32cm 1200W Electric
Rotary Lawn Mower
These instructions contain important information that will help you get the best from your product,
ensuring it is assembled correctly and safely. If you need help or have damaged or missing parts, call
the Customer Helpline on 0343 515 1905.
577136
Instruction
Manual
IMPORTANT!
Please read these
instructions fully before
starting assembly.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PowerBase 577136
Summary of Contents for PowerBase 577136
- Page 1 32cm 1200W Electric starting assembly. Rotary Lawn Mower 577136 These instructions contain important information that will help you get the best from your product, ensuring it is assembled correctly and safely. If you need help or have damaged or missing parts, call...
-
Page 2: Table Of Contents
Contents General Safety Warnings Intended Use Warning Symbols In the Box Assembly Operation Maintenance And Storage Troubleshooting Technical Data Disposal Getting Help Warranty... -
Page 3: General Safety Warnings
General Safety Warnings General safety Important - Please read these instructions fully before starting assembly. IMPORTANT! When using equipment, the following safety precautions must be followed to avoid injuries and damage: • Read all operating instructions carefully and comply with them. It is important to understand these instructions and to acquaint yourself with the machine, its correct usage and all safety requirements. - Page 4 requirements as described in DIN 57 282/ VDE 0282 and must have a minimum cross-section of 1.5mm . The plug must have an earth and any connection must also be earthed and splashproof. Before use, check the cables for signs of damage and ageing. Never use the mower if the cables are not in perfect condition (this also applies to the supply cable on the mower).
- Page 5 that they do not play with the appliance. • The appliance is only to be used with the power supply unit provided with the appliance. Personal safety • Always check the mower for signs of damage before each usage. • Always disconnect the mains lead from the electrical supply before carrying out any inspection, servicing or maintenance work.
- Page 6 the lawn mower whilst the lawn mower is being used. • Only work in good daylight or appropriate and adequate artificial light. • Never use the mower when you are tired. • Never run the mower in enclosed or poorly- ventilated rooms or if there are flammable or explosive fluids, vapours or gases nearby.
- Page 7 particularly long. In this case only tilt it up as far as is really necessary and only raise the side that is furthest away from you. • Never reach towards rotating parts with your hands or feet. Always keep away from the discharge chute.
- Page 8 mower. Ensure that you keep everybody at least 10 metres away from the mower when it is working. • Switch off the motor and disconnect the plug from the power supply if the mower strikes a foreign body. Check the mower for signs of damage and carry out all necessary repair work before you start the mower again.
- Page 9 complete standstill. • Never lift or carry the mower whilst the motor is running. • Switch off the motor and disconnect the plug whenever you leave the lawn mower. • Keep the lawn mower in a dry place which is inaccessible to children at all times.
- Page 10 The blade can cause damage to cords and lead to contact with live parts. • Disconnect from the mains supply (i.e. remove the plug from the mains socket) − Whenever leaving the machine unattended. − Before cleaning a blockage. − After striking a foreign object. −...
-
Page 11: Intended Use
Intended Use This lawn mower is designed for domestic use only: • This electric lawn mower is intended for mowing lawns in domestic and hobby gardens. • This product is not to be used in wet weather conditions and may not be used to mow wet or unusually high grass. -
Page 12: Warning Symbols
Warning Symbols The following warning symbols appear throughout this manual and indicate the appropriate safety measures you should take when operating and maintaining the appliance. Read the instruction handbook before operating this machine. Wear eye and ear protection (PPE). Do not expose to rain. Keep bystanders away. - Page 13 Guaranteed sound power level data (96dB) in accordance with Directive 2000/14/EC. Class II equipment. Recycle unwanted materials instead of disposing of them as household waste. All tools, hoses and packaging should be sorted, taken to the local recycling centre and disposed of in an environmentally safe way.
-
Page 14: In The Box
In the Box... - Page 15 Parts Upper handle bar Motor housing Bolt (x 2) Deflector guard Lower handle bar (x 2) Cable clip (x 2) Grass collection box handle Wing knob (x 2) Grass collection box top Switch box housing Grass collection box Cable strain-relief Grass collection box full Safety button indicator...
