PowerBase 577138 Instruction Manual page 15

Parts
1 Switch lever
2 Cable strain-relief
3 Switch box housing
4 Upper handle bar
5 Quick-release lever (x 4)
5a Washer (x 4)
5b Bolt (x 2)
6 Grass collection bag handle
7 Lower handle bar
8 Grass collection bag top
Grass collection bag full
8a
indicator
8b Frame* (x 2)
9 Grass collection bag
9a Clamping sleeve* (x 2)
NOTE: Parts marked with * are not shown in this overview. Please refer
to the respective section in the instruction manual.
9b Slot* (x 2)
10 Cutting height adjuster
11 Rear wheel
12 Front wheel
13 Motor housing
14 Carrying handle
15 Cable guide
16 Deflector guard
17 Cable clip (x 2)
18 Safety button
19 Blade
20 Nut
21 Rear roller
15
