This chapter describes the RCM2100 hardware in more detail,
and explains how to set up and use the accompanying prototyp-
ing and development board.
NOTE: This chapter (and this manual) assume that you have the RabbitCore RCM2100
Development Kit. If you purchased an RCM2100 module by itself, you will have to
adapt the information in this chapter and elsewhere to your test and development setup.
2.1 Connections
There are three steps to connecting the Prototyping Board for use with Dynamic C and the
sample programs:
1. Attach the RCM2100 module to the Prototyping Board.
2. Connect the programming cable between the RCM2100 module and the workstation PC.
3. Connect the power supply to the Prototyping Board.
User's Manual
2. G
ETTING
S
TARTED
7