-
Page 16: Assembly
Assembling The Lawn Mower Step 1 – Assembling handles 1. Insert the lower handle bar (3) into the supports (7) on the deck (10) (Fig. 1) 2. Fix the lower handle bar (3) using the enclosed screws (8) (Fig. 2). Fig. - Page 17 1. Clip the grass collection box handle (4) into the grass collection box top (5) (Fig. 5). 2. Align the front ends of the top and the bottom of the grass collection- box (6). Clip the two halves together, starting at the front (Fig. 6) 3.Finally, press the insert (6b) into the grass collection box (6), and make sure the insert is located securely in position.
-
Page 18: Operation
Operation Setting the cutting height WARNING! Ensure the power cord is disconnected from the mains supply before adjusting the cutting height. • Place the lawn mower on its side. • Grasp the wheel axle (18) on both sides (Fig. 9). •... - Page 19 Fig. 10 Switching on and off WARNING: Before switching on, ensure that the mower is not in contact with any foreign objects. 1. To switch on, press the safety button (16) on the handle, then activate the switch lever (17). Release the safety button (16). (Fig. 11). 2.
- Page 20 Operation Before you connect the equipment to the mains supply, make sure that the data on the rating plate corresponds to your mains supply. WARNING! Always ensure the on/off switch is working correctly; do not use if you suspect a fault. Before you perform any repair or maintenance work on the machine, ensure that the blade is not rotating and that the power supply is disconnected.
- Page 21 Mowing direction Place the mains lead in loops on the ground near the wall socket. Mow away from the socket and cable and ensure that the mains lead is always on the section of lawn that you have already mowed so that you do not run over the mains lead with the mower (Fig.
- Page 22 Emptying grass collection box To remove the grass collection box, raise the deflector guard (11) with one hand and remove the grass collection box (6) holding its handle (4) with your other hand (Fig. 15). To maintain safety, the deflector guard automatically closes to the rear discharge position when you remove the grass collection box (6).
-
Page 23: Maintenance And Storage
Maintenance and Storage Cleaning WARNING! Always switch the product off, disconnect it from power supply and let the product cool down before performing inspection, maintenance and cleaning work! 1. Keep all safety devices, air vents and the motor housing free of dirt and dust as far as possible. - Page 24 Blade maintenance WARNING! If the blade is blunt, it can be sharpened in a specialised workshop. If the blade is damaged or showing signs of imbalance, it must be replaced. Carry out the following steps to change the blade: 1. Turn the mower over and rest it carefully on its side. 2.
- Page 25 Plug replacement 13AMP fuse approved to BS 1362 Connecet Blue Brown L (Live) to N (Neutral) Outer sleeve Cable grip firmly clamped If you need to replace the fitted plug, then follow the instructions below. IMPORTANT! The wires in the mains lead are coloured in accordance with the following code: Blue –...
-
Page 26: Troubleshooting
Troubleshooting WARNING! Only perform the steps described within these instructions! All further inspection, maintenance and repair work must be performed by a qualified specialist! Always turn off the machine and remove the plug before making any adjustment. The following table provides solutions to common problems encountered with the mower. -
Page 27: Technical Data
Technical Data Technical data table Specification Value Model M5E1232E Voltage 220-240V ~ 50Hz Power input 1200W No load speed 3400min Cutting width 32cm Cutting height 20mm/40mm/60mm Volume of grass collection box Measured sound pressure level L 80dB(A) K=3dB(A) Measured sound power level L 90.6dB(A) K=2.08dB(A) Guaranteed sound power level L 96dB(A) -
Page 28: Disposal
Disposal Disposal and recycling Recycle unwanted materials instead of disposing of them as household waste. All tools, hoses and packaging should be sorted, taken to the local recycling centre and disposed of in an environmentally safe way. Getting Help If you need help or have damaged or missing parts, call the Customer Helpline on 0343 515 1905.
