlight...

  • Page 21: Operating Mode 'Slave

    ‘Operating Mode: AUTO Jumping’ : Automatic Jump effect ‘Operating Mode: STATIC’ : Freely mixable colour with optional rainbow and stro‐ boscopic effect or automatic show ‘Operating Mode: Color Macro’ : Selecting a pre-defined colour macro Co6 LED Flood IP65 270W RGBW LED floodlight...

  • Page 22: Menu Overview

    Operating 7.3 Menu overview Co6 LED Flood IP65 270W RGBW LED floodlight...

  • Page 23: Functions In 2-Channel Dmx Mode

    70…77 Lavender 78…85 Mauve 86…93 Magenta 94…101 Pink 102…109 Warm white 110…117 White 118…125 Cold white 126…127 Colour change halted 128…191 Colour change effect, increasing speed 192…255 Colour transition effect, increasing speed Co6 LED Flood IP65 270W RGBW LED floodlight...

  • Page 24: Functions In 3-Channel Dmx Mode 1

    70…77 Lavender 78…85 Mauve 86…93 Magenta 94…101 Pink 102…109 Warm white 110…117 White 118…125 Cold white 126…127 Colour change halted 128…191 Colour change effect, increasing speed 192…255 Colour transition effect, increasing speed Co6 LED Flood IP65 270W RGBW LED floodlight...

  • Page 25: Functions In 3-Channel Dmx Mode 2

    Intensity green (0 % to 100 %), LED row 3 0…255 Intensity blue (0 % to 100 %), LED row 3 0…255 Intensity white (0 % to 100 %), LED row 3 Co6 LED Flood IP65 270W RGBW LED floodlight...

  • Page 26: Functions In 14-Channel Dmx Mode

    Intensity white (0 % to 100 %) Colour macro 0…5 Blackout 6…13 14…21 Amber 22…29 Yellowish-amber coloured 30…37 Yellow 38…45 Green 46…53 Turquoise 54…61 Cyan 62…69 Blue 70…77 Lavender 78…85 Mauve 86…93 Magenta 94…101 Pink 102…109 Warm white Co6 LED Flood IP65 270W RGBW LED floodlight...
  • Page 27 6…30 Automatic show 1 31…55 Automatic show 2 56…80 Automatic show 3 81…105 Automatic show 4 106…130 Automatic show 5 131…155 Automatic show 6 156…180 Automatic show 7 181…205 Automatic show 8 Co6 LED Flood IP65 270W RGBW LED floodlight...
  • Page 28 6…63 Dimmer characteristic ‘LED’ (3 s delay) 64…127 Dimmer characteristic ‘Halogen’ (5 s delay) 128…191 Fan speed setting ‘Silent’ activated (3 s delay) 192…255 Fan speed setting ‘Silent’ deactivated (3 s delay) Co6 LED Flood IP65 270W RGBW LED floodlight...

  • Page 29: Functions In 26-Channel Dmx Mode

    Intensity white (0 % to 100 %) Colour macro 0…5 Blackout 6…13 14…21 Amber 22…29 Yellowish-amber coloured 30…37 Yellow 38…45 Green 46…53 Turquoise 54…61 Cyan 62…69 Blue 70…77 Lavender 78…85 Mauve 86…93 Magenta 94…101 Pink 102…109 Warm white Co6 LED Flood IP65 270W RGBW LED floodlight...
  • Page 30 6…30 Automatic show 1 31…55 Automatic show 2 56…80 Automatic show 3 81…105 Automatic show 4 106…130 Automatic show 5 131…155 Automatic show 6 156…180 Automatic show 7 181…205 Automatic show 8 Co6 LED Flood IP65 270W RGBW LED floodlight...
  • Page 31 Intensity green (0 % to 100 %), LED row 3 0…255 Intensity blue (0 % to 100 %), LED row 3 0…255 Intensity white (0 % to 100 %), LED row 3 Co6 LED Flood IP65 270W RGBW LED floodlight...

  • Page 32: Technical Specifications

    –20 °C … +40 °C Relative humidity 50 %, non condensing Further information Outdoor housing design Floodlight Colour mixture RGBW LED type x-in-1 Base housing Fanless Remote control Not possible Wireless DMX Housing colour Black Co6 LED Flood IP65 270W RGBW LED floodlight...

  • Page 33: Plug And Connection Assignments

    The unit offers a 3-pin XLR socket for DMX output and a 3-pin XLR plug for DMX input. Please refer to the drawing and table below for the pin assignment of a suit‐ able XLR plug. Configuration Ground, shielding Signal inverted (DMX–, ‘cold signal’) Signal (DMX+, ‘hot signal’) Co6 LED Flood IP65 270W RGBW LED floodlight...

  • Page 34: Troubleshooting

    DMX interface circuit. 4. Press Mode until the display shows ‘ADDRESS XXX’ . If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. Co6 LED Flood IP65 270W RGBW LED floodlight...

  • Page 35: Cleaning

    Clean with a soft cloth using our lamp and lens cleaner (item no. 280122). Always dry the parts carefully. Co6 LED Flood IP65 270W RGBW LED floodlight...

  • Page 36: Protecting The Environment

    Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. Co6 LED Flood IP65 270W RGBW LED floodlight...
  • Page 37 Notes Co6 LED Flood IP65 270W RGBW LED floodlight...
  • Page 38 Notes Co6 LED Flood IP65 270W RGBW LED floodlight...
  • Page 40 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
